12
11.Replace the lower hinge part to the
left side and fixi it with the special
flange self-tapping screws. Replace the
adjustable bottom feet parts
to another side and fixing it.
12.Transfer the lower door to the
property position, adjust the lower
hinge part, make the hinge axis into the
lower hole of the lower door, then tight
the bolts.
middle hinge part
14. Transfer the upper door to the
appropriate position. Secure the door’s
level, make the middle hinge axis into
the lower hole of the upper door.
self-tapping screws
13.Slot the lower door onto the
bottom hinge pin and hold in
position. Turn the middle hinge by
180°, change the washer on the axis
to the lower side, adjust the middle
hinge to the appropriate position
and then install it ensuring the lower
door in secured in place.
washer
Note: washer may stick
to lower door
17. Open the upper door and install the
①Self-tapping screw
②Upper hinge cover
③Special flange screw
④Upper hinge
⑤Screw hole cover
③
①
②
④
⑤
15.Move the upper door to an
appropriate position, and then fix
part④ by screws③.(Please hold the
upper door by hand when
installing).Install the upper hinge
cover② on the left corner by screw①.
16.Install the screw hole cover⑤
on the top right coner of the refrigerator.
door racks and then close it. Note:
If your appliance has handle, you have
to reverse handle by follow instructions
below.
Remove the upper door and place it on
a smooth surface with its panel
upwards. Lever part① and part④,
then loose screws②. Change
handle③ to the right side, then install
screws②, part① and part④ in turn.
