INSTRUCTIONS AND SAFETY MANUAL
MODEL: CSM9NXTB /100977
SERIAL # ______________________________________
(FOR YOUR FUTURE REFERENCE PLEASE WRITE IN SERIAL # LOCATED ON MACHINE LABEL)
9” (230mm) STEEL CUTTING CIRCULAR SAW
IMPORTANT!
The Metal Devil saw you have purchased is a well–made tool.
Used according to the directions it will give you excellent service for a number of
metal-cutting applications. Misuse of this tool, however, could result in serious or fatal
injury. Please read these operating and safety instructions carefully and completely.
Read, understand and follow all safety information.
If you are uncertain about any aspect of using this equipment contact your distributor.
1
Ear and eye protection must be worn
while operating this equipment.
WARRANTY REPAIRS:
Contact your local Metal Devil Distributor for
assistance with obtaining warranty repairs.
MODEL CSM9NXTB/100977 SPECIFICATIONS
MACHINE
Motor: 120V 60Hz 15 Amp Watts 1800
Cutting Capabilities (Square Tubing) : 90˚ cut :1/4” (6mm) wall thickness
45˚ cut :1/4” (6mm) wall thickness
Bevel Cut: 0-45˚
Maximum Cutting Thickness: 3/8” (9.5mm)
Maximum Cutting Depth: 3.25” (82.6mm)
RPM No Load Speed: 2300 RPM
Recommended Max.Duty Cyle: 30 minutes
Sound Pressure Level: Under Load DB(A) 93.8
Weight: 22 lbs (10 kg’s)
BLADE DIMENSIONS
Diameter: 9” (229mm)
Arbor / Bore Diameter: 1˝
Avergage Blade Kerf: .083“ (2.1mm)
STANDARD EQUIPMENT SUPPLIED WITH SAW
1- Side Handle 1- Fence Guide
1- Pair Safety Goggles 1- Ear Plug Set
1- Carry Case 1- Blade Wrench
1- Operating Instructions 1- Metal Cutting Blade.
READ AND SAVE ALL INSTRUCTIONS FOR FUTURE USE!
NOTICE:
Normal wear and tear and damage caused by misuse
is not covered under the 1 year guarantee.
