MODEL CSM7NXTB /100960
SPECIFICATIONS:
MACHINE
Motor: 120V 60Hz 13 Amp Watts 1560
Cutting Capabilities: (Square Tubing) 90 degree cut :1/8” (3mm) wall thickness
Bevel Cut: 0-45˚
Max Cutting thickness: 1/4” (6mm) – mild steel plate
Maximum Cutting Depth: 2.36” (60mm)
RPM No Load Speed: 3800 RPM
Recommended Max.Duty Cyle: 30 minutes
Sound Pressure Level: Under Load DB(A) 88
Weight: 18 lbs / 8.2 kg’s
BLADE DIMENSIONS
Diameter: 7” (178mm) 7-1/4˝ (188mm)
Arbor / Bore Diameter: 20mm 20mm
Avergage Blade Kerf: .071“ (1.8mm)
STANDARD EQUIPMENT SUPPLIED WITH SAW
1- Side Handle
1- Fence Guide
1- Pair Safety Goggles
1- Ear Plug Set
1- Carry Case
1-6mm Hex Key
(For Hex Screws)
1- Operating Instructions
1- Metal Cutting Blade.
IMPORTANT!
The Metal Devil saw you have purchased is a well–made tool.
Used according to the directions it will give you excellent service for a number of
metal-cutting applications. Misuse of this tool, however, could result in serious or
fatal injury. Please read these operating and safety instructions carefully and
completely. Read, understand and follow all safety information. If you are uncertain
about any aspect of using this equipment contact your distributor.
1
Ear and eye protection must be worn
while operating this equipment.
WARRANTY REPAIRS:
Contact your local Metal Devil Distributor for
assistance with obtaining warranty repairs.
READ AND SAVE ALL INSTRUCTIONS FOR FUTURE USE!
NOTICE:
Normal wear and tear and damage caused by misuse
is not covered under the 1 year guarantee.
