1.5 Positioning the stove
Distance to walls and lintel
When the stove is positioned near combustible materials, observe all current local and national
building regulations with regards to clearances. Whatever regulations apply to your area, do
not in any case install the stove within 8 inches of combustible materials around the sides or 16
inches above the top of the stove. These distances may need to be increased if the materials
are sensitive to heat. Note also that wall paper and other decorative materials may become de-
tached with the effects of heat and care should be taken to ensure that they do not fall towards
the stove in such an event.
When the stove is positioned near non-combustible materials, a gap of 4 inches or more is
recommended for cleaning purposes and to ensure that heat circulates around the stove and
out into the room.
Appliance Clearances
Parallel Corner
Top or Rear Vent Side Rear
Integral rear and 8-in 10-in 7-in
bottom shields 205-mm 255-mm 180-mm
Integral shields plus 8-in 6-in 7-in
connector shield 205-mm 150-mm 180-mm
Integral shields and 8-in 6-in 7-in
double wall connector 205-mm 150-mm 180-mm
Minimum alcove 32-in
width 815-mm
Maximum alcove 24-in
depth 610-mm
Alcove ceiling above 36-in
stove top 915-mm
