INTELINANO PLUS
Input
code
Input source Type Terminal assignment
I00 Not Used binary T07, T11, T12, T13, T14, T15
I01 Emergency Stop binary T07, T11, T12, T13, T14, T15
I02 Remote Start/Stop binary T11
I03 Remote Start And Load binary T11
I04 Access Lock binary T07, T11, T12, T13, T14, T15
I05 AMF Blocked binary T07, T11, T12, T13, T14, T15
I06 MCB Feedback binary T07, T11, T12, T13, T14, T15
I07 GCB Feedback binary T07, T11, T12, T13, T14, T15
I10 External Warning 1 binary T07, T11, T12, T13, T14, T15
I11 External Warning 2 binary T07, T11, T12, T13, T14, T15
I12 External Warning 3 binary T07, T11, T12, T13, T14, T15
I13 External Shutdown 1 binary T07, T11, T12, T13,T14, T15
I14 External Shutdown 2 binary T07, T11, T12, T13, T14, T15
I15 External Shutdown 3 binary T07, T11, T12, T13, T14, T15
I20 Low Fuel Level binary T07, T11, T12, T13, T14, T15
I21 Fuel Level Analog analog T13, T14, T15
I22 Low Oil Pressure binary T07, T11, T12, T13, T14, T15
I23 Oil Pressure Analog analog T13, T14, T15
I24 High Coolant Temperature binary T07, T11, T12, T13, T14, T15
I25 Coolant Temperature Analog analog T13, T14, T15
I29 Fuel Level SD binary T07, T11, T12, T13, T14, T15
Normally Open Contact – output Normally Open Contact – input button
Normally Closed Contact – output Normally Closed Contact – input button
Outputs and inputs
User curves
I21 I23 I25
VDO Level % VDO 5 Bar VDO 40-120 °C
Datcon Level % VDO 10 Bar VDO 50-150 °C
Datcon 5 Bar Datcon High °C
Datcon 7 Bar Datcon Low °C
Datcon 10 Bar
NOT selected NOT selected NOT selected
To apply all changes return to the main setup menu and restart the controller by pressing the Stop button.
For ECU conguration use PC software NanoEdit. For more details see InteliNano AMF Reference Guide.
