INTELINANO PLUS
6
TECHNICAL DATA
Power supply range 6-36VDC
Power supply drop-out immunity 100ms
Power consumption 35 - 95 mA
Zero Power Mode consumption 52 - 344 μA
Operating temperature -20... 70°C
Operating humidity 95% non-condensing (IEC/EN 60068-2-30)
Protection degree (front panel) IP65 - with GASKET 4x405 only
IP50 - without gasket
Storage temperature -30... 80°C
Binary inputs (up to 6)
Input resistance 1,5 kΏ
Closed contact voltage <2V
Open contact voltage >3,5V
Binary outputs (up to 6)
Low current outputs (4) 500 mA
High current outputs (2) 6A - (long term) / 10A (short term) (L≤500mH)
Total output current 10A – (long term) / 16A – (short term) (L≤500mH)
Generator/Mains measurements
Measurement inputs 1ph generator voltage, 1ph current, 3ph mains voltage
Measurement type True RMS
Voltage range 480V Ph-Ph (277V Ph-N)
Max. measured voltage 340V Ph-N
Voltage accuracy 1 %
Frequency range 40-70 Hz
Frequency accuracy 1 %
Current range 0 - 5 A
Current accuracy 2% True RMS
Charging alternator preexcitation circuit
Excitation current 100 mA
Charging fail threshold 80%
USB (device) On the board
Type CAN bus
Galvanic insulation No
Baud rate 250 kbps
Bus length max. 200m
Termination resistor 120 Ohm, built-in, jumper activated
