SYMBOLS - ABBREVIATIONS LEGEND MAGIC WELD
M
2.3
© MOSA 1.0-05/04
21/05/04 22243-GB
Equipment and optional
Permanent magnet
alternator
Genera-
tion
+
-
~
°C: temperature Celsius grades
A: Ampere
B: pretrol
C.A.(c.a.): alternating current
C.C.(c.c.): direct current
cc: cm³ (volume)
CE: European norm conformity
CF: special for pipe welding
D: GFI
F: Fuse
g/kwh: grams/kilowatt hour (engine consumption)
GMP: permanent magnet alternator
Hz: frequency
I: single-phase auxiliary generation (symbol 1~)
IP: protection grads for electric devices against acess to
dangerous parts according to the IEC 529 norm (Internal
Protection)
kg: kilogram (mass)
K: welding cables set
kVA: kilovolt ampere
kW: kilowatt (engine power)
kWh: kilowatt hour (energy)
Lwa: maximum acoustic (power level) according to the
regulations in force
mm: millimeter (length) (measure)
S: symbol of EN 60974-1
T: thermic switch
V: Volt
PAR
600
Single-phase
1 ~
Engine
Welding
control
Optionals
Conformity
CE
EEC
Sound power
conformity
EN 60974-1
conformity
Various
news
InformationUsers'
manual
Air
cooling
Socket
230/110/48V EEC
Welding cur-
rent electr.
regulation
Gasoline
engine
Manual
recoil
Arc
control
Fuse
Welding with
covered
electrode
Socket
230V Schuko
Ground con-
nection point
Engine shut
down (oil)
A.C.
Plus MinusD.C.
Options on
request
Standard
equipment
Maintenance
Time
Central
lifting eye
Welding
cables
Various
