Parallel engine driven welder MAGIC WELD
M
34.3
© MOSA 1.1-03/05
How to put two machines in parallel:
from the front panels of the machines connect the two positives welding sockets(+) between
themselves and the two negative welding sockets bethween themselves.
To effect the connection ask for the accessory K2X150.
ATTENTION: use fit cables and tight at the connection point.
How to proceed:
-start the machine putting the two welding handles (T) in the wanted position (half of the total
current);
-put in parallel with the right cables;
-proceed with welding.
21/05/04 22243-GB
