6
If you ignore these Warnings or fail to inspect or maintain your wheel-
chair as directed in the manual, you may fall, tip over or lose control
of the wheelchair and seriously injure yourself or others or damage
the wheelchair
4.1.6 Note to dealers & qualified technicians
Read this manual before servicing, repairing, operating
or adjusting the wheelchair. If you have any questions or
difficulties understanding the following instructions, please
contact a qualified technician; you may also wish to contact a
Motion Composites technician by phone or email (see contact
information on previous page).
4.2 Symbols
The following symbols are used throughout this manual. Please
familiarize yourself with their meaning.
The warning sign indicates important information to
prevent injuries and property damage.
Useful information for the user
Initial setup of your PLATINE wheelchair must be done
by a qualified technician.
The latest version of this manual can be found on our
website at motioncomposites.com
Regular maintenance of your PLATINE will extend the
life of the wheelchair. Take your wheelchair to a
qualified technician every year for inspection and
servicing.
Do not use air or electric tool, tightening should be
done manually.
5. Tutorial
To find the latest tutorial or information or contact team at:
http://www.motioncomposites.com/en/team/
6. Technical Specifications
6.1 Structure
Frame Folding with Aluminum
Hydroformed cross brace
Material Material 6061 & 7000 series
aluminum alloy
Weight 16 lb (7.25 kg)
(w/o rear wheels & footrest)
Weight capacity 265 lb (120 kg)
Kit HD: 350 lb (159 kg)
6.2 Dimensions
Width 14’’ to 22’
(36.5 cm to 56.8 cm)
Depth 15’’ to 20’’
(38.1 cm to 50.8 cm)
Front seat-to-floor height
Platine 1 13 ¾” (34,9 cm) to 21 ¾” (55,2 cm)
Platine 2 12 ½” (31,75 cm) to 20 ½” (52,1 cm)
Rear seat-to-floor height
Platine 1 13 ¾” (34,9 cm) to 21 ¼” (53,9 cm)
Platine 2 12 ½” (31,7 cm) to 20” (50,8 cm)
6.3 Adjustability
Upholstery Tension adjustable or slide-on
Back height 16” (40.6 cm) or 21” (53.3 cm)
Adjustable angle from 85° to 110°
Footrest Swing in / Swing out
Camber 0°, 3°, 6°
Centre of gravity from 1 ¼” (3.2 cm)
to 2 ¼” (6.7 cm)
+ amputee axle plate option
6.4 Back Upholstery
All Upholstery are made with waterproof material that can be
cleaned.
Seams are not waterproof.
The adjustable tension back upholstery is made of waterproof
material.
Air-Knit or Synthetic Suede, found on slip-on or semi-tension
adjustable back upholstery, can absorb moisture.
