REMOVI
NG AND
REF
I TT
I NG THE
CRANKGEAR
REPLAC
I
NG
CRANKGEAR
BUSH I NGS
CONT'D,
REFITTING
THE
CRANKGEAR:
Reverse
the removal
procedure.
Take
care
in
positioning
the
"master"
link in the
correct
way
(see
page
48).
REPLACING
CRANKGEAR
BUSHINGS:
Remove
the driven
pulley (refer
to
page
47
).
Remove
the
crankgear
(see
preceeding
page).
Drive
the bushing
out Li,
usjrrq a steel
drift
punch
(tZmm) (fjg.
3).
Drive
the remaining
bushing
out with
the
20mm
steel tube.
Fit
new bushings
by
usjns
Tool
No. 100009
(fiq.
4).
Insert
the
crank
axle in
the
bushings.
The
axle
should
turr
free'ly
without
play
(if
necessary
use a
16mm
reamer
on the
bushjnqs).
-
Fit
the
crankgear
and
the
pulley
(see
above and
page
48
).
