Page 4
Unfolding your Trolley
1. Lift the trolley using the carry handle (located within the lower bag support)
and pull the front wheel up (g. 1) and towards you until fully extended
2. Place the trolley on the oor with all three wheels touching the ground.
You may want to hold the handle to stop it tipping backwards
3. Pull the locking lever upwards to release the folding lock (g. 2)
4. Place one hand on the carry handle and use the locking lever to pull the
frame upwards (g. 3) until it is fully extended (g. 4) and the central spring
is no longer visible (g. 5)
5. Lift the handle to the desired height and resecure the lever to lock (g. 6)
Adjusting the Handle Height
To adjust the handle height, release the locking lever and move the handle
into the desired position (g. 6). Resecure the lever once you have selected the
required handle height.
Unfolding your Trolley / Adjusting the Handle Height
Fig 4Fig 3
Fig 6Fig 5
Fig 1
Fig 2
