Beginners Referenze DX100 6
MOVC Function Moves to a taught point with circular interpolation type.
Additional
Item
Position data,
Base axis position data,
Station axis position data
These data do not
appear on the
screen.
V=<play speed>,
VR=<play speed of the posture>,
VE=<play speed of external axis>
Same as MOVL.
PL=<position level> PL:0 to 8
NWAIT
ACC=(acceleration adjustment ratio) ACC: 20 to 100%
DEC=(deceleration adjustment ratio) DEC: 20 to 100%
Example MOVC V=138 PL=0 NWAIT
MOVS Function Moves to a taught point with spline interpolation type.
Additional
Item
Position data,
Base axis position data,
Station axis position data
These data do not
appear on the
screen.
V=<play speed>,
VR=<play speed of the posture>,
VE=<play speed of external axis>
Same as MOVL.
PL=<position level> PL:0 to 8
NWAIT
ACC=(acceleration adjustment ratio) ACC: 20 to 100%
DEC=(deceleration adjustment ratio) DEC: 20 to 100%
Example MOVS V=120 PL=0
IMOV Function Moves the specified increment from the current position with linear
interpolation type.
Additional
Item
P<variable number>,
BP<variable number>,
EX<variable number>
V=<play speed>,
VR=<play speed of the posture>,
VE=<play speed of external axis>
Same as MOVL.
PL=<position level> PL:0 to 8
NWAIT
BF,RF,TF,UF# (<user coordinate number>) BF:
base coordinates
RF:
robot coordinates
TF:
tool coordinates
UF:
user coordinates
UNTIL statement
ACC=(acceleration adjustment ratio) ACC: 20 to 100%
DEC=(deceleration adjustment ratio) DEC: 20 to 100%
Example IMOV P000 V=138 PL=1 RF

Motoman DX100 Specifications

General

Model	DX100
Protection Class	IP20
Manufacturer	Yaskawa
Interface	Ethernet
Mounting	Floor
Control Method	Digital servo control
Programming Method	Teach pendant
Humidity	20% to 80% RH (non-condensing)
