VZ-28
Series Spare parts
No.
Part No.
Part name
1
F001A28M601
VZ-28 Housing
2
F001A28M015
Crab Eye Nut
3
F001A28M075
Channel Selector Knob
4
F001A28M044
ON/OFF/Volume Knob
5
F001A28M068
Rear Cover
6
F001A28M023
Seal Contact
7
F001A28M046
Seal Chassis
8
F001A28M052
Aluminum Chassis
9
F001A28E001
PCBA(400-470MHz)
9-1
F001A28M009
Channel Potentiometer
9-2
F001A28M014
Volume Potentiometer
10
F001A28E005
PCBA(136-174MHz)
11
F001A28E007
PCBA(350-390MHz)
12
F001A28M064
Audio Connector Jacks(two)
13
F001A28E022
PA(Power Amplifier)
14
F001A28E081
Microphone
15
F001A28E011
Speaker
16
F001A28M012
Antenna (Antenna Connector)
17
F001A28M031
Battery contact
18
F001A28M099
LCD
19
F001A28E017
Keyboard
13
