To remove the battery, lift up the latch which is

at the bottom of the radio, then slide the battery

out from the radio.

Note

When removing the battery, ensure that the

radio is turned off.

Attaching the Antenna

Ensure the radio is turned off before attaching the

antenna.

1 Set the antenna in its receptacle.

2 Turn the antenna clockwise to attach to the radio.
