8
Getting started
Connecting the base
1. Plug the telephone line cord into the socket marked on the underside of
the base.
2. Plug the power adaptor into the socket marked
on the underside of the
base and plug the other end into the mains power wall socket. Switch on the
mains power.
Installing and charging the handset
1. Remove the battery cover from the back of the handset by placing your finger
in the groove at the bottom of the handset and lifting the cover up to release,
then insert the 300mAh Ni-MH battery pack supplied.
Use your
finger to unclip
the cover and
lift up.
Insert your
finger
here.
Lower the
cover and
clip into
place.
Position the
battery
cover as
shown.
To close: To open:
1
2
