Motorola CDM Series Service Manual

Chapter 1: 3-4 Recommended Test Equipment
6881091C63-A
S1339_ RF millivoltmeter 100mV to 3 VRF.
10kHz to 1.2GHz
RF level measurements
S1348_ Programmable DC power
supply
0–20V DC, 0–5 amps, current limited Bench supply for 7.5V
DC
Table 3-3 Wattmeter Plug-In Elements
Power 25-60MHz 50-125MHz 100-250MHx 200-500MHz 400-1000MHz
5W — 01-80305F21 01-80305F29 01-80305F38 01-80305F46
10W — 01-80305F22 01-80305F30 01-80305F39 01-80305F47
25W 01-80305F15 01-80305F23 01-80305F31 01-80305F40 01-80305F48
50W 01-80305F16 01-80305F24 01-80305F32 01-80305F41 01-80305F49
100W 01-80305F17 01-80305F25 01-80305F33 01-80305F42 01-80305F50
250W 01-80305F18 01-80305F26 01-80305F34 01-80305F43 01-80305F51
500W 01-80305F19 01-80305F27 01-80305F35 01-80305F44 01-80305F52
1000W 01-80305F20 01-80305F28 01-80305F36 01-80305F45 01-80305F53
Motorola Part
Number
Description Characteristics Application
