Motorola CM160

4-20 UHF1 25-40W PCB 8486577Z02 / Schematics
C1090 NOT PLACED GCAM DUMMY PART NUM-
BER
C1091 NOT PLACED GCAM DUMMY PART NUM-
BER
C1092 NOT PLACED GCAM DUMMY PART NUM-
BER
C1093 NOT PLACED GCAM DUMMY PART NUM-
BER
C1094 2113740F53 CAP CHIP REEL CL1 +/-30
120
C1095 2113740F41 CAP CHIP REEL CL1 +/-30
39
C1096 2113740F41 CAP CHIP REEL CL1 +/-30
39
C1097 2113740F41 CAP CHIP REEL CL1 +/-30
39
C1098 2113740F53 CAP CHIP REEL CL1 +/-30
120
C1099 2113740F53 CAP CHIP REEL CL1 +/-30
120
C110 2113740F53 CAP CHIP REEL CL1 +/-30
120
C1100 2113740F53 CAP CHIP REEL CL1 +/-30
120
C1101 2113740F34 CAP CHIP REEL CL1 +/-30
20
C1102 2113740F34 CAP CHIP REEL CL1 +/-30
20
C1103 2113741A57 CAP CHIP 33K +-5%
(2160521A31
C1104 2113743E10 CAP CHIP .033 UF 10% X 7R
C1106 2113740F41 CAP CHIP REEL CL1 +/-30
39
C1107 2113740F53 CAP CHIP REEL CL1 +/-30
120
C1108 2113740F29 CAP CHIP REEL CL1 +/-30
12
C1109 2113740F41 CAP CHIP REEL CL1 +/-30
39
Circuit
Ref.
Motorola
Part No.
Description
C1110 2113740F41 CAP CHIP REEL CL1 +/-30
39
C1111 211 3740F 41 CAP CHIP REEL CL1 +/-30
39
C1112 2113740F41 CAP CHIP REEL CL1 +/-30
39
C1113 2113740F53 CAP CHIP REEL CL1 +/-30
120
C1114 2113740F41 CAP CHIP REEL CL1 +/-30
39
C1115 2113740F41 CAP CHIP REEL CL1 +/-30
39
C1116 2113740F41 CAP CHIP REEL CL1 +/-30
39
C1117 2113740F38 CAP CHIP REEL CL1 +/-30
30
C1118 2113740F23 CAP CHIP REEL CL1 +/-30
6.8
C1119 2113740F53 CAP CHIP REEL CL1 +/-30
120
C1121 2113740F07 CAP CHIP REEL CL1 +/-30
1.5
C1122 2113740F41 CAP CHIP REEL CL1 +/-30
39
C1123 2113740F41 CAP CHIP REEL CL1 +/-30
39
C1124 2113740F41 CAP CHIP REEL CL1 +/-30
39
C1125 2113740F41 CAP CHIP REEL CL1 +/-30
39
C1126 2113740F53 CAP CHIP REEL CL1 +/-30
120
C1127 2360567A03 CAP TANTALUM
C1128 2113740F41 CAP CHIP REEL CL1 +/-30
39
C1129 2113740F41 CAP CHIP REEL CL1 +/-30
39
C1130 2113740F41 CAP CHIP REEL CL1 +/-30
39
Circuit
Ref.
Motorola
Part No.
Description
C1131 NOT PLACED GCAM DUMMY PART NUM-
BER
C1132 2113740F41 CAP CHIP REEL CL1 +/-30
39
C1151 NOT PLACED GCAM DUMMY PART NUM-
BER
C1152 NOT PLACED GCAM DUMMY PART NUM-
BER
C1153 2113740F28 CAP CHIP REEL CL1 +/-30
11
C1154 2113740F34 CAP CHIP REEL CL1 +/-30
20
C1155 NOT PLACED GCAM DUMMY PART NUM-
BER
C1156 2113740A39 CAP CHIP REEL CL1 +/-30
27
C1157 2113740F69 CAP CHIP REEL CL1 +/-30
56
C1251 2113740A28 CAP CHIP REEL CL1 +/-30
9.1
C1252 2113740A59 CHIP CAPACITORS 150PF
+-30%
C1253 2113740A31 CAP CHIP REEL CL1 +/-30
12
C1254 2113740A28 CAP CHIP REEL CL1 +/-30
9.1
C1255 2113740A59 CHIP CAPACITORS 150PF
+-30%
C1256 2113740A31 CAP CHIP REEL CL1 +/-30
12
C1258 2113740A46 CAP CHIP REEL CL1 +/-30
47
C1260 2113741F49 CAP CHIP CL2 X7R REEL
10000
C1261 2113740F53 CAP CHIP REEL CL1 +/-30
120
C1263 2113741F25 CAP CHIP CL2 X7R REEL
1000
C1264 2113743K15 CHIP CAP, CER 0.1UF
Circuit
Ref.
Motorola
Part No.
Description
C1267 2113740A42 CAP CHIP REEL CL1 +/-30
36
C1268 NOT PLACED GCAM DUMMY PART NUM-
BER
C1269 2113740A42 CAP CHIP REEL CL1 +/-30
36
C1270 NOT PLACED GCAM DUMMY PART NUM-
BER
C1271 2113740F53 CAP CHIP REEL CL1 +/-30
120
C1272 2113743E10 CAP CHIP .033 UF 10% X 7R
C1273 2111078B44 CAP CHIP RF 120 5 NPO
100V
C1274 2111078B32 CAP CHIP RF 39 5 NPO
100V
C1275 2111078B20 CAP CHIP RF 18 5 NPO
100V
C1276 2111078B03 CAP CHIP RF 3.9.25 NPO
100V
C1277 2111078B11 CAP CHIP RF 8.2.5 NPO
100V
C1278 NOT PLACED GCAM DUMMY PART NUM-
BER
C1279 NOT PLACED GCAM DUMMY PART NUM-
BER
C1280 2111078B03 CAP CHIP RF 3.9.25 NPO
100V
C1281 2113740F53 CAP CHIP REEL CL1 +/-30
120
C1282 2113740F53 CAP CHIP REEL CL1 +/-30
120
C1283 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2000 2113743F18 CAP CHIP 2.2 UF 16V +80-
20%
C2001 2311049J11 CAPACITOR TANT 10%
4.7UF
C2002 2311049A72 CAP TANT CHIP 10.0UF 10%
10V
Circuit
Ref.
Motorola
Part No.
Description
