Motorola CM160

UHF1 25-40W PCB 8486577Z02 / Schematics 4-21
C2003 2113743K15 CHIP CAP, CER 0.1UF
C2004 2113743F18 CAP CHIP 2.2 UF 16V +80-
20%
C2005 2113743F18 CAP CHIP 2.2 UF 16V +80-
20%
C2006 2113743F18 CAP CHIP 2.2 UF 16V +80-
20%
C2007 2113743E20 CAP CHIP. 10 UF 10%
C2008 2113743E20 CAP CHIP. 10 UF 10%
C2009 2113743E20 CAP CHIP. 10 UF 10%
C2010 2113743E20 CAP CHIP. 10 UF 10%
C2011 2113743E20 CAP CHIP. 10 UF 10%
C2012 NOT PLACED GCAM DUMMY PART NUM-
BER
C2013 2113743E20 CAP CHIP. 10 UF 10%
C2014 2113743E20 CAP CHIP. 10 UF 10%
C2015 2113743E20 CAP CHIP. 10 UF 10%
C2016 2113743E20 CAP CHIP. 10 UF 10%
C2017 2113743E20 CAP CHIP. 10 UF 10%
C2018 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2019 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2020 2113743E20 CAP CHIP. 10 UF 10%
C2021 2113741F25 CAP CHIP CL2 X7R REEL
1000
C2022 2113741F49 CAP CHIP CL2 X7R REEL
10000
C2023 2113741F49 CAP CHIP CL2 X7R REEL
10000
C2024 2113741F49 CAP CHIP CL2 X7R REEL
10000
C2025 2113741F49 CAP CHIP CL2 X7R REEL
10000
C2026 2113741F49 CAP CHIP CL2 X7R REEL
10000
Circuit
Ref.
Motorola
Part No.
Description
C2027 2113741F49 CAP CHIP CL2 X7R REEL
10000
C2028 2113741F33 CAP CHIP CL2 X7R REEL
2200
C2029 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2030 2113741F39 CAP CHIP CL2 XTR REEL
3900
C2031 NOT PLACED GCAM DUMMY PART NUM-
BER
C2032 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2033 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2034 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2035 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2036 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2037 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2038 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2039 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2040 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2041 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2042 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2043 2113740L14 CAP CER CHIP 6.8PF +-
0.1PF
C2044 NOT PLACED GCAM DUMMY PART NUM-
BER
C2045 2113740F53 CAP CHIP REEL CL1 +/-30
120
Circuit
Ref.
Motorola
Part No.
Description
C2046 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2047 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2048 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2049 NOT PLACED GCAM DUMMY PART NUM-
BER
C2050 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2051 2113740F59 CAP CHIP REEL CL1 +/-30
220
C2052 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2053 NOT PLACED GCAM DUMMY PART NUM-
BER
C2054 2113740L37 CAP 62.0 PF 50V 2.0%
C2055 2113740F35 CAP CHIP REEL CL1 +/-30
22
C2056 2113740F20 CAP CHIP REEL CL1 +/-30
5.1
C2057 2113740F20 CAP CHIP REEL CL1 +/-30
5.1
C2058 2113740F20 CAP CHIP REEL CL1 +/-30
5.1
C2059 2113740F20 CAP CHIP REEL CL1 +/-30
5.1
C2060 2113740F31 CAP CHIP REEL CL1 +/-30
15
C2061 2113740A31 CAP CHIP REEL CL1 +/-30
12
C2062 2113740F29 CAP CHIP REEL CL1 +/-30
12
C2063 2113740L18 CAP CER CHIP10.0 PF+-
.25PF
C2064 2113740A28 CAP CHIP REEL CL1 +/-30
9.1
C2065 2113740F53 CAP CHIP REEL CL1 +/-30
120
Circuit
Ref.
Motorola
Part No.
Description
C2066 2113740L03 CAP CER CHIP 2.4PF +-
0.1PF
C2067 2113740F20 CAP CHIP REEL CL1 +/-30
5.1
C2068 2113740F20 CAP CHIP REEL CL1 +/-30
5.1
C2069 2113740F05 CAP CHIP REEL CL1 +/-30
1.2
C2070 2113740L13 CAP CER CHIP 6.2 PF+-
0.1PF
C2071 2113740L13 CAP CER CHIP 6.2 PF+-
0.1PF
C2072 2113740L04 CAP CER CHIP 2.7 PF +-
0.1PF
C2073 2113740F03 CAP CHIP REEL CL1 +/-30
1.0
C2074 2109720D14 CAP CER CHIP LOW DIST
0.1UF
C2076 NOT PLACED GCAM DUMMY PART NUM-
BER
C2078 0886629Z02 CAP,FILM,1UF,+10%,--
10%,63V-D
C2129 2113740F53 CAP CHIP REEL CL1 +/-30
120
C2198 2113741F25 CAP CHIP CL2 X7R REEL
1000
C300 NOT PLACED GCAM DUMMY PART NUM-
BER
C301 2311049A57 CAP TANT CHIP A/P 10UF
10% 16
C302 2113740F54 CAP CHIP REEL CL1+/-30
130
C303 2113743K15 CHIP CAP, CER 0.1UF
C304 2113743E20 CAP CHIP. 10 UF 10%
C305 2113743E20 CAP CHIP. 10 UF 10%
C306 2113743E20 CAP CHIP. 10 UF 10%
C307 2113743E20 CAP CHIP. 10 UF 10%
C308 2113743E20 CAP CHIP. 10 UF 10%
Circuit
Ref.
Motorola
Part No.
Description
