Motorola CM360 Service Information

4-20 VHF1 1-25W PCB 8486672Z01 / Schematics
C1128 2113740F59 CAP CHIP REEL CL1 +/-30 220
C1129 2113740F59 CAP CHIP REEL CL1 +/-30 220
C1130 2113740F59 CAP CHIP REEL CL1 +/-30 220
C1131 NOT PLACED GCAM DUMMY PART NUMBER
C2000 2113743F18 CAP CHIP 2.2 UF 16V +80-20%
C2001 2311049J11 CAPACITOR TANT 10% 4.7UF
C2002 2311049A56 CAP TAN CHIP A/P 4.7 20 10
C2003 2113743K15 CER CHIP CAP .100UF
C2004 2113743F18 CAP CHIP 2.2 UF 16V +80-20%
C2005 2113743F18 CAP CHIP 2.2 UF 16V +80-20%
C2006 2113743F18 CAP CHIP 2.2 UF 16V +80-20%
C2007 2113743E20 CAP CHIP. 10 UF 10%
C2008 2113743E20 CAP CHIP. 10 UF 10%
C2009 2113743E20 CAP CHIP. 10 UF 10%
C2010 2113743E20 CAP CHIP. 10 UF 10%
C2011 2113743E20 CAP CHIP. 10 UF 10%
C2012 NOT PLACED GCAM DUMMY PART NUMBER
C2013 2113743E20 CAP CHIP. 10 UF 10%
C2014 2113743E20 CAP CHIP. 10 UF 10%
C2015 2113743E20 CAP CHIP. 10 UF 10%
C2016 2113743E20 CAP CHIP. 10 UF 10%
C2017 2113743E20 CAP CHIP. 10 UF 10%
C2018 2113743E20 CAP CHIP. 10 UF 10%
C2019 2113743E20 CAP CHIP. 10 UF 10%
C2020 2113743E20 CAP CHIP. 10 UF 10%
C2021 2113741F49 CAP CHIP CL2 X7R REEL 10000
C2022 2113741F49 CAP CHIP CL2 X7R REEL 10000
C2023 2113741F49 CAP CHIP CL2 X7R REEL 10000
C2024 2113741F49 CAP CHIP CL2 X7R REEL 10000
C2025 2113741F49 CAP CHIP CL2 X7R REEL 10000
C2026 2113741F49 CAP CHIP CL2 X7R REEL 10000
C2027 2113741F49 CAP CHIP CL2 X7R REEL 10000
Circuit
Ref.
Motorola
Part No.
Description
C2028 2113741F33 CAP CHIP CL2 X7R REEL 2200
C2029 2113741F25 CAP CHIP CL2 X7R REEL 1000
C2030 2113741F39 CAP CHIP CL2 XTR REEL 3900
C2031 NOT PLACED GCAM DUMMY PART NUMBER
C2032 2113741F25 CAP CHIP CL2 X7R REEL 1000
C2033 2113741F25 CAP CHIP CL2 X7R REEL 1000
C2034 2113741F25 CAP CHIP CL2 X7R REEL 1000
C2035 2113741F25 CAP CHIP CL2 X7R REEL 1000
C2036 2113741F25 CAP CHIP CL2 X7R REEL 1000
C2037 2113741F25 CAP CHIP CL2 X7R REEL 1000
C2038 2113741F25 CAP CHIP CL2 X7R REEL 1000
C2039 2113741F25 CAP CHIP CL2 X7R REEL 1000
C2040 2113741F25 CAP CHIP CL2 X7R REEL 1000
C2041 2113741F25 CAP CHIP CL2 X7R REEL 1000
C2042 2113741F25 CAP CHIP CL2 X7R REEL 1000
C2043 2113740L14 CAP CER CHIP 6.8PF +-0.1PF
C2044 2113740L06 CAP CER CHIP 3.3 PF+/-0.1PF
C2045 2113740F67 CAP CHIP CL1 +/-30 470 5%
C2046 2113740F67 CAP CHIP CL1 +/-30 470 5%
C2047 2113740F67 CAP CHIP CL1 +/-30 470 5%
C2048 2113740F67 CAP CHIP CL1 +/-30 470 5%
C2049 NOT PLACED GCAM DUMMY PART NUMBER
C2050 2113740F67 CAP CHIP CL1 +/-30 470 5%
C2051 2113740F59 CAP CHIP REEL CL1 +/-30 220
C2052 2113740F67 CAP CHIP CL1 +/-30 470 5%
C2053 NOT PLACED GCAM DUMMY PART NUMBER
C2054 2113740L37 CAP 62.0 PF 50V 2.0%
C2055 2113740F35 CAP CHIP REEL CL1 +/-30 22
C2056 2113740F33 CAP CHIP REEL CL1 +/-30 18
C2057 2113740F33 CAP CHIP REEL CL1 +/-30 18
C2058 2113740F33 CAP CHIP REEL CL1 +/-30 18
C2059 2113740F33 CAP CHIP REEL CL1 +/-30 18
Circuit
Ref.
Motorola
Part No.
Description
C2060 2113740F31 CAP CHIP REEL CL1 +/-30 15
C2061 2113740F29 CAP CHIP REEL CL1 +/-30 12
C2062 2113740F29 CAP CHIP REEL CL1 +/-30 12
C2063 2113740L22 CAP 15.0 PF 50V 2.0 %
C2064 2113740F32 CAP CHIP REEL CL1 +/-30 16
C2065 2113740F27 CAP CHIP REEL CL1 +/-30 10
C2066 2113740L16 CAP CER CHIP 8.2 PF+-0.1PF
C2067 2113740F32 CAP CHIP REEL CL1+/-30 16
C2068 2113740F32 CAP CHIP REEL CL1 +/-30 16
C2069 2113740L12 CAP CER CHIP 5.6PF +-0.1PF
C2070 2113740F41 CAP CHIP REEL CL1 +/-30 39
C2071 2113740F41 CAP CHIP REEL CL1 +/-30 39
C2072 2113740L04 CAP CER CHIP 2.7 PF +-0.1PF
C2073 2113740F03 CAP CHIP REEL CL1 +/-30 1.0
C2074 2109720D14 CAP CER CHIP LOW DIST
0.1UF
C2075 2109720D14 CAP CER CHIP LOW DIST
0.1UF
C2076 NOT PLACED GCAM DUMMY PART NUMBER
C2077 2109720D14 CAP CER CHIP LOW DIST
0.1UF
C2078 2109720D14 CAP CER CHIP LOW DIST
0.1UF
C2079 2109720D14 CAP CER CHIP LOW DIST
0.1UF
C2080 2109720D14 CAP CER CHIP LOW DIST
0.1UF
C2081 2113740F67 CAP CHIP CL1 +/-30 470 5%
C300 2113740F43 CAP CHIP REEL CL1 +/-30 47
C301 2311049A57 CAP TANT CHIP A/P 10UF 10%
16V
C302 2113740F54 CAP CHIP REEL CL1+/-30 130
C303 2113743K15 CER CHIP CAP .100UF
C304 2113743E20 CAP CHIP. 10 UF 10%
C305 2113743E20 CAP CHIP. 10 UF 10%
Circuit
Ref.
Motorola
Part No.
Description
C306 2113743E20 CAP CHIP. 10 UF 10%
C307 2113743E20 CAP CHIP. 10 UF 10%
C308 2113743E20 CAP CHIP. 10 UF 10%
C309 2113743E20 CAP CHIP. 10 UF 10%
C310 2113743E20 CAP CHIP. 10 UF 10%
C311 2113743E20 CAP CHIP. 10 UF 10%
C312 2113743E20 CAP CHIP. 10 UF 10%
C313 2113743E20 CAP CHIP. 10 UF 10%
C314 2113743E20 CAP CHIP. 10 UF 10%
C315 2113743E20 CAP CHIP. 10 UF 10%
C316 2113743E20 CAP CHIP. 10 UF 10%
C317 2113743E20 CAP CHIP. 10 UF 10%
C318 2113743E20 CAP CHIP. 10 UF 10%
C319 2113743E20 CAP CHIP. 10 UF 10%
C320 2113743E20 CAP CHIP. 10 UF 10%
C321 2113741F49 CAP CHIP CL2 X7R REEL 10000
C322 2113741F41 CAP CHIP CL2 X7R REEL 4700
C323 2113741F25 CAP CHIP CL2 X7R REEL 1000
C324 2113741F25 CAP CHIP CL2 X7R REEL 1000
C325 2113741F25 CAP CHIP CL2 X7R REEL 1000
C326 2113741F25 CAP CHIP CL2 X7R REEL 1000
C327 2113741F25 CAP CHIP CL2 X7R REEL 1000
C328 2113740F67 CAP CHIP CL1 +/-30 470 5%
C329 2113740F67 CAP CHIP CL1 +/-30 470 5%
C330 2113740F67 CAP CHIP CL1 +/-30 470 5%
C331 2113740F67 CAP CHIP CL1 +/-30 470 5%
C332 2113741F13 CAP CHIP CL2 X7R REEL 330
C333 2113740F53 CAP 120 PF 50V 2.0 %
C334 2113740F52 CAP 110 PF 50V 2.0 %
C335 2113740L17 CAP CER CHIP 9.1 PF+-0.1PF
C336 2113740L14 CAP CER CHIP 6.8PF +-0.1PF
C337 2113740F55 CAP CHIP REEL CL1 +/-30 150
Circuit
Ref.
Motorola
Part No.
Description
