Motorola CM360 Service Information

VHF1 1-25W PCB 8486672Z01 / Schematics 4-21
C338 2113740F57 CAP CHIP REEL CL1 +/-30 180
C339 2113740F50 CAP CHIP REEL CL1 +/-30 91
C340 2113740F50 CAP CHIP REEL CL1 +/-30 91
C341 2113740F51 CAP CHIP REEL CL1 +/-30 100
C342 2113740F49 CAP CHIP REEL CL1 +/-30 82
C343 2113740F53 CAP CHIP REEL CL1 +/-30 120
C344 NOT PLACED GCAM DUMMY PART NUMBER
C345 NOT PLACED GCAM DUMMY PART NUMBER
C346 2113740F46 CAP CHIP REEL CL1+/-30 62
C347 2113740F45 CAP CHIP REEL CL1 +/-30 56
C348 2113740F41 CAP CHIP REEL CL1 +/-30 39
C349 NOT PLACED GCAM DUMMY PART NUMBER
C350 2113740F51 CAP CHIP REEL CL1 +/-30 44
C351 2113740F43 CAP CHIP REEL CL1 +/-30 47
C352 2113740F39 CAP CHIP REEL CL1 +/-30 33
C353 2113740F38 CAP CHIP REEL CL1 +/-30 30
C354 2113740F43 CAP CHIP REEL CL1 +/-30 47
C355 2113740F42 CAP CHIP REEL CL1 +/-30 43
C356 NOT PLACED GCAM DUMMY PART NUMBER
C357 2113740F35 CAP CHIP REEL CL1 +/-30 22
C359 NOT PLACED GCAM DUMMY PART NUMBER
C360 NOT PLACED GCAM DUMMY PART NUMBER
C361 2113740F33 CAP CHIP REEL CL1 +/-30 18
C362 2113740F33 CAP CHIP REEL CL1 +/-30 18
C363 NOT PLACED GCAM DUMMY PART NUMBER
C364 2113740F25 CAP CHIP REEL CL1+/-30 8.2
C365 2113740F34 CAP CHIP REEL CL1+/-30 20
C366 NOT PLACED GCAM DUMMY PART NUMBER
C367 NOT PLACED GCAM DUMMY PART NUMBER
C400 2113741F25 CAP CHIP CL2 X7R REEL 1000
C401 2113743K15 CER CHIP CAP .100UF
C402 2113743K15 CER CHIP CAP .100UF
Circuit
Ref.
Motorola
Part No.
Description
C403 2113743K15 CER CHIP CAP .100UF
C404 2113743K15 CER CHIP CAP .100UF
C405 2113743K15 CER CHIP CAP .100UF
C406 2113743K15 CER CHIP CAP .100UF
C407 2113743K15 CER CHIP CAP .100UF
C408 2113743K15 CER CHIP CAP .100UF
C410 2113743K15 CER CHIP CAP .100UF
C411 2113741F25 CAP CHIP CL2 X7R REEL 1000
C412 2113741F25 CAP CHIP CL2 X7R REEL 1000
C413 2113741F25 CAP CHIP CL2 X7R REEL 1000
C414 2113741F25 CAP CHIP CL2 X7R REEL 1000
C415 2113741F25 CAP CHIP CL2 X7R REEL 1000
C416 2113741F25 CAP CHIP CL2 X7R REEL 1000
C417 2113741F25 CAP CHIP CL2 X7R REEL 1000
C418 2113741F25 CAP CHIP CL2 X7R REEL 1000
C421 2113743E07 CER CHIP CAP .022UF
C422 2113741F25 CAP CHIP CL2 X7R REEL 1000
C423 2113743K15 CER CHIP CAP .100UF
C490 NOT PLACED GCAM DUMMY PART NUMBER
C5000 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5001 2389289U01 10UF 50V 20% ALUMINUM SMD
C5002 2311049A99 CAP TANT CHIP 47 UF 10V 20%
C5003 2311049A99 CAP TANT CHIP 47 UF 10V 20%
C5005 2360567A03 CAP TANTALUM
C5006 2311049A57 CAP TANT CHIP A/P 10UF 10%
16V
C5007 2311049A99 CAP TANT CHIP 47 UF 10V 20%
C5008 2311049A57 CAP TANT CHIP A/P 10UF 10%
16V
C5009 2311049A57 CAP TANT CHIP A/P 10UF 10%
16V
C5010 2311049A57 CAP TANT CHIP A/P 10UF 10%
16V
Circuit
Ref.
Motorola
Part No.
Description
C5011 2311049A57 CAP TANT CHIP A/P 10UF 10%
16V
C5012 2311049A56 CAP TAN CHIP A/P 4.7 20 10
C5013 2113928P04 CAP CER CHIP 1.0UF 20% 6.3V
C5014 NOT PLACED GCAM DUMMY PART NUMBER
C5015 2113743K15 CER CHIP CAP .100UF
C5016 2113743K15 CER CHIP CAP .100UF
C5017 2113743K15 CER CHIP CAP .100UF
C5018 2113743K15 CER CHIP CAP .100UF
C5019 2113743K15 CER CHIP CAP .100UF
C5020 2113743K15 CER CHIP CAP .100UF
C5021 2113741M69 CAP CHIP CLS2 100000 PF 20V
10
C5022 2113743K15 CER CHIP CAP .100UF
C5023 2113743K15 CER CHIP CAP .100UF
C5024 2113743K15 CER CHIP CAP .100UF
C5025 2113743K15 CER CHIP CAP .100UF
C5026 2113743K15 CER CHIP CAP .100UF
C5027 2113743K15 CER CHIP CAP .100UF
C5028 2113743K15 CER CHIP CAP .100UF
C5029 2113743K15 CER CHIP CAP .100UF
C5030 2113743K15 CER CHIP CAP .100UF
C5031 2113743K15 CER CHIP CAP .100UF
C5032 2113743K15 CER CHIP CAP .100UF
C5033 2113743K15 CER CHIP CAP .100UF
C5034 2113743K15 CER CHIP CAP .100UF
C5035 2113743K15 CER CHIP CAP .100UF
C5036 2113743K15 CER CHIP CAP .100UF
C5037 2113743K15 CER CHIP CAP .100UF
C5038 2113743K15 CER CHIP CAP .100UF
C5039 NOT PLACED GCAM DUMMY PART NUMBER
C5040 NOT PLACED GCAM DUMMY PART NUMBER
C5041 2113743F18 CAP CHIP 2.2 UF 16V +80-20%
Circuit
Ref.
Motorola
Part No.
Description
C5042 2113743F16 CAP CHIP 1.0UF 16V+80-20%
C5043 2113743F16 CAP CHIP 1.0UF 16V+80-20%
C5044 2113928C04 CAP CER CHIP 4.7UF
6.3V10%0805
C5045 2113743F16 CAP CHIP 1.0UF 16V+80-20%
C5046 2113743E20 CAP CHIP. 10 UF 10%
C5047 2113743E20 CAP CHIP. 10 UF 10%
C5048 2113743E20 CAP CHIP. 10 UF 10%
C5049 2113743E20 CAP CHIP. 10 UF 10%
C5050 2113743E20 CAP CHIP. 10 UF 10%
C5051 2113743E20 CAP CHIP. 10 UF 10%
(CM160/CM360 only)
C5052 2113743E20 CAP CHIP. 10 UF 10%
C5053 2113743E20 CAP CHIP. 10 UF 10%
(CM160/CM360 only)
C5054 2113743E20 CAP CHIP. 10 UF 10%
(CM160/CM360 only)
C5055 2113928C04 CAP CER CHIP 4.7UF
6.3V10%0805
C5056 2113928C04 CAP CER CHIP 4.7UF
6.3V10%0805
C5057 2113928C04 CAP CER CHIP 4.7UF
6.3V10%0805
C5058 NOT PLACED GCAM DUMMY PART NUMBER
C5059 2113743E07 CER CHIP CAP .022UF
C5060 2113741M69 CAP CHIP CLS2 100000 PF 20V
10
C5061 2113741M69 CAP CHIP CLS2 100000 PF 20V
10
C5062 2113741M69 CAP CHIP CLS2 100000 PF 20V
10
C5063 2113741M69 CAP CHIP CLS2 100000 PF 20V
10
C5064 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5065 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5066 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5067 2113741F25 CAP CHIP CL2 X7R REEL 1000
Circuit
Ref.
Motorola
Part No.
Description
