Motorola CM360 Service Information

4-22 VHF1 1-25W PCB 8486672Z01 / Schematics
C5068 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5069 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5070 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5071 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5072 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5073 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5074 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5075 NOT PLACED GCAM DUMMY PART NUMBER
C5076 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5077 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5078 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5079 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5080 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5081 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5082 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5083 2113740F51 CAP CHIP REEL CL1 +/-30 100
C5084 2113740F51 CAP CHIP REEL CL1 +/-30 100
C5085 2113741A53 CAP CHIP CL2 X7R REEL 22000
C5086 2113741A53 CAP CHIP CL2 X7R REEL 22000
C5087 2113740F53 CAP CHIP REEL CL1 +/-30 120
C5088 2113740F49 CAP CHIP REEL CL1 +/-30 82
C5089 2113740F49 CAP CHIP REEL CL1 +/-30 82
C5090 2113740F49 CAP CHIP REEL CL1 +/-30 82
C5091 2113740F49 CAP CHIP REEL CL1 +/-30 82
C5092 2113740F59 CAP CHIP REEL CL1 +/-30 220
C5094 2113740F59 CAP CHIP REEL CL1 +/-30 220
C5095 2113740F59 CAP CHIP REEL CL1 +/-30 220
C5096 2113740F59 CAP CHIP REEL CL1 +/-30 220
C5097 2113740F59 CAP CHIP REEL CL1 +/-30 220
C5098 2113740F59 CAP CHIP REEL CL1 +/-30 220
C5099 2113740F59 CAP CHIP REEL CL1 +/-30 220
C5100 2113740F59 CAP CHIP REEL CL1 +/-30 220
Circuit
Ref.
Motorola
Part No.
Description
C5101 2113741F25 CAP CHIP CL2 X7R REEL 1000
(CM160/CM360 only)
C5102 2113743E20 CAP CHIP. 10 UF 10%
(CM160/CM360 only)
C5103 2113743K15 CER CHIP CAP .100UF
(CM160/CM360 only)
C5104 NOT PLACED GCAM DUMMY PART NUMBER
C5110 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5111 2113741F25 CAP CHIP CL2 X7R REEL 1000
C5113 NOT PLACED GCAM DUMMY PART NUMBER
C5114 2113743F16 CAP CHIP 1.0UF 16V+80-20%
C5115 NOT PLACED GCAM DUMMY PART NUMBER
C5116 NOT PLACED GCAM DUMMY PART NUMBER
C5117 NOT PLACED GCAM DUMMY PART NUMBER
C5118 2113743E20 CAP CHIP. 10 UF 10%
C5119 2113743H14 CAP CHIP 10.0 UF 16V +80-20%
C5120 NOT PLACED GCAM DUMMY PART NUMBER
C5121 2113741F25 CAP CHIP CL2 X7R REEL 1000
C602 2113741F25 CAP CHIP CL2 X7R REEL 1000
C603 2113741F25 CAP CHIP CL2 X7R REEL 1000
C604 2113741F25 CAP CHIP CL2 X7R REEL 1000
C605 2113741F25 CAP CHIP CL2 X7R REEL 1000
C606 2113741F25 CAP CHIP CL2 X7R REEL 1000
C607 2113741F25 CAP CHIP CL2 X7R REEL 1000
C608 NOT PLACED GCAM DUMMY PART NUMBER
C609 NOT PLACED GCAM DUMMY PART NUMBER
C610 2113741F25 CAP CHIP CL2 X7R REEL 1000
C611 2113741F25 CAP CHIP CL2 X7R REEL 1000
C612 2113741F25 CAP CHIP CL2 X7R REEL 1000
C613 2113741F25 CAP CHIP CL2 X7R REEL 1000
C614 2113741F25 CAP CHIP CL2 X7R REEL 1000
C615 2113741F25 CAP CHIP CL2 X7R REEL 1000
C616 2113741F25 CAP CHIP CL2 X7R REEL 1000
Circuit
Ref.
Motorola
Part No.
Description
C617 2113741F25 CAP CHIP CL2 X7R REEL 1000
C618 2113741F25 CAP CHIP CL2 X7R REEL 1000
C619 NOT PLACED GCAM DUMMY PART NUMBER
C620 2113741F25 CAP CHIP CL2 X7R REEL 1000
C621 2113741F25 CAP CHIP CL2 X7R REEL 1000
C622 2113741F25 CAP CHIP CL2 X7R REEL 1000
C623 2113741F25 CAP CHIP CL2 X7R REEL 1000
C624 2113741F25 CAP CHIP CL2 X7R REEL 1000
C625 2113741F25 CAP CHIP CL2 X7R REEL 1000
C626 2113741F25 CAP CHIP CL2 X7R REEL 1000
C627 2113741F25 CAP CHIP CL2 X7R REEL 1000
C628 2113741F25 CAP CHIP CL2 X7R REEL 1000
C629 2113741F25 CAP CHIP CL2 X7R REEL 1000
C630 2113741F25 CAP CHIP CL2 X7R REEL 1000
C631 2113741F25 CAP CHIP CL2 X7R REEL 1000
C632 2113741F25 CAP CHIP CL2 X7R REEL 1000
C633 2113741F25 CAP CHIP CL2 X7R REEL 1000
C662 2113741F25 CAP CHIP CL2 X7R REEL 1000
C678 2113741M69 CAP CHIP CLS2 100000 PF 20V
10
CR300 4880154K03 SOT MMBD353 RH DIODE
DUAL SCHT
CR301 4880154K03 SOT MMBD353 RH DIODE
DUAL SCHT
D100 NOT PLACED GCAM DUMMY PART NUMBER
D101 4813833C02 DIODE DUAL 70V ‘5B’ COMM
CATH
D102 4813833C02 DIODE DUAL 70V ‘5B’ COMM
CATH
D103 4802482J02 PIN DIODE SMD
D104 4802482J02 PIN DIODE SMD
D105 4805218N57 DIODE DUAL
D106 4805218N57 DIODE DUAL
D107 4805218N57 DIODE DUAL
Circuit
Ref.
Motorola
Part No.
Description
D108 4805218N57 DIODE DUAL
D200 4802233J09 DIODE TRIPLE SOT25-RH
D201 4802233J09 DIODE TRIPLE SOT25-RH
D202 4862824C03 DIODE VARACTOR
D203 4805649Q13 DIODE VCTR ISV 228
D204 4805649Q13 DIODE VCTR ISV 228
D205 4862824C01 DIODE VARACTOR
D301 4802245J97 Band Switchind Diode, Rohm
DAN
D302 4802245J97 Band Switchind Diode, Rohm
DAN
D303 4802245J97 Band Switchind Diode, Rohm
DAN
D304 4802245J97 Band Switchind Diode, Rohm
DAN
D305 4880142L01 SOT MMBV109 RH
D400 4813833C07 DIODE DUAL 100V ‘5C’ SERIES
D401 4813833C02 DIODE DUAL 70V ‘5B’ COMM
CATH
D402 4809948D42 DIODE SCHOTTKY RB751V-40
D500 4813833C02 DIODE DUAL 70V ‘5B’ COMM
CATH
D501 NOT PLACED GCAM DUMMY PART NUMBER
D502 4813825A23 DIODE, DISCRETE SPECIALS
VAR&P
D511 4813833C02 DIODE DUAL 70V ‘5B’ COMM
CATH
D513 4813833C02 DIODE DUAL 70V ‘5B’ COMM
CATH
FL300 9180022M11 XTAL FILTER 44.85MHZ
FL301 9180468V06 SMD455KHZ 4 ELEMENT CER
FLTR
FL302 9180468V04 SMD455KHZ 4 ELEMENT CER
FLTR
FL303 9180469V03 SMD455KHZ 6 ELEMENT CER
FLTR
Circuit
Ref.
Motorola
Part No.
Description
