Motorola CM360 Service Information

VHF1 1-25W PCB 8486672Z01 / Schematics 4-23
FL304 9180469V06 SMD455KHZ 6 ELEMENT CER
FLTR
J11 2889309U01 MINI-UHF PCB R.A
J2 0989241U02 FLEX 20PIN 1MM TOP NON ZIF
J3 0986615Z01 CONN,ZIF,F,28CONT,,TIN,,,CBL
(CM160/CM360 only)
L100 2484657R01 INDUCTOR BEAD CHIP
L101 2462587T30 IND CHIP 1000NH 5% LOW PRO
L102 2462587T30 IND CHIP 1000NH 5% LOW PRO
L103 2462587T30 IND CHIP 1000NH 5% LOW PRO
L104 2462587T13 IND CHIP 68NH 5% LOW PRO
L105 2462587T13 IND CHIP 68NH 5% LOW PRO
L106 2460591A11 COIL AIR WOUND INDUC 7.66
L107 2460591A01 COIL AIR WOUND INDUC 4.22
L108 2462587X69 IND CHIP LO-PRO 1200 NH 5%
L109 NOT PLACED GCAM DUMMY PART NUMBER
L110 2462587N42 CHIP IND 12 NH 5%
L111 2485873L05 ENCAPSULATED AIR WOUND
48NH
L112 2485873L05 ENCAPSULATED AIR WOUND
48NH
L113 2485873L05 ENCAPSULATED AIR WOUND
48NH
L114 2485873L05 ENCAPSULATED AIR WOUND
48NH
L115 2485873L01 ENCAPSULATED AIR WOUND
COIL
L116 2485873L01 ENCAPSULATED AIR WOUND
COIL
L117 2484657R01 INDUCTOR BEAD CHIP
L118 2484657R01 INDUCTOR BEAD CHIP
L119 2484657R01 INDUCTOR BEAD CHIP
L120 2484657R01 INDUCTOR BEAD CHIP
L121 2484657R01 INDUCTOR BEAD CHIP
L122 2460591C23 COIL AIR WOUND INDUC 13.85
Circuit
Ref.
Motorola
Part No.
Description
L126 2462587X69 IND CHIP LO-PRO 1200 NH 5%
L200 2462587Q42 IND CHIP 390NH 10%
L201 2462587V44 IND CHIP 680 NH 10%
L202 2462587V44 IND CHIP 680 NH 10%
L203 2462587V44 IND CHIP 680 NH 10%
L204 2462587V44 IND CHIP 680 NH 10%
L205 2462587Q47 IND CHIP 1000 NH 10%
L206 2413923C05 IND CHIP 33 NH 2%
L207 2413923C07 IND CHIP 47 NH 2%
L208 2413926N24 IND CER CHIP 100.0 NH 5%
L209 2413926N24 IND CER CHIP 100.0 NH 5%
L210 2413926N24 IND CER CHIP 100.0 NH 5%
L211 2413926N24 IND CER CHIP 100.0 NH 5%
L212 2413926N24 IND CER CHIP 100.0 NH 5%
L213 2413926N24 IND CER CHIP 100.0 NH 5%
L214 2413926H20 IND CHIP 47.0 NH 5%
L215 2413926H20 IND CHIP 47.0 NH 5%
L216 2413926H20 IND CHIP 47.0 NH 5%
L217 2462587Q42 IND CHIP 390NH 10%
L300 2460591G24 COIL AIR WOUND INDUC 33.47
L301 2462587X69 IND CHIP LO-PRO 1200 NH 5%
L302 2462587X69 IND CHIP LO-PRO 1200 NH 5%
L303 2462587N69 CHIP IND 1200 NH 5%
L304 2483411T74 INDUCTOR CHIP SHIELDED
L305 2413926K31 IND CER CHIP 470.0 NH 5%
L306 2462587N55 CHIP IND 150 NH 5%
L307 2460591G24 COIL AIR WOUND INDUC 33.47
L308 2460591G24 COIL AIR WOUND INDUC 33.47
L309 2460591G24 COIL AIR WOUND INDUC 33.47
L310 2460591G24 COIL AIR WOUND INDUC 33.47
L311 2460591G24 COIL AIR WOUND INDUC 33.47
L312 2460591G24 COIL AIR WOUND INDUC 33.47
Circuit
Ref.
Motorola
Part No.
Description
L313 2460591G24 COIL AIR WOUND INDUC 33.47
L314 2460591G24 COIL AIR WOUND INDUC 33.47
L315 NOT PLACED GCAM DUMMY PART NUMBER
L500 2484657R01 INDUCTOR BEAD CHIP
L501 2484657R01 INDUCTOR BEAD CHIP
L502 2484657R01 INDUCTOR BEAD CHIP
M100 2686201B01 HEAT SPREADER WM
M105 7588823L03 PAD GROUND LCD
M106 7588823L03 PAD GROUND LCD
M107 7588823L03 PAD GROUND LCD
M108 7588823L04 PAD GROUND LCD
M109 7588823L04 PAD GROUND LCD
M110 7588823L04 PAD GROUND LCD
M111 3985994A01 CONTACT, PCB SPEAKER
M112 3985994A01 CONTACT, PCB SPEAKER
M113 3985994A01 CONTACT, PCB SPEAKER
M114 3985994A01 CONTACT, PCB SPEAKER
M9 0289511U01 NUTS
P1 2804503J01 CONNECTOR,ACCY 16 PIN
P2 NOT PLACED GCAM DUMMY PART NUMBER
PCB 8486672Z01 MARLIN VHF
Q100 4886163B01 LDMOS SMT 35W 520MH 12V
Q101 4813824A10 TSTR NPN 40V .2A GEN PURP
Q102 4813824A10 TSTR NPN 40V .2A GEN PURP
Q103 4813824A06 XSTR NPN 30V DARLINGTON
Q105 4813828A11 TSTR 520 MHZ 3W, 12.5V RF
LDMO
Q106 4805128M27 SOT TRANS
Q200 4802245J95 BJT, NPN TRANSISTOR
Q300 4809940E02 TSTR DIG NPN DTC114YE
Q301 4813824A17 XSTR PNP40V .2A GENPB=100-
300
Q302 4813824A10 TSTR NPN 40V .2A GEN PURP
Circuit
Ref.
Motorola
Part No.
Description
Q303 4802245J95 BJT, NPN TRANSISTOR
Q304 4809939C04 TSTR DUAL PNP/NPN UMC3
Q305 4802197J95 RF TRANSISTOR PBR941
Q306 4813824A17 XSTR PNP40V .2A GENPB=100-
300
Q400 4809940E02 TSTR DIG NPN DTC114YE
Q401 4880141L03 QSTR PNP SOT23 LO PROFILE
TAPE
Q403 4809940E02 TSTR DIG NPN DTC114YE
Q404 4809940E02 TSTR DIG NPN DTC114YE
Q405 4809940E02 TSTR DIG NPN DTC114YE
Q407 4809940E02 TSTR DIG NPN DTC114YE
Q408 4880048M01 TSTR NPN DIG 47K/47K
Q409 4880048M01 TSTR NPN DIG 47K/47K
Q410 4880048M01 TSTR NPN DIG 47K/47K
Q411 4880048M01 TSTR NPN DIG 47K/47K
Q412 4880048M01 TSTR NPN DIG 47K/47K
Q413 4809940E02 TSTR DIG NPN DTC114YE
Q414 4809940E02 TSTR DIG NPN DTC114YE
Q415 NOT PLACED GCAM DUMMY PART NUMBER
Q416 4809940E02 TSTR DIG NPN DTC114YE
Q417 4813824A10 TSTR NPN 40V .2A GEN PURP
Q500 4813824A10 TSTR NPN 40V .2A GEN PURP
Q501 4809940E02 TSTR DIG NPN DTC114YE
Q502 4809940E02 TSTR DIG NPN DTC114YE
Q503 4813824A10 TSTR NPN 40V .2A GEN PURP
Q504 4880048M01 TSTR NPN DIG 47K/47K
Q505 4813824A10 TSTR NPN 40V .2A GEN PURP
Q506 4813824A10 TSTR NPN 40V .2A GEN PURP
R101 NOT PLACED GCAM DUMMY PART NUMBER
R102 0683962T51 RES CHIP 120 5-1
R103 0683962T51 RES CHIP 120 5-1
R104 0683962T51 RES CHIP 120 5-1
Circuit
Ref.
Motorola
Part No.
Description
