8
English
GETTING STARTED
ACCESSORY INFORMATION
Attaching the Battery
Removing the Battery
1 Align the battery to the battery rails on the
back of the radio (approximately 1 cm from the
top of the radio.)
2 Press the battery firmly to the radio and slide
the battery upward until the latch snaps into
place.
3 Slide the battery latch, located on radio
bottom, into the lock position.
1 Turn off the radio if it is turned on.
2 Slide the battery latch into the unlock position.
Disengage by pushing downward and holding
the latch towards the front of the radio.
3 With the battery latch disengaged, slide the
battery down from the top of the radio
approximately 1 cm. Once the battery is free
from the battery rails, lift it directly away from
the radio.
Battery Latch
Locked Un-locked
