68P09301A65-A 1-3
FEB 2009
Desktop CPEi 775 User Guide 1
Back of the CPE
The back of the CPE unit contains the reset switch, AC Power Connector, Ethernet
connector, Ethernet LED, Line 1 and Line 2 telephone ports.
Figure 1-2: CPE Ports and Connections
Operating Information
Operating temperature for this unit is 0-40°C (32-104°F).
Table 1-2 Port Descriptions
Port Port Description
Ethernet Ethernet Port
Power AC Power Connector
Reset Hardware Reset Button (A paperclip is
recommended for accessing this button).
Phone Line 1 RJ-11 port for use with VoIP.
Phone Line 2 RJ-11 port for use with VoIP.
