Figure 2-2: DSR-4410MD Back Panel (Detailed)
AC 100-240V 50/60/Hz 60 W
TVPass® Card
ETHERNET
GIGE
10/100
RF IN 0
ASI IN ASI OUT 1
VIDEO OUT
PRIMARY AUDIO
L+ L-GNDR+ R-
SECONDARY AUDIO
GNDGNDQ+Q-
GND
CUE TONE
GNDGNDNO
ALARM
COMNC
RF IN 1
ASI OUT 2
TVPass® Card
ETHERNET
GIGE
10/100
Note: Additional audio and data
connectors may be ordered through
Phoenix Contact part numbers
1840447 / 1840528.
Note: GigE and 10/100 ports are
standard RJ45 Ethernet.
PRIMARY AUDIO
L+ L- GND R+ R-
SECONDARY AUDIO
GND GND Q+ Q-
GND
CUE TONE
GND GNDNO
ALARM
COM NC
