DSR-4410MD 1
1
Introducing the DSR-4410MD
The Motorola DSR-4410MD is a commercial Satellite Multiplex Decrypter designed for cable
operators and other commercial satellite operations. After properly setting up the DSR-4410MD,
it can receive authorization and control information from the satellite operator.
Note: Features denoted with will be available in a future firmware release.
Key Features
• A variable front-end allows the DSR-4410MD to be used in either full or partial transponder
mode.
• Manual tuning for either ASI input or two L-band inputs (ports).
• Demodulates DigiCipher
®
II signals.
• Operational modes include: DCII-MAN, DVB-MAN, or 8PSK.
• The user is able to select an input L-band frequency of 950 to 2150 MHz. The user can select
any of the following code rates: 5/11, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, and 7/8.
• The DSR-4410MD is capable of storing multiple Virtual Channel Tables (VCTs) and Network
Information Tables (NITs). One VCT may be selected at a time.
• Once the Satellite Multiplex Decrypter has acquired an MPEG signal, the user can select a
program from a list of programs as defined in the Program Association Table (PAT).
• One video output for OSD video. Outputs either 525-line NTSC/PAL M or 625-line PAL video
formats, automatically matching based on the programmer's input format. (No conversion is
done between 525-line and 625-line video.)
• VBI reinsertion on lines 10-22 supports data services such as North American Broadcast.
Teletext, SID/AMOL I and II, and Closed Caption.
Future
Release
