For best quality audio, please take care to ground the shield on both the Satellite Multiplex
Decrypter GND terminal and at the channel modulator end. Choose one of the following
audio configurations:
• For services transmitted in stereo and used in your plant as stereo, connect the Left
Audio Out terminals (L+ and L-) to the left audio inputs on the channel modulator, and
connect the Right Audio Out terminals (R+ and R-) to the right audio inputs on the
channel modulator.
• For services transmitted as a single mono, connect the Left Audio Out terminals
(L+ and L-) to the audio inputs on the channel modulator. Right Audio Out terminals
(R+ and R-) also contain the single mono. For more details about mono configurations,
see the note on page 24.
DSR-4410MDs are able to generate cue tones when commanded over the satellite link. If
these internally generated cue tones are used, connect the 600-ohm differential Cue Tone+
and Cue Tone- terminals on the DSR-4410MD to the device receiving the tones. The
cautions on cable and grounding noted in the audio instructions also apply to cue tones.
Plug the DSR-4410MD into a power source. Verify that the LCD screen is lit.
Proceed with the installation using the front panel menus.
