VHF Test Specifications 1-3
1.3 VHF Test Specifications
General
Transmitter
Receiver
Specifications subject to change without notice. All
electrical specifications and methods refer to EIA/TIA
603 standards.
VHF
Channel Capacity: 16 or 64 Channels
Power Supply: 7.5 Volts ±20%
Dimensions (HxWxD)
with Battery:
High Capacity Li-Ion
130.5mm x 62mm x 45mm
(5.12
" x 2.44" x 1.77")
Weight: with Battery:
High Capacity Li-Ion 397g (14.0 oz.)
Average Battery Life
@ (5-5-90* Duty
Cycle):
High Capacity Li-Ion
17 hr low power/
12 hr high power
Model Number: LAH65KDC9AA2_N,
LAH65KDH9AA4_N
Frequency Range: 146-174 MHz
Channel Spacing: 12.5/20/25 kHz
Temperature Range: -30° to 60°C
Frequency Stability: ±2.5 ppm
FCC ABZ99FT3045
*5% receive; 5% transmit; 90% standby.
VHF
RF Output
Li-Ion @ 7.5 V:
Low
1 W
High
5 W
Frequency: 146-174 MHz
Channel Spacing: 12.5/20/25 kHz
Spurious/Harmonics: -36 dBm < 1 GHz
-30 dBm > 1 GHz
FM Noise: -40 dB (12.5 kHz)
-45 dB (25 kHz)
Modulation Limitation: ±2.5 kHz @ 12.5 kHz/
±5 kHz @ 25 kHz
Audio Response:
(from 6 dB/oct.
Pre-emphasis, 300 to
3000 Hz)
+1 to -3 dB
Audio Distortion:
@ 1000 Hz, 60%
Rated Max. Dev.
3%
VHF
12.5 kHz
VHF
25kHz
Channel Spacing: 12.5/20/25 kHz
Sensitivity
12 dB EIA SINAD:
0.25 µV (typical)
Adjacent Channel
Selectivity:
-60 dB -70 dB
Intermodulation: -70 dB
Freq. Stability
(-30° C to +60° C):
0.00025%
Spur Rejection: -75 dB
Image and 1/2 I-F
Rejection:
-70 dB
Audio Output
@ <5% Distortion:
500 mW into 24
Ω
