7-14 Mechanical View and Parts List
Item
Motorola
Part
Number
Description
1 See Section 6 Antenna
2 3680530Z02 Knob, Frequency
3 1386440Z02 Escutcheon, Top; 16 Ch.
4 5886627Z01 Antenna Adaptor / Seal
5 1586391Z01 Housing, ELP+, Plain
6 3586621Z01 Felt, Speaker
7 3886489Z01 PTT, Rubber
8 4586439Z01 PTT, Plastic
9 5085738Z08 Speaker
10 4286620Z01 Retainer, Speaker
11 3586621Z02 Felt, Microphone
12 0780608V01 Boot, Microphone
13 5085880L01 Microphone
14 3286431Z02 Seal, Main O-ring
15 7586436Z01 Pad, PA Interface
16 2786389Z01 Chassis
17 3286435Z01 Seal, Battery Contact Block
18 0304726J05 Screws, Chassis; 4 Used
19 1586437Z01 Shroud, Audio Jack
20 5586445Z02 Latch Assembly
21 4105944K01 Spring, Latch; 2 Used
22 3886441Z01 Cap, Dust
23 3286432Z01 Seal, Control Shaft
24 3386443Z01 Label, Escutcheon Seal
25 6186446Z02 Lightpipe
26 3680529Z01 Knob, Volume
27 0386434Z01 Screw, Speaker Retainer
NON-REFERENCED ITEMS
3386625Z01 Nameplate, Motorola
Nameplate, EP450
