Motorola GP series Service Manual

1-4 MODEL CHART AND TECHNICAL SPECIFICATIONS
5.0 GP240/GP540/GP280/GP580 Model Chart
One user guide is selectable via option.
x = Indicates one of each is required.
* = Service replacement boards.
Professional GP200/GP500 Series (UHF)
Model Description
MDH25RDC9GC3 GP540 UHF 403-470 MHz 4W
MDH25RDH9GC6 GP580 UHF 403-470 MHz 4W
MDH25RDC9GB3 GP240 UHF 403-470 MHz 4W
MDH25RDH9GB6 GP280 UHF 403-470 MHz 4W
Item Description
X X *PMLE4192_ GP240/GP540 UHF Back Cover Kit
X X *PMLE4193_ GP280/GP580 UHF Back Cover Kit
X X *PMLN4216_ GP240/GP540 UHF Front Housing Kit
X X *PMLN4373_ GP280/GP580 UHF Front Housing Kit
X X 6864120B15 GP240/GP280 User Guide (English)
X X 6864120B16 GP240/GP280 User Guide (ENG, RUS, FR, TUR)
X X 6864120B17 GP240/GP280 User Guide (GER, SPA, POR, IT)
X X 6864120B18 GP240/GP280 User Guide (SWE,NL, DAN, FIN)
X X 6864120B19 GP240/GP280 User Guide (CZ, PL, HU, RO)
X X 6864120B20 GP540/GP580 User Guide (English)
X X 6864120B21 GP540/GP580 User Guide (ENG, RUS, FR, TUR)
X X 6864120B22 GP540/GP580 User Guide (GER, SPA, POR, IT)
X X 6864120B23 GP540/GP580 User Guide (SWE,NL, DAN, FIN)
X X 6864120B24 GP540/GP580 User Guide (CZ, PL, HU, RO)
XXXX NAE6483_ Antenna (403-433 MHz) Stubby
X X X X HNN9008_ Battery, NiMH Standard

Motorola GP series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Number of Channels	16
Channel Spacing	12.5 kHz / 25 kHz
Battery Life	8 hours (with standard battery)
Operating Voltage	7.5V DC
Ingress Protection	IP54
MIL-STD	810 C, D, E, F
