UHF PCB 8480587Z03 Schematics 4-29
UHF (403-470 MHz) Harmonic Filter
SHIELD
SH100
1
HF SHIELD
ANT_BIAS
RF_JACK
100pF
C101
C102
6.2pF
L101
19.61nH
10pF
C103
L102
19.61nH
19.61nH
L104
4.7pF
C106
6.2pF
C104
CR101
3.3pF
C107
20pF
C175
240
R170
240
R101
3
1
CR102
2
RX_IN
100pF
C108
390nH
L105
TX_OUT
ZMY0130486-O
ZMY0130486-O
