Motorola GP series Service Manual

UHF PCB 8480587Z03 Parts List 4-31
C424 2311049A59 10uF
C425 2113743M24 0.1uF
C426 2113743N50 100pF
C427 2113743N50 100pF
C428 2113743M24 0.1uF
C429 2113743M24 0.1uF
C430 2113928N01 0.1uF
C431 2113743N50 100pF
C433 2113743L41 0.01uF
C434 2113743M24 0.1uF
C435 2113743M24 0.1uF
C436 2113743N34 22.0pF
C437 2113743N34 22.0pF
C440 2113743G26 4.7uF
C441 2113743N50 100pF
C442 2113743E20 10uF
C443 2113928N01 0.1uF
C444 2113743N50 100pF
C445 2113743N50 100pF
C447 2113743M08 0.022uF
C448 2113928N01 0.1uF
C449 2113743N50 100pF
C451 2113743M08 0.022uF
C452 2113743G26 4.7uF
C453 2113743N50 100pF
C456 2113743N50 100pF
C458 2113743N50 100pF
C459 2113743N50 100pF
C463 2113743N50 100pF
C466 2113743N50 100pF
C467 2113928N01 0.1uF
C471 2113743N50 100pF
C472 2113743L09 470pF
C473 2113743L09 470pF
C475 2113743H14 10.0uF
C476 2113928D08 10.0uF
C479 2113928N01 0.1uF
C480 2113928D08 10.0uF
C481 2113928N01 0.1uF
C482 2113928N01 0.1uF
C490 2113743N50 100pF
C491 2113743N50 100pF
C492 2113743N50 100pF
C493 2113743N50 100pF
C494 2113743N50 100pF
C495 2113743N50 100pF
C496 2113743N50 100pF
C497 2113743N50 100pF
C502 2311049A05 0.47pF
C503 2113743N50 100pF
C505 2113743N50 100pF
Circuit
Ref
Motorola
Part No.
Description
C511 2113743N50 100pF
C512 2113743N50 100pF
C513 2113743N50 100pF
C514 2113743N50 100pF
C520 2113743L41 0.01uF
C521 2113743L41 0.01uF
C522 2113743L41 0.01uF
C523 2113743L41 0.01uF
C701 2180478Z20 1.0uF
C702 2113928N01 0.1uF
C703 2113743N50 100 pF
C704 2113928N01 0.1uF
C705 2113928N01 0.1uF
C707 2113928N01 0.1uF
C708 2113928N01 0.1uF
C709 2113743L17 1000 pF
C710 2311049A30 33 uF
C711 2113743L41 0.1 uF
C713 2113928N01 0.1 uF
C714 2113928N01 0.1 uF
C715 2113928N01 0.1 uF
C717 2113928N01 0.1 uF
C718 2113743L17 1000pF
C719 2113928N01 0.1uF
CR101 4880973Z02 PIN DIODE
CR102 4802245J41 PIN DIODES
CR105 5185963A15 TEMPERATURE SENSE
CR201 4802233J09 DIODE TRIPLE
CR203 4862824C03 VARACTOR
CR241 4805649Q13 DUAL VARACTOR
CR242 4862824C01 VARACTOR
CR243 4862824C01 VARACTOR
CR251 4802245J22 VARACTOR
CR301 4862824C01 VARACTOR
CR302 4862824C01 VARACTOR
CR303 4880154K03 DUAL COMMON ANODE-
CATHODE
CR304 4862824C01 VARACTOR
CR305 4862824C01 VARACTOR
CR306 4802245J42 RING QUAD DIODE
CR308 4802245J41 PIN DIODES
CR310 4862824C01 VARACTOR
CR411 4802245J47 DIODE SCHOTTKY
CR412 4802245J47 DIODE SCHOTTKY
CR413 4802245J47 DIODE SCHOTTKY
CR440 4813833C02 DUAL DIODE COMMON
CATHODE
CR501 4880107R01 RECTIFIER
CR503 4805729G49 LED RED/YEL
CR700 4802245J47 DIODE SCHOTTKY
E101 2484657R01 FERRITE BEAD
Circuit
Ref
Motorola
Part No.
Description
E400-
E409 2480640Z01 FERRITE BEAD
F501 6580542Z01 FUSE 3A
FL201 4802245J49 CRYSTAL 16.8MHZ CLIP
FL301 4802245J43 XTAL FILTER 45.1MHZ
FL401 4870368G02 CLOCK OSC XTAL
H101 2680499Z01 HEAT SPREADER
J101 0180117S05 RF JACK ASSEMBLY
J102 0280519Z02 NUT, ANTENNA
J400 0905505Y04 40 PINS CONNECTOR
J403 0905505Y02 20 PINS CONNECTOR
L101 2479990B02 19.61nH
L102 2479990B02 19.61nH
L104 2479990B02 19.61nH
L105 2462587N22 390nH
L106 2479990A02 7.66nH
L107 2479990G01 33.47nH
L108 2479990A01 4.22nH
L109 2479990B01 11.03nH
L112 2462587N45 22nH
L113 2413926H09 5.6nH
L114 2462587N22 390nH
L115 2462587N22 390nH
L116 2479990A03 9.75nH
L160 2413926H14 15.0nH
L201 2462587Q20 2.2UH
L202 2462587Q20 2.2UH
L203 2462587Q20 2.2UH
L232 2462587P25 12UH
L241 2462587V41 390nH
L242 2462587V38 220nH
L243 2460593C01 TEFLON RESONATOR
L251 2462587V28 33nH
L253 2460593C02 TEFLON RESONATOR
L261 2462587V29 39nH
L271 2462587V32 68nH
L273 2462587V28 33nH
L281 2462587V41 390nH
L282 2462587V41 390nH
L301 2479990C01 13.9nH
L302 2479990C01 13.9nH
L303 2462587V26 22nH
L304 2462587V37 180nH
L305 2462587V26 22nH
L306 2479990C01 13.9nH
L307 2479990C01 13.9nH
L309 2479990C02 16.28nH
L310 2462587V36 150nH
L311 2462587N65 750nH
L314 2462587N72 2.2UH
L325 2480646Z20 2.20UH
Circuit
Ref
Motorola
Part No.
Description
L330 2462587N64 680nH
L331 2480646Z20 2.20UH
L332 2462587N53 100nH
L340 2462587V41 390nH
L400 2462587Q42 390nH
L401 2462587Q42 390nH
L410 2462587Q42 390nH
L411 2462587Q42 390nH
L505 2462587Q42 390nH
P100 3905643V01 GND CONTACT FINGER
PB501 4080523Z01 TACTILE PUSH BUTTON
PB502 4080523Z01 TACTILE PUSH BUTTON
PB503 4080523Z01 TACTILE PUSH BUTTON
PB504 4080523Z01 TACTILE PUSH BUTTON
PB505 4080523Z01 TACTILE PUSH BUTTON
Q110 4802245J55 RF POWER FET
Q111 4802245J50 DUAL NPN/PNP
Q210 4802245J50 DUAL NPN/PNP
Q241 4805218N63 NPN
Q260 4802245J50 DUAL NPN/PNP
Q261 4802245J50 DUAL NPN/PNP
Q301 4802245J44 NPN
Q302 4802245J44 NPN
Q315 4880214G02 NPN
Q320 4805218N63 NPN
Q400 4809579E18 MOSFET P-CHAN
Q403 4880214G02 NPN
Q405 4802245J54 DUAL NPN
Q410 4802245J54 DUAL NPN
Q416 4809579E18 MOSFET P-CHAN
Q417 4802245J50 DUAL NPN/PNP
Q502 5180159R01 DUAL NPN
Q505 4880214G02 NPN
R101 0662057A34 240
R102 0680735Z01 0.075
R103 0662057M41 43
R104 0662057N15 47K
R106 0662057M26 10
R108 0662057M92 5.6K
R109 0662057N30 200K
R110 0662057M61 300
R111 0662057M33 20
R112 0662057M61 300
R120 0662057N14 43K
R130 0662057M98 10K
R131 0662057N05 18K
R132 0662057N33 270K
R161 0662057M57 200
R170 0662057A34 240
R171 0662057N14 43K
R172 0662057A32 200
Circuit
Ref
Motorola
Part No.
Description

Motorola GP series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Number of Channels	16
Channel Spacing	12.5 kHz / 25 kHz
Battery Life	8 hours (with standard battery)
Operating Voltage	7.5V DC
Ingress Protection	IP54
MIL-STD	810 C, D, E, F
