Motorola GP series Service Manual

UHF PCB 8480587Z05 Parts List 4-37
CR241 4805649Q13 Vara cto r
CR242 4862824C08 Varactor
CR243 4862824C08 Varact or
CR251 4802245J22 Varactor
CR301 4862824C08 Varact or
CR302 4862824C08 Varactor
CR303 4880154K03 Dual Schottky Diode
CR304 4862824C08 Varactor
CR305 4862824C08 Varact or
CR306 4802245J42 Ring Quad Diode
CR308 4802245J41 Pin Diode
CR310 4862824C08 Varactor
CR411 4802245J62 Diode Schottky
CR412 4802245J62 Diode Schottky
CR413 4802245J62 Diode Schottky
CR440 4813833C02 Dual Common Cathode
Diode
CR501 4880107R01 Rectifier
CR503 4805729G49 Red/Yellow LED
CR601 NOTPLACED
CR700 4802245J47 Diode Schottky
E101 2484657R01 FERRITE BEAD
E400 2480640Z01 FERRITE BEAD
E401 2480640Z01 FERRITE BEAD
E402 2480640Z01 FERRITE BEAD
E403 2480640Z01 FERRITE BEAD
E404 2480640Z01 FERRITE BEAD
E405 2480640Z01 FERRITE BEAD
E406 2480640Z01 FERRITE BEAD
E407 2480640Z01 FERRITE BEAD
E408 2480640Z01 FERRITE BEAD
E409 2480640Z01 FERRITE BEAD
F501 6580542Z01 Fuse 3A
FL201 4805875Z04 16.8 MHZ Xtal Filter
FL301 9186153B01 Xtal Filter 45.1MHz
FL401 4870368G02 Real Time Clock Xtal Oscilla-
tor 38.4kHz
H101 2680499Z01 Heat Spreader
J101 0985613Z01 RF Jack
J102 0280519Z02 Antenna Nut
J400 0905505Y04 40-Pin Connector
Circuit
Ref.
Motorola
Part No.
Description
J403 0905505Y02 20-Pin Connector
L101 2479990B02 19.61nH
L102 2479990B02 19.61nH
L104 2479990B02 19.61nH
L105 2462587N22 390nH
L106 2479990A02 7.66nH
L107 2479990G01 33.47nH
L108 2479990A01 4.2nH
L109 2479990B01 11.03nH
L112 2462587N45 22nH
L113 2413926H09 5.6nH
L114 2462587N45 22nH
L115 2462587N22 390nH
L116 2479990A03 9.75nH
L160 2413926H14 15nH
L201 2462587Q20 2200nH
L202 2462587Q20 2200nH
L203 2462587Q20 2200nH
L232 2462587P25 12000nH
L241 2462587V41 390nH
L242 2462587V38 220nH
L243 2485776Z01 RESONATOR
L251 2462587V28 33nH
L253 2460593C02 RESONATOR
L261 2462587V29 39nH
L271 2462587V32 68nH
L273 2462587V28 33nH
L281 2462587V41 390nH
L282 2462587V41 390nH
L301 2479990C01 13.9nH
L302 2479990C01 13.9nH
L303 2462587V26 22nH
L304 2462587V37 180nH
L305 2462587V26 22nH
L306 2479990C01 13.9nH
L307 2479990C01 13.9nH
L309 2479990C02 16.28nH
L310 2462587V36 150nH
L311 2462587N65 750nH
L314 2462587N72 2200nH
L321 NOTPLACED
Circuit
Ref.
Motorola
Part No.
Description
L325 2480646Z20 2.20uH
L330 2462587N64 680nH
L331 2480646Z20 2.20uH
L332 2462587N53 100nH
L340 2462587V41 390nH
L400 2462587Q42 390nH
L401 2462587Q42 390nH
L410 2462587Q42 390nH
L411 2462587Q42 390nH
L505 2462587Q42 390nH
L601 NOTPLACED
M100 7585651Z01 PAD, EMI, SMT
M101 7585651Z01 PAD, EMI, SMT
M300 7585651Z01 PAD, EMI, SMT
M301 7585651Z01 PAD, EMI, SMT
M400 7585651Z01 PAD, EMI, SMT
M401 7585651Z01 PAD, EMI, SMT
P100 3905643V01 Ground Contact Finger
PB501 4080523Z02 Tactile Switch
PB502 4080523Z02 Tactile Switch
PB503 4080523Z02 Tactile Switch
PB504 4080523Z02 Tactile Switch
PB505 4080523Z02 Tactile Switch
Q110 4813828A09 RF PA
Q111 4809939C05 DUAL NPN/PNP Transistor
Q210 4809939C05 DUAL NPN/PNP Transistor
Q241 4805218N63 RF NPN Transistor
Q260 4809939C05 DUAL NPN/PNP Transistor
Q261 4809939C05 DUAL NPN/PNP Transistor
Q301 4802245J44 NPN Transistor
Q302 4802245J44 NPN Transistor
Q310 NOTPLACED
Q315 4880214G02 NPN Transistor
Q316 NOTPLACED
Q320 4805218N63 RF NPN Transistor
Q400 4809579E18 MOSFET P-Channel
Q403 4813824A17 PNP Transistor
Q405 4802245J54 Dual NPN Transistor
Q410 4802245J54 Dual NPN Transistor
Q416 4809579E18 MOSFET P-Channel
Q417 4809939C05 DUAL NPN/PNP Transistor
Circuit
Ref.
Motorola
Part No.
Description
Q502 5180159R01 Dual NPN Transistor
Q505 4880214G02 NPN Transistor
R101 0662057A34 240
R102 0680539Z01 0.1
R103 0662057M41 43
R104 0662057N15 47K
R106 0662057M26 10
R107 NOTPLACED
R108 0662057M92 5.6K
R109 0662057N30 200K
R110 0662057M61 300
R111 0662057M33 20
R112 0662057M61 300
R120 0662057N14 43K
R130 0662057M98 10K
R131 0662057N05 18K
R132 0662057N33 270K
R133 NOTPLACED
R161 0662057M57 200
R170 0662057A34 240
R171 0662057N14 43K
R172 0662057A32 200
R173 0662057N29 180K
R174 0662057N15 47K
R175 0662057B59 3
R176 0662057B59 3
R201 0662057N21 82K
R202 0662057N23 100K
R204 0662057N15 47K
R231 0662057M52 120
R232 0662057M69 620
R233 0662057M68 560
R241 0662057M32 18
R242 0662057M57 200
R243 0662057M98 10K
R244 0662057N01 12K
R245 0662057M59 240
R248 0662057M37 30
R251 0662057M32 18
R252 0662057M62 330
R253 0662057M95 7.5K
Circuit
Ref.
Motorola
Part No.
Description

Motorola GP series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Number of Channels	16
Channel Spacing	12.5 kHz / 25 kHz
Battery Life	8 hours (with standard battery)
Operating Voltage	7.5V DC
Ingress Protection	IP54
MIL-STD	810 C, D, E, F
