Motorola GP series Service Manual

UHF2 PCB 8485677Z03 (GP1280) Parts List 4-35
C514 2113743N50 100pF
C520 2113743L41 10000pF
C521 2113743L41 10000pF
C522 2113743L41 10000pF
C523 2113743L41 10000pF
C601 NOTPLACED
C602 NOTPLACED
C603 NOTPLACED
C701 2180478Z20 1uF
C702 2113928N01 0.1uF
C703 2113743N50 100pF
C704 2113928N01 0.1uF
C705 2113928N01 0.1uF
C706 NOTPLACED
C707 2113928N01 0.1uF
C708 2113928N01 0.1uF
C709 2113743L17 1000pF
C711 2113743L41 10000pF
C713 2113928N01 0.1uF
C714 2113928N01 0.1uF
C715 2113928N01 0.1uF
C717 2113928N01 0.1uF
C718 2113743L17 1000pF
C719 2113928N01 0.1uF
CR101 4880973Z02 Pin Diode
CR102 4802245J41 Pin Diode
CR103 4802245J41 Pin Diode
CR105 5185963A15 Temperature Sensor
CR160 NOTPLACED
CR201 4802233J09 Triple Diode
CR203 4862824C03 Varactor
CR241 4805649Q13 Vara cto r
CR242 4862824C01 Varactor
CR243 4862824C01 Varact or
CR251 4802245J22 Varactor
CR301 4862824C01 Varact or
CR302 4862824C01 Varactor
CR303 4880154K03 Dual Schottky Diode
Circuit
Ref.
Motorola
Part No.
Description
CR304 4862824C01 Varactor
CR305 4862824C01 Var actor
CR306 4802245J42 Ring Quad Diode
CR308 4802245J41 Pin Diode
CR310 4862824C01 Varactor
CR411 4802245J62 Diode Schottky
CR412 4802245J62 Diode Schottky
CR413 4802245J62 Diode Schottky
CR440 4813833C02 Dual Common Cathode
Diode
CR501 4880107R01 Rectifier
CR503 4805729G49 Red/Yellow LED
CR601 NOTPLACED
CR700 4802245J47 Diode Schottky
E101 2484657R01 FERRITE BEAD
E400 2480640Z01 FERRITE BEAD
E401 2480640Z01 FERRITE BEAD
E402 2480640Z01 FERRITE BEAD
E403 2480640Z01 FERRITE BEAD
E404 2480640Z01 FERRITE BEAD
E405 2480640Z01 FERRITE BEAD
E406 2480640Z01 FERRITE BEAD
E407 2480640Z01 FERRITE BEAD
E408 2480640Z01 FERRITE BEAD
E409 2480640Z01 FERRITE BEAD
F501 6580542Z01 Fuse 3A
FL201 4805875Z04 16.8 MHZ Xtal Filter
FL301 9186153B01 Xtal Filter 45.1MHz
FL401 4870368G02 Real Time Clock Xtal
Oscillator 38.4kHz
H101 2680499Z01 Heat Spreader
J101 0985613Z01 RF Jack
J102 0280519Z02 Antenna Nut
J400 0905505Y04 40-Pin Connector
J403 0905505Y02 20-Pin Connector
L101 2460591B28 13.37nH
L102 2460591B28 13.37nH
L104 2460591B48 15.22nH
Circuit
Ref.
Motorola
Part No.
Description
L105 2462587N22 390nH
L106 2460591A19 8.71nH
L107 2479990G01 33.47nH
L108 2479990A01 4.22nH
L112 2462587N42 12nH
L113 2413926H09 5.6nH
L114 2462587N42 12nH
L115 2462587N22 390nH
L116 2479990C02 16.28nH
L117 2409154M17 22nH
L160 2413926H14 15nH
L201 2462587Q20 2,200nH
L202 2462587Q20 2,200nH
L203 2462587Q20 2,200nH
L232 2462587P25 12000nH
L241 2462587V41 390nH
L242 2462587V26 22nH
L243 2485776Z02 RESONATOR
L251 2462587V41 390nH
L253 2460593C03 RESONATOR
L261 2462587V29 39nH
L271 2462587V27 27nH
L273 2462587V25 18nH
L281 2462587V41 390nH
L282 2462587V41 390nH
L301 2479990B01 11. 03nH
L302 2479990B01 11.03nH
L303 2462587V26 22nH
L304 2462587V37 180nH
L305 2462587V23 12nH
L306 2479990B01 11.03nH
L307 2479990B01 11. 03nH
L309 2479990C02 16.28nH
L310 2462587V36 150nH
L311 2462587N65 750nH
L314 2462587N72 2200nH
L321 NOTPLACED
L325 2480646Z20 2.2uH
Circuit
Ref.
Motorola
Part No.
Description
L330 2462587N64 680nH
L331 2480646Z20 2.2uH
L332 2462587N53 100nH
L340 2462587V41 390nH
L400 2462587Q42 390nH
L401 2462587Q42 390nH
L410 2462587Q42 390nH
L411 2462587Q42 390nH
L505 2462587Q42 390nH
L601 NOTPLACED
P100 3905643V01 Ground Contact Finger
PB501 4080523Z02 Tactile Switch
PB502 4080523Z02 Tactile Switch
PB503 4080523Z02 Tactile Switch
PB504 4080523Z02 Tactile Switch
PB505 4080523Z02 Tactile Switch
Q110 4813828A09 RF PA
Q111 4809939C05 DUAL NPN/PNP Transistor
Q210 4809939C05 DUAL NPN/PNP Transistor
Q241 4805218N63 RF NPN Transistor
Q260 4809939C05 DUAL NPN/PNP Transistor
Q261 4809939C05 DUAL NPN/PNP Transistor
Q301 4802245J44 NPN Transistor
Q302 4802245J44 NPN Transistor
Q310 NOTPLACED
Q315 4880214G02 NPN Transistor
Q316 NOTPLACED
Q320 4805218N63 RF NPN Transistor
Q400 4809579E18 MOSFET P-Channel
Q403 4813824A17 PNP Transistor
Q405 4802245J54 Dual NPN Transistor
Q410 4802245J54 Dual NPN Transistor
Q416 4809579E18 MOSFET P-Channel
Q417 4809939C05 DUAL NPN/PNP Transistor
Q502 5180159R01 Dual NPN Transistor
Q505 4880214G02 NPN Transistor
R101 0662057A34 240
R102 0680539Z01 0.1
Circuit
Ref.
Motorola
Part No.
Description

Motorola GP series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Number of Channels	16
Channel Spacing	12.5 kHz / 25 kHz
Battery Life	8 hours (with standard battery)
Operating Voltage	7.5V DC
Ingress Protection	IP54
MIL-STD	810 C, D, E, F
