Motorola GP series Detailed Service Manual

3-18 UHF PCB 8480450Z03 / PCB 8480587Z01 Parts List
C351 2113743N33 20pF
C352 2113743N28 12pF
C353 2113743N41 43pF
C354 2113743N42 47pF
C355 2113743A24 0.33uF
C356 2113743M08 22000pF
C357 2113743A23 0.22uF
C358 2113741A23 1200pF
C359 2109720D14 0.1uF
C360 2113743E07 0.022uF
C361 2113741F49 10nF
C362 2113743M08 22000pF
C363 2311049A40 2.2uF
C364 2113743L41 10000pF
C370 2113743N50 100pF
C374 2113743N50 100pF
C375 2113743N50 100pF
C380 2113743L41 10000pF
C381 2113743N21 6.2pF
C382 2311049A59 10uF
C383 2113743N50 100pF
C384 2113743N44 56pF
C385 2113743N44 56pF
C386 2113743N50 100pF
C390 2113743N50 100pF
C395 2113743N50 100pF
C397 2311049A05 0.47uF
C400 2113743L41 10000pF
C401 2113743M24 100000pF
C402 2113743M24 100000pF
C403 2113743G24 2.2uF
C407 2113928N01 0.1uF
C408 2113743N50 100pF
C409 2113743M24 100000pF
C410 2113928N01 0.1uF
C411 2113743M24 100000pF
C414 2113743M24 100000pF
C415 2185895Z01 0.01uF
C416 2113928N01 0.1uF
C420 2113743L41 10000pF
C421 2113928N01 0.1uF
Circuit
Ref
Motorola
Part No.
Description
C422 2113743M24 100000pF
C423 2113743N50 100pF
C424 2311049A59 10uF
C425 2113743M24 100000pF
C426 2113743N50 100pF
C427 2113743N50 100pF
C428 2113743M24 100000pF
C429 2113743M24 100000pF
C430 2113928N01 0.1uF
C431 2113743N50 100pF
C433 2113743L41 10000pF
C434 2113928N01 0.1uF (not used in GP140/240)
C435 2113743M24 100000pF
C436 2113743N34 22pF (not used in GP140/240)
C437 2113743N34 22pF (not used in GP140/240)
C440 2113743G26 4.7uF
C441 2113743N50 100pF
C442 2113743E20 10uF
C443 2113928N01 0.1uF
C444 2113743N50 100pF
C445 2113743N50 100pF
C447 2113743M08 22000pF
C448 2113928N01 0.1uF
C449 2113743N50 100pF
C451 2113743M08 22000pF
C452 2113743B29 1uF
C453 2113743N50 100pF
C456 2113743N50 100pF
C458 2113743N50 100pF
C459 2113743N50 100pF
C463 2113743N50 100pF
C466 2113743N50 100pF
C467 2113928N01 0.1uF
C471 2113743N50 100pF
C472 2113743L09 470pF
C473 2113743L09 470pF
C475 2113743H14 10uF
C476 2113928D08 10uF
C479 2113928N01 0.1uF
C480 2113743G26 4.7uF
C481 2113928N01 0.1uF
Circuit
Ref
Motorola
Part No.
Description
C482 2113928N01 0.1uF
C490 2113743N50 100pF
C491 2113743N50 100pF
C492 2113743N50 100pF
C493 2113743N50 100pF
C494 2113743N50 100pF
C495 2113743N50 100pF
C496 2113743N50 100pF
C497 2113743N50 100pF
C502 2311049A05 0.47uF
C503 2113743N50 100pF
C505 2113743N50 100pF
C511 2113743N50 100pF
C512 2113743N50 100pF
C513 2113743N50 100pF
C514 2113743N50 100pF
C520 2113743L41 10000pF
C521 2113743L41 10000pF
C522 2113743L41 10000pF
C523 2113743L41 10000pF
CR101 4880973Z02 Pin diode
CR102 4802245J41 Pin diode
CR105 5185963A15 Temperature Sensor
CR201 4802233J09 Triple diode (SOT 25)
CR203 4862824C03 Va racto r
CR241 4805649Q13 Varactor
CR242 4862824C08 Va racto r
CR243 4862824C08 Varactor
CR251 4802245J22 Varactor
CR301 4862824C08 Varactor
CR302 4862824C08 Va racto r
CR303 4880154K03 Dual common anode-cathode
diode
CR304 4862824C08 Va racto r
CR305 4862824C08 Varactor
CR306 4802245J42 Ring Quad diode (SOT-143)
CR308 4802245J41 Pin diode
CR310 4862824C08 Va racto r
CR411 4802245J47 Schottky diode
CR412 4802245J47 Schottky diode
CR413 4802245J47 Schottky diode
Circuit
Ref
Motorola
Part No.
Description
CR440 4813833C02 Dual common cathode diode
CR501 4880107R01 Rectifier
CR503 4805729G49 Red/Yellow LED
E101 2484657R01 Ferrite bead
E400 2480640Z01 Ferrite bead
E401 2480640Z01 Ferrite bead
E402 2480640Z01 Ferrite bead
E403 2480640Z01 Ferrite bead
E404 2480640Z01 Ferrite bead
E405 2480640Z01 Ferrite bead
E406 2480640Z01 Ferrite bead
E407 2480640Z01 Ferrite bead
E408 2480640Z01 Ferrite bead
E409 2480640Z01 Ferrite bead
F501 6580542Z01 3A fuse
FL201 4802245J49 16.8MHz Xtal oscillator
FL301 4802245J43 Xtal Filter 45.1MHz
FL401 4870368G02 Real Time clock Osc Xtal (not
used in GP140/240)
H101 2680499Z01 Heat spreader
J101 0985613Z01 RF Jack
J102 0280519Z02 Antenna nut
J400 0905505Y04 40-pin connector
J403 0905505Y02 20-pin connector
L101 2479990B02 19.61nH
L102 2479990B02 19.61nH
L104 2479990B02 19.61nH
L105 2462587N22 390nH
L106 2479990A02 7.66nH
L107 2479990G01 33.47nH
L108 2479990A01 4.22nH
L109 2479990B01 11.03nH
L112 2462587N45 22nH
L113 2413926H09 0.3nH
L114 2462587N22 390nH
L115 2462587N22 390nH
L116 2479990A03 9.75nH
L160 2413926H14 15nH
L201 2462587Q20 2200nH
L202 2462587Q20 2200nH
L203 2462587Q20 2200nH
Circuit
Ref
Motorola
Part No.
Description
