UHF PCB 8480450Z03 / PCB 8480587Z01 Parts List 3-19
L232 2462587P25 12000nH
L241 2462587V41 390nH
L242 2462587V38 220nH
L243 2460593C01 Multi-layered Teflon resonator,
Rx
L251 2462587V28 33nH
L253 2460593C02 Multi-layered Teflon resonator,
Tx
L261 2462587V29 39nH
L271 2462587V32 68nH
L273 2462587V28 33nH
L281 2462587V41 390nH
L282 2462587V41 390nH
L301 2479990C01 13.9nH
L302 2479990C01 13.9nH
L303 2462587V26 22nH
L304 2462587V37 180nH
L305 2462587V26 22nH
L306 2479990C01 13.9nH
L307 2479990C01 13.9nH
L309 2479990C02 16.28nH
L310 2462587V36 150nH
L311 2462587N65 750nH
L314 2462587N72 2200nH
L325 2480646Z20 2.2uH
L330 2462587N64 680nH
L331 2480646Z20 2.2uH
L332 2462587N53 100nH
L340 2462587V41 390nH
L400 2462587Q42 390nH
L401 2462587Q42 390nH
L410 2462587Q42 390nH
L411 2462587Q42 390nH
L505 2462587Q42 390nH
P100 3905643V01 Ground contact finger
PB501 4080523Z01 Tactile switch
PB502 4080523Z01 Tactile switch
PB503 4080523Z01 Tactile switch
PB504 4080523Z01 Tactile switch
PB505 4080523Z01 Tactile switch
Q110 4802245J55 RF Power amplifier
Circuit
Ref
Motorola
Part No.
Description
Q111 4802245J50 Dual NPN/PNP Transistor
Q210 4802245J50 Dual NPN/PNP Transistor
Q241 4805218N63 RF NPN transistor
Q260 4802245J50 Dual NPN/PNP Transistor
Q261 4802245J50 Dual NPN/PNP Transistor
Q301 4802245J44 NPN Transistor
Q302 4802245J44 NPN Transistor
Q315 4880214G02 NPN Transistor
Q320 4805218N63 RF NPN transistor
Q400 4809579E18 Mosfet P-chan
Q403 4880214G02 NPN Transistor
Q405 4802245J54 Dual NPN Transistor
Q410 4802245J54 Dual NPN Transistor
Q416 4809579E18 Mosfet P-chan (not used in
GP140/240)
Q417 4802245J50 Dual NPN/PNP Transistor
Q502 5180159R01 Dual NPN Transistor
Q505 4880214G02 NPN Transistor
R101 0662057A34 240
R102 0680539Z01 0.1
R103 0662057M41 43
R104 0662057N15 47k
R106 0662057M26 10
R108 0662057M92 5600
R109 0662057N30 200k
R110 0662057M61 300
R111 0662057M33 20
R112 0662057M61 300
R120 0662057N14 43k
R130 0662057M98 10k
R131 0662057N05 18k
R132 0662057N33 270k
R161 0662057M57 200
R170 0662057A34 240
R171 0662057N14 43k
R172 0662057A32 200
R173 0662057N29 180k
R201 0662057N21 82k
R202 0662057N23 100k
R204 0662057N15 47k
R231 0662057M52 120
Circuit
Ref
Motorola
Part No.
Description
R232 0662057M69 620
R233 0662057M68 560
R241 0662057M32 18
R242 0662057M57 200
R243 0662057M98 10k
R244 0662057N01 12k
R245 0662057M59 240
R248 0662057M37 30
R251 0662057M32 18
R252 0662057M62 330
R253 0662057M95 7500
R254 0662057M95 7500
R255 0662057M89 4300
R256 0662057M37 30
R260 0662057M74 1000
R300 0662057M82 2200
R301 0662057N23 100k
R302 0662057N23 100k
R303 0662057M74 1000
R304 0662057N01 12k
R305 0662057M67 0
R306 0662057N23 100k
R307 0662057N23 100k
R308 0662057M60 270
R309 0662057M32 18
R310 0662057M60 270
R311 0662057N10 30k
R312 0662057M83 2400
R313 0662057M62 330
R314 0662057M85 3000
R315 0662057N01 12k
R316 0662057A96 91k
R317 0662057M74 1000
R318 0662057A79 18k
R319 0662057A29 150
R320 0662057M74 1000
R321 0662057M83 2400
R322 0662057N30 200k
R324 0662057M81 2000
R325 0662057M94 6800
R327 0662057N11 33k
Circuit
Ref
Motorola
Part No.
Description
R328 0662057M12 2.7
R329 0662057M01 0
R339 0662057M01 0
R340 0662057M94 6800
R342 0662057N23 100k
R343 0662057M26 10
R344 0662057N01 12k
R345 0662057M98 10k
R346 0662057N17 56k
R347 0662057M74 1000
R348 0662057M87 3600
R349 0662057C01 0
R350 0662057N23 100k
R351 0662057C01 0
R352 0662057M86 3300
R355 0662057M01 0
R400 0662057N15 47k
R401 0662057M01 0
R405 0662057M01 0
R406 0662057N20 75k
R407 0662057N19 68k
R409 0662057M98 10k
R410 0662057N23 100k
R411 0662057M98 10k
R413 0662057M01 0
R414 0662057V34 180k
R415 0662057V26 91k
R416 0662057M90 4700
R418 0662057M01 0
R419 0662057M67 0 (not used in GP140/240)
R420 0662057B46 10M (not used in GP140/240)
R421 0662057M81 2000
R423 0662057N39 470k
R424 0662057N12 36k
R425 0662057N10 30k
R426 0662057N35 330k (not used in GP140/240)
R427 0662057M84 2700
R428 0662057M10 2.2
R429 0662057M98 10k
R431 0662057N39 470k
R432 0662057N16 51k
Circuit
Ref
Motorola
Part No.
Description
