Motorola GP series Detailed Service Manual

3-138 UHF PCB 8415234H08 Parts List
C233 2313960A26 CAP,FXD,.1UF,+10%,-
10%,35V-DC,
C234 2313960A55 CAP,FXD,.47UF,+10%,-
10%,25V-DC
C235 2113946N03 CAP CER CHP 2.2UF 16V
C238 2113945L17 CAP,FXD,470PF,+5%,-
5%,50V-DC,0
C241 2113944A40 CAP CER CHP 100.0PF
50V 5%
C242 2113944A22 CAP CER CHP 7.5PF 50V
+/- 0.5P
C243 2113944A22 CAP CER CHP 7.5PF 50V
+/- 0.5P
C244 2113944C13 CAP CER CHP 2.0PF 50V
+/- 0.25
C245 2113944A10 CAP CER CHP 2.4PF 50V
+/- 0.25
C246 2113944A40 CAP CER CHP 100.0PF
50V 5%
C247 2113944A40 CAP CER CHP 100.0PF
50V 5%
C248 2113946K02 CAP CER CHP 0.10UF 16V
C250 2113944A22 CAP CER CHP 7.5PF 50V
+/- 0.5P
C251 2113944A40 CAP CER CHP 100.0PF
50V 5%
C252 2113944A25 CAP CER CHP 10.0PF 50V
+/- 0.5
C253 2113944C12 CAP CER CHP 1.8PF 50V
+/- 0.25
C254 2113944A14 CAP CER CHP 3.6PF 50V
+/- 0.25
C255 2113944A40 CAP CER CHP 100.0PF
50V 5%
C257 2113944A40 CAP CER CHP 100.0PF
50V 5%
Circuit
Ref
Motorola
Part No.
Description
C258 2113945B02 CAP CER CHP 10,000PF
25V 10%
C259 2113945B02 CAP CER CHP 10,000PF
25V 10%
C260 2113944A40 CAP CER CHP 100.0PF
50V 5%
C263 2113944A62 CAP,FXD,.75PF,.25PF+/-
,50V-DC,
C264 2113944A40 CAP CER CHP 100.0PF
50V 5%
C265 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C271 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C272 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C273 2113946K02 CAP CER CHP 0.10UF 16V
C276 2113946N03 CAP CER CHP 2.2UF 16V
C277 2113944A40 CAP CER CHP 100.0PF
50V 5%
C278 2313960D07 CAP,FXD,10,+10,-
10,16,SM,,-55M
C279 2113946N03 CAP CER CHP 2.2UF 16V
C281 2113944A40 CAP CER CHP 100.0PF
50V 5%
C285 2113944A40 CAP CER CHP 100.0PF
50V 5%
C286 2113946K02 CAP CER CHP 0.10UF 16V
C289 2113944A40 CAP CER CHP 100.0PF
50V 5%
C291 2313960M51 CAP,FXD,10UF,+10%,-
10%,6.3V-DC
C292 2113946K02 CAP CER CHP 0.10UF 16V
C293 2113945G98 CAP,FXD,.47UF,+10%,-
10%,50V-DC
Circuit
Ref
Motorola
Part No.
Description
C294 2113944A40 CAP CER CHP 100.0PF
50V 5%
C295 2113944A40 CAP CER CHP 100.0PF
50V 5%
C296 2113946K02 CAP CER CHP 0.10UF 16V
C297 2113945B02 CAP CER CHP 10,000PF
25V 10%
C298 2113946K02 CAP CER CHP 0.10UF 16V
C301 2113944A14 CAP CER CHP 3.6PF 50V
+/- 0.25
C302 2113944A25 CAP CER CHP 10.0PF 50V
+/- 0.5
C303 2113944C20 CAP CER CHP 3.9PF 50V
+/- 0.25
C304 2113944A25 CAP CER CHP 10.0PF 50V
+/- 0.5
C305 2113944A80 CAP,FXD,20PF,+5%,-
5%,50V-DC,04
C306 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C307 2113944A40 CAP CER CHP 100.0PF
50V 5%
C308 2113944A40 CAP CER CHP 100.0PF
50V 5%
C309 2113944A40 CAP CER CHP 100.0PF
50V 5%
C310 2113944A40 CAP CER CHP 100.0PF
50V 5%
C311 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C312 2113944A24 CAP CER CHP 9.1PF 50V
+/- 0.5P
C313 2113944A25 CAP CER CHP 10.0PF 50V
+/- 0.5
C314 2113946K02 CAP CER CHP 0.10UF 16V
C315 2113944A40 CAP CER CHP 100.0PF
50V 5%
Circuit
Ref
Motorola
Part No.
Description
C316 2113944C20 CAP CER CHP 3.9PF 50V
+/- 0.25
C317 2113944A24 CAP CER CHP 9.1PF 50V
+/- 0.5P
C318 2113944A22 CAP CER CHP 7.5PF 50V
+/- 0.5P
C319 2113944A11 CAP CER CHP 2.7PF 50V
+/- 0.25
C320 2113944A79 CAP,FXD,16PF,+5%,-
5%,50V-DC,04
C321 2113944A40 CAP CER CHP 100.0PF
50V 5%
C322 2113944A38 CAP CER CHP 82.0PF 50V
5%
C324 2113944A29 CAP CER CHP 22.0PF 50V
5%
C325 2115153H26 CAP, CERAMIC, COG
C326 2113946K02 CAP CER CHP 0.10UF 16V
C327 2113946K02 CAP CER CHP 0.10UF 16V
C328 2113946K02 CAP CER CHP 0.10UF 16V
C329 2113946K02 CAP CER CHP 0.10UF 16V
C334 2113945A13 CAP CER CHP 4700PF
50V 10%
C337 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C338 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C343 2113946K02 CAP CER CHP 0.10UF 16V
C344 2113945D04 CAP CER CHP 100,000PF
25V 10%
C345 2113946K02 CAP CER CHP 0.10UF 16V
C346 2113946K02 CAP CER CHP 0.10UF 16V
C347 2113946K02 CAP CER CHP 0.10UF 16V
C348 2113946K02 CAP CER CHP 0.10UF 16V
Circuit
Ref
Motorola
Part No.
Description

Motorola GP series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Number of Channels	16
Channel Spacing	12.5 kHz / 25 kHz
Battery Life	8 hours (with standard battery)
Operating Voltage	7.5V DC
Ingress Protection	IP54
MIL-STD	810 C, D, E, F
