Motorola GP series Detailed Service Manual

UHF PCB 8415234H08 Parts List 3-139
C349 2113945D04 CAP CER CHP 100,000PF
25V 10%
C350 2113946K02 CAP CER CHP 0.10UF 16V
C351 2113944A41 CAP CER CHP 120.0PF
50V 5%
C352 2113946K02 CAP CER CHP 0.10UF 16V
C355 2113946K02 CAP CER CHP 0.10UF 16V
C357 2113946K02 CAP CER CHP 0.10UF 16V
C358 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C359 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C360 2113944A13 CAP CER CHP 3.3PF 50V
+/- 0.25
C361 2113946K02 CAP CER CHP 0.10UF 16V
C362 2113946K02 CAP CER CHP 0.10UF 16V
C364 2113944A81 CAP,FXD,24PF,+5%,-
5%,50V-DC,04
C366 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C367 2113944A82 CAP,FXD,30PF,+5%,-
5%,50V-DC,04
C370 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25
C371 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C372 2113944A40 CAP CER CHP 100.0PF
50V 5%
C373 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C374 2113944A40 CAP CER CHP 100.0PF
50V 5%
C375 2113944A40 CAP CER CHP 100.0PF
50V 5%
C378 NOTPLACE
D
GCAM DUMMY PART
NUMBER
Circuit
Ref
Motorola
Part No.
Description
C380 2113945B02 CAP CER CHP 10,000PF
25V 10%
C381 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C382 2313960B57 CAP,FXD,10UF,+10%,-
10%,6.3V-DC
C383 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C385 2113944A31 CAP CER CHP 33.0PF 50V
5%
C386 2113944A40 CAP CER CHP 100.0PF
50V 5%
C387 2113944C83 CAP, FXD, 24PF, +5%, -5%,
50V-DC, 0603, C0G, -
55DEG CMIN, 125DEG
CMAX, PB
C388 2113944C84 CAP, FXD, 24PF, +5%, -5%,
50V-DC, 0603, C0G, -
55DEG CMIN, 125DEG
CMAX, PB
C389 2113944C85 CAP, FXD, 24PF, +5%, -5%,
50V-DC, 0603, C0G, -
55DEG CMIN, 125DEG
CMAX, PB
C390 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C391 2113944A81 CAP CHIP 24.0 PF 5%
COG
C392 2113944C86 CAP, FXD, 24PF, +5%, -5%,
50V-DC, 0603, C0G, -
55DEG CMIN, 125DEG
CMAX, PB
C400 2113944A40 CAP CER CHP 100.0PF
50V 5%
C401 2113946K02 CAP CER CHP 0.10UF 16V
C402 2113944F54 CAP, 33PF
C403 2113944C81 CAP, 24PF
C404 NOTPLACE
D
GCAM DUMMY PART
NUMBER
Circuit
Ref
Motorola
Part No.
Description
C405 2113944A40 CAP CER CHP 100.0PF
50V 5%
C406 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C407 2113946B04 CAP CER CHP 0.10UF 10V
10%
C408 2113944A40 CAP CER CHP 100.0PF
50V 5%
C409 2113946K02 CAP CER CHP 0.10UF 16V
C410 2113946B04 CAP CER CHP 0.10UF 10V
10%
C411 2113946K02 CAP CER CHP 0.10UF 16V
C414 2113946K02 CAP CER CHP 0.10UF 16V
C415 2185895Z01 CAPACITOR CER LOW
DIST .01UF
C416 2113946B04 CAP CER CHP 0.10UF 10V
10%
C419 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C420 2113945B02 CAP CER CHP 10,000PF
25V 10%
C421 2113946B04 CAP CER CHP 0.10UF 10V
10%
C422 2113946K02 CAP CER CHP 0.10UF 16V
C423 2113944A40 CAP CER CHP 100.0PF
50V 5%
C424 2313960B57 CAP,FXD,10UF,+10%,-
10%,6.3V-DC
C425 2113946K02 CAP CER CHP 0.10UF 16V
C426 2113944A40 CAP CER CHP 100.0PF
50V 5%
C427 2113944A40 CAP CER CHP 100.0PF
50V 5%
C428 2113946K02 CAP CER CHP 0.10UF 16V
C429 2113946K02 CAP CER CHP 0.10UF 16V
Circuit
Ref
Motorola
Part No.
Description
C430 2113946B04 CAP CER CHP 0.10UF 10V
10%
C431 2113944A40 CAP CER CHP 100.0PF
50V 5%
C432 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C433 2113945B02 CAP CER CHP 10,000PF
25V 10%
C434 2113946B04 CAP CER CHP 0.10UF 10V
10%
C435 2113946K02 CAP CER CHP 0.10UF 16V
C436 2113944A29 CAP CER CHP 22.0PF 50V
5%
C437 2113944A29 CAP CER CHP 22.0PF 50V
5%
C440 2113946Q01 CAP CER CHP 4.7UF 16V
C441 2113944A40 CAP CER CHP 100.0PF
50V 5%
C442 2113945D04 CAP CER CHP 100,000PF
25V 10%
C443 2113946B04 CAP CER CHP 0.10UF 10V
10%
C444 2113944A40 CAP CER CHP 100.0PF
50V 5%
C445 2113944A40 CAP CER CHP 100.0PF
50V 5%
C447 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-D
C448 2113946B04 CAP CER CHP 0.10UF 10V
10%
C449 2113944A40 CAP CER CHP 100.0PF
50V 5%
C450 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C451 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-D
Circuit
Ref
Motorola
Part No.
Description

Motorola GP series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Number of Channels	16
Channel Spacing	12.5 kHz / 25 kHz
Battery Life	8 hours (with standard battery)
Operating Voltage	7.5V DC
Ingress Protection	IP54
MIL-STD	810 C, D, E, F
