Motorola GP series Detailed Service Manual

3-140 UHF PCB 8415234H08 Parts List
C452 2113955D31 CAP,FXD,1UF,,+10%,-
10%,16V-DC,
C453 2113944A40 CAP CER CHP 100.0PF
50V 5%
C456 2113944A40 CAP CER CHP 100.0PF
50V 5%
C458 2113944A40 CAP CER CHP 100.0PF
50V 5%
C459 2113944A40 CAP CER CHP 100.0PF
50V 5%
C463 2113944A40 CAP CER CHP 100.0PF
50V 5%
C466 2113944A40 CAP CER CHP 100.0PF
50V 5%
C467 2113946B04 CAP CER CHP 0.10UF 10V
10%
C471 2113944A40 CAP CER CHP 100.0PF
50V 5%
C472 2113945A05 CAP CER CHP 470PF 50V
10%
C473 2113945A05 CAP CER CHP 470PF 50V
10%
C475 2113956E91 CAP,FXD,10UF,+10%,-
10%,16V-DC,
C476 2113946R01 CAP CER CHP 10.0UF 10V
C479 2113946B04 CAP CER CHP 0.10UF 10V
10%
C480 2113946R01 CAP CER CHP 10.0UF 10V
C481 2113946B04 CAP CER CHP 0.10UF 10V
10%
C482 2113946B04 CAP CER CHP 0.10UF 10V
10%
C490 2113944A40 CAP CER CHP 100.0PF
50V 5%
C491 2113944A40 CAP CER CHP 100.0PF
50V 5%
Circuit
Ref
Motorola
Part No.
Description
C492 2113944A40 CAP CER CHP 100.0PF
50V 5%
C493 2113944A40 CAP CER CHP 100.0PF
50V 5%
C494 2113944A40 CAP CER CHP 100.0PF
50V 5%
C495 2113944A40 CAP CER CHP 100.0PF
50V 5%
C496 2113944A40 CAP CER CHP 100.0PF
50V 5%
C497 2113944A40 CAP CER CHP 100.0PF
50V 5%
C498 NOTPLACE
D
GCAM DUMMY PART
NUMBER
C499 2113946B04 CAP CER CHP 0.10UF 10V
10%
C502 2313960A55 CAP,FXD,.47UF,+10%,-
10%,25V-DC
C503 2113944A84 CAP,FXD,43PF,+5%,-
5%,50V-DC,04
C505 2113944A40 CAP CER CHP 100.0PF
50V 5%
C511 2113944A40 CAP CER CHP 100.0PF
50V 5%
C512 2113944A40 CAP CER CHP 100.0PF
50V 5%
C513 2113944A40 CAP CER CHP 100.0PF
50V 5%
C514 2113944A40 CAP CER CHP 100.0PF
50V 5%
C520 2113945B02 CAP CER CHP 10,000PF
25V 10%
C521 2113945B02 CAP CER CHP 10,000PF
25V 10%
C522 2113945B02 CAP CER CHP 10,000PF
25V 10%
C523 2113945B02 CAP CER CHP 10,000PF
25V 10%
Circuit
Ref
Motorola
Part No.
Description
C524 2113944A40 CAP CER CHP 100.0PF
50V 5%
C525 2113944A40 CAP CER CHP 100.0PF
50V 5%
C526 2113944A40 CAP CER CHP 100.0PF
50V 5%
C527 2113944A40 CAP CER CHP 100.0PF
50V 5%
C528 2113944A40 CAP CER CHP 100.0PF
50V 5%
C529 2113944A40 CAP CER CHP 100.0PF
50V 5%
C597 2113944A84 CAP,FXD,43PF,+5%,-
5%,50V-DC,0402,C0
C598 2113944A15 CAP CER CHP 3.9PF 50V
+/- 0.25
C599 2113944A15 CAP CER CHP 4.7PF 50V
+/- 0.25
C600 2113944A81 CAP CHIP 24.0 PF 5%
COG
C601 2113944A40 CAP CHIP 100 PF 5% COG
C602 2113944A17 CAP CHIP 4.7 PF +-.25PF
COG
C603 2113944C81 CAP, FXD, 24PF, +5%, -5%,
50V-DC, 0603, C0G, -
55DEG CMIN, 125DEG
CMAX, PB
C604 2113944C82 CAP, FXD, 24PF, +5%, -5%,
50V-DC, 0603, C0G, -
55DEG CMIN, 125DEG
CMAX, PB
C605 2113944A40 CAP CER CHP 100.0PF
50V 5%
C610 2113944A40 CAP CER CHP 100.0PF
50V 5%
C611 2113944A40 CAP CER CHP 100.0PF
50V 5%
Circuit
Ref
Motorola
Part No.
Description
C612 2113944A40 CAP CER CHP 100.0PF
50V 5%
C613 2113944A40 CAP CER CHP 100.0PF
50V 5%
C615 2113944A40 CAP CER CHP 100.0PF
50V 5%
C616 2113944A40 CAP CER CHP 100.0PF
50V 5%
C618 2113944A40 CAP CER CHP 100.0PF
50V 5%
C619 2113944A40 CAP CER CHP 100.0PF
50V 5%
C620 2113944A40 CAP CER CHP 100.0PF
50V 5%
C621 2113944A40 CAP CER CHP 100.0PF
50V 5%
C622 2113944A40 CAP CER CHP 100.0PF
50V 5%
CR101 4880973Z02 PIN DIODE
CR102 4815257H01 SURFACE MOUNT PIN
DIODES
CR103 4815257H01 SURFACE MOUNT PIN
DIODES
CR105 5115022H01 IC TEMPERATURE
SENSOR
CR160 NOTPLACE
D
GCAM DUMMY PART
NUMBER
CR201 4815011H01 DIODE TRIPLE
CR203 4815072H01 DIODE VARACTOR
CR241 4885094Y01 DIODE VARACTOR ISV228
W18
CR242 4815279H01 BBY5503WE6327 FROM
INFINEON
CR243 4815279H01 BBY5503WE6327 FROM
INFINEON
CR251 4815322H01 VHF VARIABLE
CAPACITANCE DIODE
Circuit
Ref
Motorola
Part No.
Description

Motorola GP series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Number of Channels	16
Channel Spacing	12.5 kHz / 25 kHz
Battery Life	8 hours (with standard battery)
Operating Voltage	7.5V DC
Ingress Protection	IP54
MIL-STD	810 C, D, E, F
