Motorola GP series Detailed Service Manual

UHF PCB 8415234H08 Parts List 3-141
CR301 4815279H01 BBY5503WE6327 FROM
INFINEON
CR302 4815279H01 BBY5503WE6327 FROM
INFINEON
CR303 4815048H01 SOT MMBD353 DIODE
DUAL SCHT
CR304 4815279H01 BBY5503WE6327 FROM
INFINEON
CR305 4815279H01 BBY5503WE6327 FROM
INFINEON
CR306 4815923H02 SCHOTTKY DIODE-NEW
LEADFREE
CR311 4813974A19 DIODE
ARRAY,MXR,SM,SOT-
323,7V,
CR312 4815047H01 BAND SWITCHIND
DIODE,ROHM DAN
CR313 4815047H01 BAND SWITCHIND
DIODE,ROHM DAN
CR411 4815067H01 DIODE SCHOTTKY,
RB731U
CR412 4815067H01 DIODE SCHOTTKY,
RB731U
CR413 4815067H01 DIODE SCHOTTKY,
RB731U
CR440 4813978C02 PB FREE, NOT
COMPLETELY ENRICH
CR501 4815155H01 RECTIFIER
CR503 4805729G49 DIODE RED/YEL
D601 4880479U01 LED
D602 4880479U01 LED
D603 4880479U01 LED
D604 4880479U01 LED
D605 4880479U01 LED
D606 4880479U01 LED
E101 2415954H01 INDUCTOR BEAD CHIP
Circuit
Ref
Motorola
Part No.
Description
E102 7686949J14 FLTR,FERRITE
BEAD,2A,SM
E105 7686949J14 FLTR,FERRITE
BEAD,,,,2A,,,,,SM,0805
E106 7686949J15 FLTR, FERR,,,, 2A,,,, SM,
0603
E107 7686949J15 FLTR, FERR,,,, 2A,,,, SM,
0603
E400 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E401 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E402 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E403 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E404 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E405 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E406 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E407 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E408 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E409 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E634 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E637 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E638 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E639 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E640 2480640Z01 SURFACE MOUNT
FERRITE BEAD
Circuit
Ref
Motorola
Part No.
Description
E641 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E642 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E643 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E644 2480640Z01 SURFACE MOUNT
FERRITE BEAD
E645 2480640Z01 SURFACE MOUNT
FERRITE BEAD
F501 6515076H01 FUSE CHIP SMT TR/
1608FF 3A
FL201 4805875Z04 CRYSTAL 16.8 MHZ
FL301 9180022M11 XTAL FILTER 44.85MHZ
FL302 9180468V04 SMD455KHZ 4 ELEMENT
CER FLTR
FL303 9115811H03 SMD455KHZ 6 ELEMENT
FL304 9115811H01 SMD455KHZ 6 ELEMENT
FL401 4870368G02 REFLOWABLE CLOCK
OSC XTAL
H101 2680499Z02 HEAT SPREADER
J101 0985613Z01 JACK, RF
J102 0280519Z06 NUT, ANTENNA
J400 0915064H03 CONNECTOR, ZIF (40
PINS)
J403 0915064H02 ZIF (20 PINS)
J601 0980521Z03 CONN, ZIF VERTICAL,
40PINS
J602 0915064H01 ZIF (18 PINS)
L101 2460591C16 COIL AIR WOUND INDUC
16.28NH
L102 2460591C40 COIL AIR WOUND INDUC
17.02NH
L104 2479990B02 AIR WOUND COIL/GREEN
COLOR 19.
Circuit
Ref
Motorola
Part No.
Description
L105 2414032B22 IDCTR,WW,390NH,10%,62
0MA,1.12O
L106 2479990A02 AIR WND COIL/GREEN
COLOR7.66NH
L107 2479990G01 AIR WOUND COIL/GREEN
COLOR 33.
L108 2479990A01 AIR WOUND COIL/GREEN
COLOR 4.2
L109 2479990B01 AIR WOUND COIL/GREEN
COLOR 11.
L112 2414032B45 IDCTR,WW,22NH,5%,1A,.1
2OHM,CER
L113 2414017N09 IDCTR,CHIP,5.6NH,600MA,
.2OHM,C
L114 2414032B45 IDCTR,WW,22NH,5%,1A,.1
2OHM,CER
L115 2414032B22 IDCTR,WW,390NH,10%,62
0MA,1.12O
L116 2479990A03 AIR WOUND COIL/GREEN
COLOR 9.7
L160 2414017N14 IDCTR,CHIP,15NH,5%,600
MA,.4OHM
L201 2414017Q20 IDCTR,FXD,2.2UH,20%,30
MA,.65OH
L202 2414017Q20 IDCTR,FXD,2.2UH,20%,30
MA,.65OH
L203 2414017Q20 IDCTR,FXD,2.2UH,20%,30
MA,.65OH
L232 2414032L25 IDCTR,WW,12UH,5%,150M
A,3.8OHM,
L241 2414032F41 IDCTR,WW,390NH,10%,20
0MA,1.5OH
L242 2414032F38 IDCTR,WW,220NH,5%,400
MA,.7OHM,
L243 2485776Z01 COIL TEFLON
RESONATOR (KAPTON)
L251 2414032F28 IDCTR,WW,33NH,5%,500M
A,.27OHM,
Circuit
Ref
Motorola
Part No.
Description

Motorola GP series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Number of Channels	16
Channel Spacing	12.5 kHz / 25 kHz
Battery Life	8 hours (with standard battery)
Operating Voltage	7.5V DC
Ingress Protection	IP54
MIL-STD	810 C, D, E, F
