Motorola GP series Detailed Service Manual

3-142 UHF PCB 8415234H08 Parts List
L253 2460593C02 COIL MULT LAYERED TAP
TEF RESN
L261 2414032F29 IDCTR,WW,39NH,5%,500M
A,.29OHM,
L271 2414032F32 IDCTR,WW,68NH,5%,500M
A,.38OHM,
L273 2414032F28 IDCTR,WW,33NH,5%,500M
A,.27OHM,
L281 2414032F41 IDCTR,WW,390NH,10%,20
0MA,1.5OH
L282 2414032F41 IDCTR,WW,390NH,10%,20
0MA,1.5OH
L301 2479990C01 AIR WND COIL/GREEN
COLOR13.9NH
L302 2479990C01 AIR WND COIL/GREEN
COLOR13.9NH
L303 2414032F26 IDCTR,WW,22NH,5%,500M
A,.22OHM,
L304 2414032F37 IDCTR,WW,180NH,5%,400
MA,.64OHM
L305 2414032F26 IDCTR,WW,22NH,5%,500M
A,.22OHM,
L306 2479990C01 AIR WND COIL/GREEN
COLOR13.9NH
L307 2479990C01 AIR WND COIL/GREEN
COLOR13.9NH
L309 2479990C02 AIR WOUND COIL/GREEN
COLOR 16.
L310 2414032F36 IDCTR,WW,150NH,5%,400
MA,.56OHM
L311 2414017K32 IDCTR,CHIP,560NH,5%,50
MA,5OHM,
L321 2414032F37 IDCTR,WW,180NH,5%,400
MA,.64OHM
L325 2414032B68 IDCTR,WW,1UH,5%,460M
A,1.75OHM,
L330 0613958J74 CER CHIP RES 0.0 OHM
JMP 0805
Circuit
Ref
Motorola
Part No.
Description
L331 2414017K33 IDCTR,CHIP,680NH,5%,50
MA,5.5OH
L332 2414015A25 IDCTR,CHIP,1.2UH,2%,440
MA,2OHM
L400 2414017Q42 IDCTR,FXD,390NH,10%,20
0MA,.65O
L401 2414017Q42 IDCTR,FXD,390NH,10%,20
0MA,.65O
L410 2414017Q42 IDCTR,FXD,390NH,10%,20
0MA,.65O
L411 2414017Q42 IDCTR,FXD,390NH,10%,20
0MA,.65O
L505 2414017Q42 IDCTR,FXD,390NH,10%,20
0MA,.65O
M400 5085738Z10 SPEAKER, 20 OHM
M401 5015027H01 MIC, MINI ELECTRIC
P100 3905643V01 CONTACT ANT GRD
PB501 4086470Z01 TACT SWITCH
PB502 4086470Z01 TACT SWITCH
PB503 4086470Z01 TACT SWITCH
PB504 4086470Z01 TACT SWITCH
PB505 4086470Z01 TACT SWITCH
Q110 4813976A03 450MHZ 8W 7.5V PLD-1.5
T&R
Q111 4815055H01 TSTR DUAL NPN/PNP
UMH 5
Q210 4815055H01 TSTR DUAL NPN/PNP
UMH 5
Q241 4805218N63 RF TRANS SOT 323
BFQ67W
Q260 4815055H01 TSTR DUAL NPN/PNP
UMH 5
Q261 4815055H01 TSTR DUAL NPN/PNP
UMH 5
Q301 4816531H01 NPN SILICON BIPOLAR
TRANSISTOR
Circuit
Ref
Motorola
Part No.
Description
Q302 4802197J95 RF TRANSISTOR PBR941
Q310 4816531H01 NPN SILICON BIPOLAR
TRANSISTOR
Q320 4813973M07 XSTR,BIP GP
SS,,NPN,,TO-236,,,
Q400 4815069H02 TSTR MOSFET P-CHAN
Q403 4813973A13 XSTR,BIP GP
SS,,PNP,,TO-236,SO
Q405 4815066H01 UMG5N DIGITAL
TRANSISTOR
Q410 4815066H01 UMG5N DIGITAL
TRANSISTOR
Q416 4815069H02 TSTR MOSFET P-CHAN
Q417 4815055H01 TSTR DUAL NPN/PNP
UMH 5
Q502 4815154H01 DUAL TRANS NPN
Q505 4813973M07 XSTR,BIP GP
SS,,NPN,,TO-236,,,
Q601 4815125H01 SOT STR RH LOW
PROFILE MMBT
Q602 4813973M07 XSTR,BIP GP
SS,,NPN,,TO-236,,,
Q603 4813973M07 XSTR,BIP GP
SS,,NPN,,TO-236,,,
R101 0613952H58 CER CHIP RES 240 OHM 5
0603
R102 0615043C01 RES POWER METAL
STRIP W18 COMP
R103 0613952Q40 CER CHIP RES 43.0 OHM
5 0402
R104 0613952R17 CER CHIP RES 47K OHM
5% 0402
R106 0613952Q25 CER CHIP RES 10.0 OHM
5 0402
R107 NOTPLACE
D
GCAM DUMMY PART
NUMBER
Circuit
Ref
Motorola
Part No.
Description
R108 0613952Q91 CER CHIP RES 5600 OHM
5 0402
R109 0613952R32 CER CHIP RES 200K OHM
5 0402
R110 0613952Q60 CER CHIP RES 300 OHM 5
0402
R111 0613952Q32 CER CHIP RES 20.0 OHM
5 0402
R112 0613952Q60 CER CHIP RES 300 OHM 5
0402
R120 0613952R16 CER CHIP RES 43K OHM 5
0402
R130 0613952R01 CER CHIP RES 10K OHM
5% 0402
R131 0613952R07 CER CHIP RES 18K OHM
5% 0402
R132 0613952R35 CER CHIP RES 270K OHM
5% 0402
R133 NOTPLACE
D
GCAM DUMMY PART
NUMBER
R136 NOTPLACE
D
GCAM DUMMY PART
NUMBER
R161 0613952Q56 CER CHIP RES 200 OHM 5
0402
R170 0613952H58 CER CHIP RES 240 OHM 5
0603
R171 0613952R16 CER CHIP RES 43K OHM 5
0402
R172 0613952H49 CER CHIP RES 100 OHM
5% 0603
R173 0613952R31 CER CHIP RES 180K OHM
5% 0402
R174 0613952R17 CER CHIP RES 47K OHM
5% 0402
R175 0613952H12 CER CHIP RES 3.0 OHM 5
0603
R176 0613952H12 CER CHIP RES 3.0 OHM 5
0603
Circuit
Ref
Motorola
Part No.
Description

Motorola GP series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Number of Channels	16
Channel Spacing	12.5 kHz / 25 kHz
Battery Life	8 hours (with standard battery)
Operating Voltage	7.5V DC
Ingress Protection	IP54
MIL-STD	810 C, D, E, F
