Motorola GP series

UHF PCB 8415234H08 Parts List 3-143
R201 0613952R23 CER CHIP RES 82K OHM
5% 0402
R202 0613952R25 CER CHIP RES 100K OHM
5% 0402
R204 0613952R17 CER CHIP RES 47K OHM
5% 0402
R231 0613952Q51 CER CHIP RES 120 OHM 5
0402
R232 0613952Q68 CER CHIP RES 620 OHM 5
0402
R233 0613952Q67 CER CHIP RES 560 OHM 5
0402
R241 0613952Q31 CER CHIP RES 18.0 OHM
5 0402
R242 0613952Q56 CER CHIP RES 200 OHM 5
0402
R243 0613952R01 CER CHIP RES 10K OHM
5% 0402
R244 0613952R03 CER CHIP RES 12K OHM
5% 0402
R245 0613952Q58 CER CHIP RES 240 OHM 5
0402
R248 0613952Q36 CER CHIP RES 30.0 OHM
5 0402
R251 0613952Q31 CER CHIP RES 18.0 OHM
5 0402
R252 0613952Q61 CER CHIP RES 330 OHM 5
0402
R253 0613952Q94 CER CHIP RES 7500 OHM
5 0402
R254 0613952Q94 CER CHIP RES 7500 OHM
5 0402
R255 0613952Q88 CER CHIP RES 4300 OHM
5 0402
R256 0613952Q36 CER CHIP RES 30.0 OHM
5 0402
R260 0613952Q73 CER CHIP RES 1000 OHM
5 0402
Circuit
Ref
Motorola
Part No.
Description
R281 NOTPLACE
D
GCAM DUMMY PART
NUMBER
R301 0613952R25 CER CHIP RES 100K OHM
5% 0402
R302 0613952R25 CER CHIP RES 100K OHM
5% 0402
R303 0613952Q80 CER CHIP RES 2000 OHM
5 0402
R304 0613952R03 CER CHIP RES 12K OHM
5% 0402
R305 0613952Q66 CER CHIP RES 510 OHM 5
0402
R306 0613952R25 CER CHIP RES 100K OHM
5% 0402
R307 0613952R25 CER CHIP RES 100K OHM
5% 0402
R308 0613952Q42 CER CHIP RES 51.0 OHM
5 0402
R309 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R310 NOTPLACE
D
GCAM DUMMY PART
NUMBER
R311 0613952R13 CER CHIP RES 33K OHM
5% 0402
R312 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R313 0613952Q61 CER CHIP RES 330 OHM 5
0402
R314 0613952Q78 CER CHIP RES 1600 OHM
5 0402
R315 0613952R03 CER CHIP RES 12K OHM
5% 0402
R320 NOTPLACE
D
GCAM DUMMY PART
NUMBER
R321 0613952R15 CER CHIP RES 39K OHM
5% 0402
R322 0613952Q73 CER CHIP RES 1000 OHM
5 0402
Circuit
Ref
Motorola
Part No.
Description
R324 0613952R08 CER CHIP RES 20K OHM 5
0402
R328 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R329 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R330 0613952R01 CER CHIP RES 10K OHM
5% 0402
R331 0613952Q56 CER CHIP RES 200 OHM 5
0402
R332 0613952R03 CER CHIP RES 12K OHM
5% 0402
R333 NOTPLACE
D
GCAM DUMMY PART
NUMBER
R339 0613952Q88 CER CHIP RES 4300 OHM
5 0402
R340 0613952Q94 CER CHIP RES 7500 OHM
5 0402
R342 0613952R25 CER CHIP RES 100K OHM
5% 0402
R344 0613952Q42 CER CHIP RES 51.0 OHM
5 0402
R345 0613952R15 CER CHIP RES 39K OHM
5% 0402
R346 0613952R05 CER CHIP RES 15K OHM
5% 0402
R348 0613952Q86 CER CHIP RES 3600 OHM
5 0402
R349 0613958J74 CER CHIP RES 0.0 OHM
JMP 0805
R350 0613952Q85 CER CHIP RES 3300 OHM
5 0402
R355 0613952R25 CER CHIP RES 100K OHM
5% 0402
R358 0613952Q82 CER CHIP RES 2400 OHM
5 0402
R359 NOTPLACE
D
GCAM DUMMY PART
NUMBER
Circuit
Ref
Motorola
Part No.
Description
R360 0613952R08 CER CHIP RES 20K OHM 5
0402
R361 0613952R08 CER CHIP RES 20K OHM 5
0402
R363 0613952Q63 CER CHIP RES 390 OHM 5
0402
R364 0613952Q79 CER CHIP RES 1800 OHM
5 0402
R365 0613952Q75 CER CHIP RES 1200 OHM
5 0402
R366 0613952R03 CER CHIP RES 12K OHM
5% 0402
R367 0613952N09 CER CHIP RES 12.1K OHM
1 0402
R368 0613952N01 CER CHIP RES 10.0K OHM
1 0402
R369 0613952Q69 CER CHIP RES 680 OHM 5
0402
R370 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R371 NOTPLACE
D
GCAM DUMMY PART
NUMBER
R372 NOTPLACE
D
GCAM DUMMY PART
NUMBER
R373 NOTPLACE
D
GCAM DUMMY PART
NUMBER
R374 NOTPLACE
D
GCAM DUMMY PART
NUMBER
R375 NOTPLACE
D
GCAM DUMMY PART
NUMBER
R376 NOTPLACE
D
GCAM DUMMY PART
NUMBER
R377 NOTPLACE
D
GCAM DUMMY PART
NUMBER
R378 NOTPLACE
D
GCAM DUMMY PART
NUMBER
R400 0613952R17 CER CHIP RES 47K OHM
5% 0402
Circuit
Ref
Motorola
Part No.
Description
