Motorola GP series - Page 319

UHF Narrow Band PCB 8415234H05 Parts List 3-175
C348 2113946K02 CAP CER CHP 0.10UF 16V
C349 2113945D04 CAP CER CHP 100,000PF
25V 10%
C350 2113946K02 CAP CER CHP 0.10UF 16V
C351 2113944A41 CAP CER CHP 120.0PF
50V 5%
C352 2113946K02 CAP CER CHP 0.10UF 16V
C355 2113946K02 CAP CER CHP 0.10UF 16V
C357 2113946K02 CAP CER CHP 0.10UF 16V
C358 NOTPLACED GCAM DUMMY PART
NUMBER
C359 NOTPLACED GCAM DUMMY PART
NUMBER
C360 2113944A13 CAP CER CHP 3.3PF 50V
+/- 0.25
C361 2113946K02 CAP CER CHP 0.10UF 16V
C362 2113946K02 CAP CER CHP 0.10UF 16V
C364 2113944A81 CAP,FXD,24PF,+5%,-5%,
50V-DC,04
C366 NOTPLACED GCAM DUMMY PART
NUMBER
C367 2113944A82 CAP,FXD,30PF,+5%,-5%,
50V-DC,04
C370 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25
C371 NOTPLACED GCAM DUMMY PART
NUMBER
C372 2113944A40 CAP CER CHP 100.0PF
50V 5%
C373 NOTPLACED GCAM DUMMY PART
NUMBER
C374 2113944A40 CAP CER CHP 100.0PF
50V 5%
C375 2113944A40 CAP CER CHP 100.0PF
50V 5%
Circuit
Ref
Motorola
Part No.
Description
C378 NOTPLACED GCAM DUMMY PART
NUMBER
C380 2113945B02 CAP CER CHP 10,000PF
25V 10%
C381 NOTPLACED GCAM DUMMY PART
NUMBER
C382 2313960B57 CAP,FXD,10UF,+10%,
-10%,6.3V-DC
C383 NOTPLACED GCAM DUMMY PART
NUMBER
C385 2113944A82 CAP,FXD,30PF,+5%,-5%,
50V-DC,04
C386 2113944A40 CAP CER CHP 100.0PF
50V 5%
C390 NOTPLACED GCAM DUMMY PART
NUMBER
C391 2113944A81 CAP,FXD,24PF,+5%,-5%,
50V-DC,04
C400 2113945B02 CAP CER CHP 10,000PF
25V 10%
C401 2113946K02 CAP CER CHP 0.10UF 16V
C402 2113946K02 CAP CER CHP 0.10UF 16V
C403 2113955D33 CAP,FXD,2.2UF,+10%,
-10%, 16V-DC
C404 NOTPLACED GCAM DUMMY PART
NUMBER
C405 2113944A40 CAP CER CHP 100.0PF
50V 5%
C406 NOTPLACED GCAM DUMMY PART
NUMBER
C407 2113946B04 CAP CER CHP 0.10UF 10V
10%
C408 2113944A40 CAP CER CHP 100.0PF
50V 5%
C409 2113946K02 CAP CER CHP 0.10UF 16V
C410 2113946B04 CAP CER CHP 0.10UF 10V
10%
Circuit
Ref
Motorola
Part No.
Description
C411 2113946K02 CAP CER CHP 0.10UF 16V
C414 2113946K02 CAP CER CHP 0.10UF 16V
C415 2185895Z01 CAPACITOR CER LOW
DIST .01UF
C416 2113946B04 CAP CER CHP 0.10UF 10V
10%
C419 NOTPLACED GCAM DUMMY PART
NUMBER
C420 2113945B02 CAP CER CHP 10,000PF
25V 10%
C421 2113946B04 CAP CER CHP 0.10UF 10V
10%
C422 2113946K02 CAP CER CHP 0.10UF 16V
C423 2113944A40 CAP CER CHP 100.0PF
50V 5%
C424 NOTPLACED GCAM DUMMY PART
NUMBER
C425 2113946K02 CAP CER CHP 0.10UF 16V
C426 2113944A40 CAP CER CHP 100.0PF
50V 5%
C427 2113944A40 CAP CER CHP 100.0PF
50V 5%
C428 2113946K02 CAP CER CHP 0.10UF 16V
C429 2113946K02 CAP CER CHP 0.10UF 16V
C430 2113946B04 CAP CER CHP 0.10UF 10V
10%
C431 2113944A40 CAP CER CHP 100.0PF
50V 5%
C432 NOTPLACED GCAM DUMMY PART
NUMBER
C433 2113945B02 CAP CER CHP 10,000PF
25V 10%
C434 2113946B04 CAP CER CHP 0.10UF 10V
10%
C435 2113946K02 CAP CER CHP 0.10UF 16V
Circuit
Ref
Motorola
Part No.
Description
C436 2113944A29 CAP CER CHP 22.0PF 50V
5%
C437 2113944A29 CAP CER CHP 22.0PF 50V
5%
C440 2113946Q01 CAP CER CHP 4.7UF 16V
C441 2113944A40 CAP CER CHP 100.0PF
50V 5%
C442 2113945D04 CAP CER CHP 100,000PF
25V 10%
C443 2113946B04 CAP CER CHP 0.10UF 10V
10%
C444 2113944A40 CAP CER CHP 100.0PF
50V 5%
C445 2113944A40 CAP CER CHP 100.0PF
50V 5%
C447 2113945B04 CAP,FXD,.022UF,+10%,
-10%,25V-D
C448 2113946B04 CAP CER CHP 0.10UF 10V
10%
C449 2113944A40 CAP CER CHP 100.0PF
50V 5%
C450 NOTPLACED GCAM DUMMY PART
NUMBER
C451 2113945B04 CAP,FXD,.022UF,+10%,
-10%,25V-D
C452 2113955D31 CAP,FXD,1UF,+10%,-10%,
16V-DC,1
C453 2113944A40 CAP CER CHP 100.0PF
50V 5%
C456 2113944A40 CAP CER CHP 100.0PF
50V 5%
C458 2113944A40 CAP CER CHP 100.0PF
50V 5%
C459 2113944A40 CAP CER CHP 100.0PF
50V 5%
C463 2113944A40 CAP CER CHP 100.0PF
50V 5%
Circuit
Ref
Motorola
Part No.
Description
