3-176 UHF Narrow Band PCB 8415234H05 Parts List
C466 2113944A40 CAP CER CHP 100.0PF
50V 5%
C467 2113946B04 CAP CER CHP 0.10UF 10V
10%
C471 2113944A40 CAP CER CHP 100.0PF
50V 5%
C472 2113945A05 CAP CER CHP 470PF 50V
10%
C473 2113945A05 CAP CER CHP 470PF 50V
10%
C475 2113956E91 CAP,FXD,10UF,+10%,-
10%,16V-DC,
C476 2113946R01 CAP CER CHP 10.0UF 10V
C479 2113946B04 CAP CER CHP 0.10UF 10V
10%
C480 2113946R01 CAP CER CHP 10.0UF 10V
C481 2113946B04 CAP CER CHP 0.10UF 10V
10%
C482 2113946B04 CAP CER CHP 0.10UF 10V
10%
C490 2113944A40 CAP CER CHP 100.0PF
50V 5%
C491 2113944A40 CAP CER CHP 100.0PF
50V 5%
C492 2113944A40 CAP CER CHP 100.0PF
50V 5%
C493 2113944A40 CAP CER CHP 100.0PF
50V 5%
C494 2113944A40 CAP CER CHP 100.0PF
50V 5%
C495 2113944A40 CAP CER CHP 100.0PF
50V 5%
C496 2113944A40 CAP CER CHP 100.0PF
50V 5%
C497 2113944A40 CAP CER CHP 100.0PF
50V 5%
Circuit
Ref
Motorola
Part No.
Description
C498 NOTPLACED GCAM DUMMY PART
NUMBER
C498 NOTPLACED GCAM DUMMY PART
NUMBER
C499 2113946B04 CAP CER CHP 0.10UF 10V
10%
C502 2313960A55 CAP,FXD,.47UF,+10%,
-10%,25V-DC
C503 2113944A84 CAP,FXD,43PF,+5%,-5%,
50V-DC,04
C505 2113944A40 CAP CER CHP 100.0PF
50V 5%
C511 2113944A40 CAP CER CHP 100.0PF
50V 5%
C512 2113944A40 CAP CER CHP 100.0PF
50V 5%
C513 2113944A40 CAP CER CHP 100.0PF
50V 5%
C514 2113944A40 CAP CER CHP 100.0PF
50V 5%
C520 2113945B02 CAP CER CHP 10,000PF
25V 10%
C521 2113945B02 CAP CER CHP 10,000PF
25V 10%
C522 2113945B02 CAP CER CHP 10,000PF
25V 10%
C523 2113945B02 CAP CER CHP 10,000PF
25V 10%
C524 2113944A40 CAP CER CHP 100.0PF
50V 5%
C525 2113944A40 CAP CER CHP 100.0PF
50V 5%
C526 2113944A40 CAP CER CHP 100.0PF
50V 5%
C527 2113944A40 CAP CER CHP 100.0PF
50V 5%
C528 2113944A40 CAP CER CHP 100.0PF
50V 5%
Circuit
Ref
Motorola
Part No.
Description
C529 2113944A40 CAP CER CHP 100.0PF
50V 5%
C597 2113944A84 CAP,FXD,43PF,+5%,-5%,
50V-DC,04
C598 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25
C599 2113944A15 CAP CER CHP 3.9PF 50V
+/- 0.25
C600 2113944A81 CAP,FXD,24PF,+5%,-5%,
50V-DC,04
C601 2113944A40 CAP CER CHP 100.0PF
50V 5%
C602 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25
CR101 4880973Z02 PIN DIODE
CR102 4815257H01 SURFACE MOUNT PIN
DIODES
CR103 4815257H01 SURFACE MOUNT PIN
DIODES
CR105 5115022H01 IC TEMPERATURE SEN-
SOR
CR160 NOTPLACED GCAM DUMMY PART
NUMBER
CR201 4815011H01 DIODE TRIPLE
CR203 4815072H01 DIODE VARACTOR
CR241 4885094Y01 DIODE VARACTOR
ISV228 W18
CR242 4815279H01 BBY5503WE6327 FROM
INFINEON
CR243 4815279H01 BBY5503WE6327 FROM
INFINEON
CR251 4815322H01 VHF VARIABLE
CAPACITANCE DIODE
CR301 4815279H01 BBY5503WE6327 FROM
INFINEON
CR302 4815279H01 BBY5503WE6327 FROM
INFINEON
Circuit
Ref
Motorola
Part No.
Description
CR303 4815048H01 SOT MMBD353 DIODE
DUAL SCHT
CR304 4815279H01 BBY5503WE6327 FROM
INFINEON
CR305 4815279H01 BBY5503WE6327 FROM
INFINEON
CR306 4815923H02 SCHOTTKY DIODE-NEW
LEADFREE
CR311 4813974A19 DIODE
ARRAY,MXR,SM,SOT-
323,7V,
CR312 4815047H01 BAND SWITCHIND
DIODE,ROHM DAN
CR313 4815047H01 BAND SWITCHIND
DIODE,ROHM DAN
CR411 4815067H01 DIODE SCHOTTKY,
RB731U
CR412 4815067H01 DIODE SCHOTTKY,
RB731U
CR413 4815067H01 DIODE SCHOTTKY,
RB731U
CR440 4813978C02 PB FREE, NOT COM-
PLETELY ENRICH
CR501 4815155H01 RECTIFIER
CR503 4805729G49 DIODE RED/YEL
E101 2415954H01 INDUCTOR BEAD CHIP
E102 7686949J14 FLTR,FERRITE
BEAD,2A,SM
E105 7686949J14 FLTR,FERRITE
BEAD,2A,SM
E400 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E401 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E402 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
Circuit
Ref
Motorola
Part No.
Description
