Motorola GP series Detailed Service Manual

UHF2 PCB 8415235H01 Parts List 3-75
C463 2113944A40 CAP CER CHP 100.0PF 50V
5%
C466 2113944A40 CAP CER CHP 100.0PF 50V
5%
C467 2113946B04 CAP CER CHP 0.10UF 10V
10%
C471 2113944A40 CAP CER CHP 100.0PF 50V
5%
C472 2113945A05 CAP CER CHP 470PF 50V
10%
C473 2113945A05 CAP CER CHP 470PF 50V
10%
C475 2113743H14 CAP CHIP 10.0 UF 16V +80-
20%
C476 2113946R01 CAP CER CHP 10.0UF 10V
C479 2113946B04 CAP CER CHP 0.10UF 10V
10%
C480 2113946R01 CAP CER CHP 10.0UF 10V
C481 2113946B04 CAP CER CHP 0.10UF 10V
10%
C482 2113946B04 CAP CER CHP 0.10UF 10V
10%
C490 2113944A40 CAP CER CHP 100.0PF 50V
5%
C491 2113944A40 CAP CER CHP 100.0PF 50V
5%
C492 2113944A40 CAP CER CHP 100.0PF 50V
5%
C493 2113944A40 CAP CER CHP 100.0PF 50V
5%
C494 2113944A40 CAP CER CHP 100.0PF 50V
5%
C495 2113944A40 CAP CER CHP 100.0PF 50V
5%
C496 2113944A40 CAP CER CHP 100.0PF 50V
5%
C497 2113944A40 CAP CER CHP 100.0PF 50V
5%
C498 NOTPLACED -
C499 2113946B04 CAP CER CHP 0.10UF 10V
10%
C502 2313960A55 CAP TANT 0.47 UF 10% 25V
3216-18
C503 2113944A40 CAP CER CHP 100.0PF 50V
5%
C505 2113944A40 CAP CER CHP 100.0PF 50V
5%
C511 2113944A40 CAP CER CHP 100.0PF 50V
5%
C512 2113944A40 CAP CER CHP 100.0PF 50V
5%
Circuit
Ref
Motorola
Part No.
Description
C513 2113944A40 CAP CER CHP 100.0PF 50V
5%
C514 2113944A40 CAP CER CHP 100.0PF 50V
5%
C520 2113945B02 CAP CER CHP 10,000PF 25V
10%
C521 2113945B02 CAP CER CHP 10,000PF 25V
10%
C522 2113945B02 CAP CER CHP 10,000PF 25V
10%
C523 2113945B02 CAP CER CHP 10,000PF 25V
10%
C524 2113944A40 CAP CER CHP 100.0PF 50V
5%
C525 2113944A40 CAP CER CHP 100.0PF 50V
5%
C526 2113944A40 CAP CER CHP 100.0PF 50V
5%
C527 2113944A40 CAP CER CHP 100.0PF 50V
5%
C528 2113944A40 CAP CER CHP 100.0PF 50V
5%
C529 2113944A40 CAP CER CHP 100.0PF 50V
5%
C610 2113944A40 CAP CER CHP 100.0PF 50V
5%
C611 2113944A40 CAP CER CHP 100.0PF 50V
5%
C612 2113944A40 CAP CER CHP 100.0PF 50V
5%
C613 2113944A40 CAP CER CHP 100.0PF 50V
5%
C615 2113944A40 CAP CER CHP 100.0PF 50V
5%
C616 2113944A40 CAP CER CHP 100.0PF 50V
5%
C618 2113944A40 CAP CER CHP 100.0PF 50V
5%
C619 2113944A40 CAP CER CHP 100.0PF 50V
5%
C620 2113944A40 CAP CER CHP 100.0PF 50V
5%
C621 2113944A40 CAP CER CHP 100.0PF 50V
5%
C622 2113944A40 CAP CER CHP 100.0PF 50V
5%
CR101 4880973Z02 PIN DIODE
CR102 4815257H01 SURFACE MOUNT PIN
DIODES
CR103 4815257H01 SURFACE MOUNT PIN
DIODES
Circuit
Ref
Motorola
Part No.
Description
CR105 5115022H01 IC,TEMP
SENS,LM50C,SM,SOT-23
CR160 NOTPLACED -
CR201 4815011H01 DIODE,SWG,300MA,80V
CR203 4815072H01 DIODE,VCTR,1SV232,30V
CR241 4885094Y01 DIODE VARACTOR ISV228
W18
CR242 4885055Y01 DIODE VARACTOR PB-FREE
CR243 4885055Y01 DIODE VARACTOR PB-FREE
CR251 4815322H01 VHF VARIABLE CAPACI-
TANCE DIODE
CR301 4885055Y01 DIODE VARACTOR PB-FREE
CR302 4885055Y01 DIODE VARACTOR PB-FREE
CR303 4815048H01 DIODE,SHTK,MMBD353LT1,
SM,7V
CR304 4885055Y01 DIODE VARACTOR PB-FREE
CR305 4885055Y01 DIODE VARACTOR PB-FREE
CR306 4802245J42 RING QUAD DIODE SOT-143
PKG
CR311 4813974A19 DIODE SCHOTTKY BAR-
RIER SERIES
CR312 4815047H01 DIODE,SWG,DAN235EFTL,3
5V
CR313 4815047H01 DIODE,SWG,DAN235EFTL,3
5V
CR411 4815067H01 DIODE
ARRAY,SWG,RB731UFT108,
SMD,1M
CR412 4815067H01 DIODE
ARRAY,SWG,RB731UFT108,
SMD,1M
CR413 4815067H01 DIODE
ARRAY,SWG,RB731UFT108,
SMD,1M
CR440 4813978C02 PB FREE, NOT COM-
PLETELY ENRICHED
CR501 4815155H01 RECTIFIER
CR503 4805729G49 DIODE RED/YEL
D601 4880479U01 LED
D602 4880479U01 LED
D603 4880479U01 LED
D604 4880479U01 LED
D605 4880479U01 LED
D606 4880479U01 LED
E101 2415954H01 INDUCTOR BEAD CHIP
E400 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E401 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E402 2480640Z01 SURFACE MOUNT FERRITE
BEAD
Circuit
Ref
Motorola
Part No.
Description
E403 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E404 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E405 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E406 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E407 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E408 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E409 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E634 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E637 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E638 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E639 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E640 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E641 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E642 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E643 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E644 2480640Z01 SURFACE MOUNT FERRITE
BEAD
E645 2480640Z01 SURFACE MOUNT FERRITE
BEAD
F501 6515076H01 FUSE,FST
BLW,3A,24V,FUSE CHIP SMT
T
FL201 4805875Z04 CRYSTAL 16.8 MHZ
FL301 9180022M11 XTAL FILTER 44.85MHZ
FL302 9180468V05 SMD455KHZ 4 ELEMENT
CER FLTR
FL303 9115811H03 SMD455KHZ 6 ELEMENT
FL304 9115811H01 SMD455KHZ 6 ELEMENT
FL401 4870368G02 REFLOWABLE CLOCK OSC
XTAL
H101 2680499Z02 HEAT SPREADER
J101 0985613Z01 JACK,RF
J102 0280519Z02 NUT, ANTENNA
J400 0915064H03 CONNECTOR, ZIF (40 PINS)
J403 0915064H02 CONN,CONN,F,20CONT,CO
NNECTOR, ZIF
Circuit
Ref
Motorola
Part No.
Description

Motorola GP series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Number of Channels	16
Channel Spacing	12.5 kHz / 25 kHz
Battery Life	8 hours (with standard battery)
Operating Voltage	7.5V DC
Ingress Protection	IP54
MIL-STD	810 C, D, E, F
