Motorola GP series Detailed Service Manual

3-76 UHF2 PCB 8415235H01 Parts List
J601 0980521Z03 CONN, ZIF VERTICAL,
40PINS
J602 0915064H01 CONN,CONN,F,18CONT,CO
NNECTOR, ZIF
L101 2460591B28 COIL AIR WOUND INDUC
13.37
L102 2460591B28 COIL AIR WOUND INDUC
13.37
L104 2460591B48 COIL AIR WOUND INDUC
15.22
L105 2462587N22 CHIP IND 390 NH 10%
L106 2460591A19 COIL AIR WOUND INDUC
8.71
L107 2479990G01 AIR WOUND COIL/GREEN
COLOR 33.47NH
L108 2479990A01 AIR WOUND COIL/GREEN
COLOR 4.22NH
L112 2462587N42 CHIP IND 12 NH 5%
L113 2414017H09 IND CHIP 5.6 NH +/- 0.3NH
L114 2462587N42 CHIP IND 12 NH 5%
L115 2462587N22 CHIP IND 390 NH 10%
L116 2479990C02 AIR WOUND COIL/GREEN
COLOR 16.28NH
L117 2414017P17 IND CER CHIP 22.0 NH 5%
L160 2414017H14 IND CHIP 15.0 NH 5%
L201 2462587Q20 IND CHIP 2,200NH 20%
L202 2462587Q20 IND CHIP 2,200NH 20%
L203 2462587Q20 IND CHIP 2,200NH 20%
L232 2415844H01 CHIP IND 12000 NH 5%
L241 2462587V41 IND CHIP 390 NH 10%
L242 2462587V26 CHIP IND 22 NH 5% 0805
L243 2485776Z02 COIL TEFLON RESONATOR
(KAPTON)
L251 2462587V41 IND CHIP 390 NH 10%
L253 2460593C03 COIL MULT LAYERED TAP
TEF RESN
L261 2462587V29 CHIP IND 39 NH 5% 0805
L271 2415043H01 FIXED INDUC-
TOR,RF,27NH,5%,CER,
L273 2415043H03 FIXED INDUC-
TOR,RF,68NH,5%,CER,
L281 2462587V41 IND CHIP 390 NH 10%
L282 2462587V41 IND CHIP 390 NH 10%
L301 2479990B01 AIR WOUND COIL/GREEN
COLOR 11.03NH
L302 2479990B01 AIR WOUND COIL/GREEN
COLOR 11.03NH
L303 2462587V26 CHIP IND 22 NH 5% 0805
L304 2462587V37 CHIP IND 180 NH 5% 0805
L305 2462587V23 CHIP IND 12 NH 5% 0805
Circuit
Ref
Motorola
Part No.
Description
L306 2479990B01 AIR WOUND COIL/GREEN
COLOR 11.03NH
L307 2479990B01 AIR WOUND COIL/GREEN
COLOR 11.03NH
L309 2479990C02 AIR WOUND COIL/GREEN
COLOR 16.28NH
L310 2462587V36 CHIP IND 150NH 5% 0805
L311 2414017K32 IND CER CHIP 560.0 NH 5%
L321 2462587V37 CHIP IND 180 NH 5% 0805
L325 2462587N68 CHIP IND 1000 NH 5%
L330 2414017K33 IND CER CHIP 680.0 NH 5%
L332 2414015A25 IDCTR,CHIP,1.2UH,2%,440M
A,2OHM,CER,
L400 2462587Q42 IND CHIP 390NH 10%
L401 2462587Q42 IND CHIP 390NH 10%
L410 2462587Q42 IND CHIP 390NH 10%
L411 2462587Q42 IND CHIP 390NH 10%
L505 2462587Q42 IND CHIP 390NH 10%
P100 3905643V01 CONTACT ANT GRD
PB501 4086470Z01 TACT SWITCH
PB502 4086470Z01 TACT SWITCH
PB503 4086470Z01 TACT SWITCH
PB504 4086470Z01 TACT SWITCH
PB505 4086470Z01 TACT SWITCH
Q110 4813976A03 TSTR, 450 MHZ, 8W, 7.5V,
PLD 1.5
Q111 4815055H01 XSTR,GEN PURPOSE
SMALL SIG,NPN AND
Q210 4815055H01 XSTR,GEN PURPOSE
SMALL SIG,NPN AND
Q241 4805218N63 RF TRANS SOT 323
BFQ67W
Q260 4815055H01 XSTR,GEN PURPOSE
SMALL SIG,NPN AND
Q261 4815055H01 XSTR,GEN PURPOSE
SMALL SIG,NPN AND
Q301 4802245J44 NPN SILICON BIPOLAR
TRANSISTOR
Q302 4802197J95 RF TRANSISTOR PBR941
Q310 4802245J44 NPN SILICON BIPOLAR
TRANSISTOR
Q320 4813973M07 TSTR NPN 40V .2A GEN
PURP
Q400 4815069H02 TSTR MOSFET P-CHAN
Q403 4813973A13 XSTR,BIP GP SS,PNP,TO-
236,SOT-23,
Q405 4815066H01 XSTR,OTHR,UMG5NFTR,25
0MHZ
Q410 4815066H01 XSTR,OTHR,UMG5NFTR,25
0MHZ
Q416 4815069H02 TSTR MOSFET P-CHAN
Circuit
Ref
Motorola
Part No.
Description
Q417 4815055H01 XSTR,GEN PURPOSE
SMALL SIG,NPN AND
Q502 4815154H01 DUAL TRANS NPN
Q505 4813973M07 TSTR NPN 40V .2A GEN
PURP
Q601 4815125H01 SOT STR RH LOW PROFILE
MMBT
Q602 4813973M07 TSTR NPN 40V .2A GEN
PURP
Q603 4813973M07 TSTR NPN 40V .2A GEN
PURP
R101 0613952H58 CER CHIP RES 240 OHM 5%
0603
R102 0680539Z01 POWER METAL STRIP
RESISTORS
R104 0613952R17 CER CHIP RES 47K OHM 5%
0402
R106 0613952Q25 CER CHIP RES 10.0 OHM
5% 0402
R107 NOTPLACED -
R108 0613952Q91 CER CHIP RES 5600 OHM
5% 0402
R109 0613952R32 CER CHIP RES 200K OHM
5% 0402
R110 0613952Q60 CER CHIP RES 300 OHM 5%
0402
R111 0613952Q32 CER CHIP RES 20.0 OHM
5% 0402
R112 0613952Q60 CER CHIP RES 300 OHM 5%
0402
R120 0613952R16 CER CHIP RES 43K OHM 5%
0402
R130 0613952R01 CER CHIP RES 10K OHM 5%
0402
R131 0613952R07 CER CHIP RES 18K OHM 5%
0402
R132 0613952R35 CER CHIP RES 270K OHM
5% 0402
R133 NOTPLACED -
R136 NOTPLACED -
R161 0613952Q56 CER CHIP RES 200 OHM 5%
0402
R170 0613952H58 CER CHIP RES 240 OHM 5%
0603
R171 0613952R16 CER CHIP RES 43K OHM 5%
0402
R172 0613952H56 CER CHIP RES 200 OHM 5%
0603
R173 0613952R31 CER CHIP RES 180K OHM
5% 0402
Circuit
Ref
Motorola
Part No.
Description
R174 0613952R17 CER CHIP RES 47K OHM 5%
0402
R175 0613952H12 CER CHIP RES 3.0 OHM 5%
0603
R176 0613952H12 CER CHIP RES 3.0 OHM 5%
0603
R191 0613958J74 CER CHIP RES 0.0 OHM
JMP 0805
R201 0613952R23 CER CHIP RES 82K OHM 5%
0402
R202 0613952R25 CER CHIP RES 100K OHM
5% 0402
R204 0613952R17 CER CHIP RES 47K OHM 5%
0402
R231 0613952Q51 CER CHIP RES 120 OHM 5%
0402
R232 0613952Q68 CER CHIP RES 620 OHM 5%
0402
R233 0613952Q67 CER CHIP RES 560 OHM 5%
0402
R241 0613952Q33 CER CHIP RES 22.0 OHM
5% 0402
R242 0613952Q51 CER CHIP RES 120 OHM 5%
0402
R243 0613952R01 CER CHIP RES 10K OHM 5%
0402
R244 0613952R05 CER CHIP RES 15K OHM 5%
0402
R245 0613952Q58 CER CHIP RES 240 OHM 5%
0402
R248 0613952Q36 CER CHIP RES 30.0 OHM
5% 0402
R251 0613952Q37 CER CHIP RES 33.0 OHM
5% 0402
R252 0613952Q59 CER CHIP RES 270 OHM 5%
0402
R253 0613952Q94 CER CHIP RES 7500 OHM
5% 0402
R254 0613952Q95 CER CHIP RES 8200 OHM
5% 0402
R255 0613952Q88 CER CHIP RES 4300 OHM
5% 0402
R256 0613952Q36 CER CHIP RES 30.0 OHM
5% 0402
R260 0613952Q73 CER CHIP RES 1000 OHM
5% 0402
R281 NOTPLACED -
R301 0613952R25 CER CHIP RES 100K OHM
5% 0402
R302 0613952R25 CER CHIP RES 100K OHM
5% 0402
Circuit
Ref
Motorola
Part No.
Description

Motorola GP series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Number of Channels	16
Channel Spacing	12.5 kHz / 25 kHz
Battery Life	8 hours (with standard battery)
Operating Voltage	7.5V DC
Ingress Protection	IP54
MIL-STD	810 C, D, E, F
