Motorola GP series Detailed Service Manual

UHF2 PCB 8415235H01 Parts List 3-77
R303 0613952Q77 CER CHIP RES 1500 OHM
5% 0402
R304 0613952R03 CER CHIP RES 12K OHM 5%
0402
R305 0613952Q65 CER CHIP RES 470 OHM 5%
0402
R306 0613952R25 CER CHIP RES 100K OHM
5% 0402
R307 0613952R25 CER CHIP RES 100K OHM
5% 0402
R308 0613952Q42 CER CHIP RES 51.0 OHM
5% 0402
R309 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R310 NOTPLACED -
R311 0613952R13 CER CHIP RES 33K OHM 5%
0402
R312 0613952Q89 CER CHIP RES 4700 OHM
5% 0402
R313 0613952Q61 CER CHIP RES 330 OHM 5%
0402
R314 0613952Q78 CER CHIP RES 1600 OHM
5% 0402
R315 0613952R03 CER CHIP RES 12K OHM 5%
0402
R320 NOTPLACED -
R321 0613952R03 CER CHIP RES 12K OHM 5%
0402
R322 0613952Q73 CER CHIP RES 1000 OHM
5% 0402
R324 0613952R27 CER CHIP RES 120K OHM
5% 0402
R328 0613952Q11 CER CHIP RES 2.7 OHM 5%
0402
R329 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R330 0613952R01 CER CHIP RES 10K OHM 5%
0402
R331 0613952Q56 CER CHIP RES 200 OHM 5%
0402
R332 0613952R03 CER CHIP RES 12K OHM 5%
0402
R333 NOTPLACED -
R339 0613952Q88 CER CHIP RES 4300 OHM
5% 0402
R340 0613952Q95 CER CHIP RES 8200 OHM
5% 0402
R342 0613952R25 CER CHIP RES 100K OHM
5% 0402
R344 0613952Q42 CER CHIP RES 51.0 OHM
5% 0402
Circuit
Ref
Motorola
Part No.
Description
R345 0613952R15 CER CHIP RES 39K OHM 5%
0402
R346 0613952R05 CER CHIP RES 15K OHM 5%
0402
R348 0613952Q86 CER CHIP RES 3600 OHM
5% 0402
R349 0613958J74 CER CHIP RES 0.0 OHM
JMP 0805
R350 0613952R01 CER CHIP RES 10K OHM 5%
0402
R355 0613952R25 CER CHIP RES 100K OHM
5% 0402
R358 0613952Q73 CER CHIP RES 1000 OHM
5% 0402
R359 NOTPLACED -
R360 0613952R08 CER CHIP RES 20K OHM 5%
0402
R361 0613952R08 CER CHIP RES 20K OHM 5%
0402
R363 0613952Q63 CER CHIP RES 390 OHM 5%
0402
R364 0613952Q79 CER CHIP RES 1800 OHM
5% 0402
R365 0613952Q75 CER CHIP RES 1200 OHM
5% 0402
R366 0613952R03 CER CHIP RES 12K OHM 5%
0402
R367 0613952N09 CER CHIP RES 12.1K OHM
1% 0402
R368 0613952N01 CER CHIP RES 10.0K OHM
1% 0402
R369 0613952Q69 CER CHIP RES 680 OHM 5%
0402
R370 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R371 NOTPLACED -
R372 NOTPLACED -
R373 NOTPLACED -
R374 NOTPLACED -
R375 NOTPLACED -
R376 NOTPLACED -
R377 NOTPLACED -
R378 NOTPLACED -
R400 0613952R17 CER CHIP RES 47K OHM 5%
0402
R401 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R402 NOTPLACED -
R403 NOTPLACED -
R405 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
Circuit
Ref
Motorola
Part No.
Description
R406 0613952R22 CER CHIP RES 75K OHM 5%
0402
R407 0613952R21 CER CHIP RES 68K OHM 5%
0402
R408 NOTPLACED
R409 0613952R01 CER CHIP RES 10K OHM 5%
0402
R410 0613952R25 CER CHIP RES 100K OHM
5% 0402
R411 0613952R01 CER CHIP RES 10K OHM 5%
0402
R413 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R414 0613952P25 CER CHIP RES 178K OHM
1% 0402
R415 0613952N93 CER CHIP RES 90.9K OHM
1% 0402
R416 0613952R01 CER CHIP RES 10K OHM 5%
0402
R418 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R419 0613952Q66 CER CHIP RES 510 OHM 5%
0402
R420 0613952J73 CER CHIP RES 10.0M OHM
5% 0603
R421 0613952Q80 CER CHIP RES 2000 OHM
5% 0402
R423 0613952R41 CER CHIP RES 470K OHM
5% 0402
R424 0613952R14 CER CHIP RES 36K OHM 5%
0402
R425 0613952R12 CER CHIP RES 30K OHM 5%
0402
R426 0613952R37 CER CHIP RES 330K OHM
5% 0402
R427 0613952Q83 CER CHIP RES 2700 OHM
5% 0402
R428 0613952Q09 CER CHIP RES 2.2 OHM 5%
0402
R429 0613952R22 CER CHIP RES 75K OHM 5%
0402
R431 0613952R41 CER CHIP RES 470K OHM
5% 0402
R432 0613952R18 CER CHIP RES 51K OHM 5%
0402
R434 0613952Q61 CER CHIP RES 330 OHM 5%
0402
R435 0613952Q80 CER CHIP RES 2000 OHM
5% 0402
R436 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
Circuit
Ref
Motorola
Part No.
Description
R437 NOTPLACED -
R445 0613952R10 CER CHIP RES 24K OHM 5%
0402
R447 0613952R25 CER CHIP RES 100K OHM
5% 0402
R448 0613952R01 CER CHIP RES 10K OHM 5%
0402
R449 0613952R10 CER CHIP RES 24K OHM 5%
0402
R450 0613959Y45 CER CHIP RES 68.0 OHM
5% 2512
R451 0613952R05 CER CHIP RES 15K OHM 5%
0402
R452 0613952R25 CER CHIP RES 100K OHM
5% 0402
R453 NOTPLACED -
R454 NOTPLACED -
R455 NOTPLACED -
R456 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R457 0613952R01 CER CHIP RES 10K OHM 5%
0402
R460 0613952Q89 CER CHIP RES 4700 OHM
5% 0402
R461 0613952Q55 CER CHIP RES 180 OHM 5%
0402
R462 0613952R01 CER CHIP RES 10K OHM 5%
0402
R463 0613952Q60 CER CHIP RES 300 OHM 5%
0402
R471 0613952R08 CER CHIP RES 20K OHM 5%
0402
R472 0613952R14 CER CHIP RES 36K OHM 5%
0402
R473 0613952Q25 CER CHIP RES 10.0 OHM
5% 0402
R475 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R476 0613952R37 CER CHIP RES 330K OHM
5% 0402
R477 0613952Q73 CER CHIP RES 1000 OHM
5% 0402
R478 0613952R01 CER CHIP RES 10K OHM 5%
0402
R479 0613952Q66 CER CHIP RES 510 OHM 5%
0402
R481 0613952R10 CER CHIP RES 24K OHM 5%
0402
R492 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
Circuit
Ref
Motorola
Part No.
Description
