Motorola GP series Service Information

VHF PCB 8086101B09 Parts List (GP1280) 4-23
Q3721 4802245J50 DUAL NPN/PNP UMC5N
Q3801 4813827A07 NPNSML SIG MMBR941LT1 7Y
Q400 4809579E18 MOSFET P-CHAN TP010IT
Q403 4880214G02 TSTR MMBT3904
Q405 4802245J54 UMG5N DIGITAL TRANSIS-
TOR
Q410 4802245J54 UMG5N DIGITAL TRANSIS-
TOR
Q416 4809579E18 MOSFET P-CHAN TP010IT
Q417 4802245J50 DUAL NPN/PNP UMC5N
Q502 5180159R01 DUAL TRANS NPNS
Q505 4880214G02 TSTR MMBT3904
R3200 0662057M54 150 5% 20X40
R3201 0662057M82 2200 5% 20X40
R3202 0662057M90 4700 5% 20X40
R3203 0662057M98 10K 5% 20X40
R3204 0662057M26 10 5% 20X40
R3205 0662057M74 1000 5% 20X40
R3206 0662057N23 100K 5% 20X40
R3207 0662057N13 39K 5% 20X40
R3208 0662057M50 100 5% 20X40
R3209 0662057M74 1000 5% 20X40
R3210 0662057M82 2200 5% 20X40
R3211 0662057M82 2200 5% 20X40
R3212 0662057M90 4700 5% 20X40
R3213 0662057M82 2200 5% 20X40
R3214 0662057M34 22 5% 20X 40
R3219 0662057M50 100 5% 20X40
R3220 0662057M90 4700 5% 20X40
R3221 0662057M50 100 5% 20X40
R3224 0662057M26 10 5% 20X40
R3225 0662057M74 1000 5% 20X40
R3226 0662057M26 10 5% 20X40
R3270 0662057M74 1000 5% 20X40
R3271 0662057M42 47 5% 20X40
R3272 0662057N15 47K 5% 20X40
R3273 0662057N15 47K 5% 20X40
R3274 0662057M83 2400 5% 20X40
R3275 0662057M74 1000 5% 20X40
R3276 0662057N30 200K 5% 20X40
R3303 0662057N23 100K 5% 20X40
R3304 0662057N23 100K 5% 20X40
R3305 0662057N19 68K 5% 20X40
R3306 0662057M82 2200 5% 20X40
R3307 0662057N11 33K 5% 20X40
R3308 0662057M78 1500 5% 20X40
R3309 0662057M92 5600 5% 20X40
R3310 0662057M98 10K 5% 20X40
R3311 0662057M26 10 5% 20X40
R3312 0662057M38 33 5% 20X40
R3313 0662057M34 22 5% 20X 40
Circuit
Ref
Motorola
Part No
Description
R3314 0662057M26 10 5% 20X40
R3315 0662057M62 330 5% 20X40
R3316 0662057M66 470 5% 20X40
R3317 0662057N23 100K 5% 20X40
R3318 0662057M66 470 5% 20X40
R3321 0662057M54 150 5% 20X40
R3322 0662057M58 220 5% 20X40
R3323 0662057M32 18 5% 20X40
R3324 0662057M58 220 5% 20X40
R3501 0662057M61 300 5% 20X40
R3502 0662057M32 18 5% 20X40
R3503 0662057M61 300 5% 20X40
R3505 0662057M62 330 5% 20X40
R3512 0662057A27 120 OHMS 5%
R3513 0662057A25 100 OHMS 5%
R3519 0680539Z01 PWR METAL STRIP RES
R3542 0662057M92 5600 5% 20X40
R3543 0662057M50 100 5% 20X40
R3544 0662057A25 100 OHMS 5%
R3545 0662057A25 100 OHMS 5%
R3546 0662057N11 33K 5% 20X40
R3547 0662057N01 12K 5% 20X40
R3548 0662057M95 7500 55 20X40
R3551 0662057M40 39 5% 20X40
R3561 0662057N01 12K 5% 20X40
R3562 0662057N11 33K 5% 20X40
R3563 0662057N33 270K 5% 20X40
R3564 0662057N35 330K 5% 20X40
R3569 0662057M92 5600 5% 20X40
R3570 0662057M98 10K 5% 20X40
R3571 0662057A27 120 OHMS 5%
R3572 0662057A27 120 OHMS 5%
R3573 0662057A27 120 OHMS 5%
R3701 0662057M50 100 5% 20X40
R3703 0662057M54 150 5% 20X40
R3704 0662057M54 150 5% 20X40
R3705 0662057N11 33K 5% 20X40
R3721 0662057M66 470 5% 20X40
R3722 0662057M74 1000 5% 20X40
R3723 0662057M50 100 5% 20X40
R3727 0662057N23 100K 5% 20X40
R3741 0662057M50 100 5% 20X40
R3751 0662057N30 200K 5% 20X40
R3752 0662057N35 330K 5% 20X40
R3761 0662057N15 47K 5% 20X40
R3802 0662057M50 100 5% 20X40
R3803 0662057M58 220 5% 20X40
R3804 0662057M98 10K 5% 20X40
R3805 0662057N08 24K 5% 20X40
R3806 0662057M34 22 5% 20X 40
R3808 0662057M26 10 5% 20X40
Circuit
Ref
Motorola
Part No
Description
R3811 0662057M50 100 5% 20X40
R3816 0662057M74 1000 5% 20X40
R3817 0662057M01 0 5% 20X40
R3821 0662057M58 220 5% 20X40
R3822 0662057M42 47 5% 20X40
R3823 0662057N11 33K 5% 20X40
R3824 0662057N07 22K 5% 20X40
R3825 0662057M38 33 5% 20X40
R3826 0662057M32 18 5% 20X40
R3828 0662057M50 100 5% 20X40
R3829 0662057M01 0 5% 20X40
R3831 0662057M98 10K 5% 20X40
R3832 0662057N01 12K 5% 20X40
R3833 0662057M58 220 5% 20X40
R3834 0662057M42 47 5% 20X40
R3835 0662057N15 47K 5% 20X40
R3836 0662057M98 10K 5% 20X40
R400 0662057N15 47K 5% 20X40
R4001 0662057M74 1000 5% 20X40
R4002 0662057M74 1000 5% 20X40
R4003 0662057M74 1000 5% 20X40
R4004 0662057M74 1000 5% 20X40
R4005 0662057M74 1000 5% 20X40
R4006 0662057M74 1000 5% 20X40
R4007 0662057M74 1000 5% 20X40
R4008 0662057M74 1000 5% 20X40
R4009 0662057M74 1000 5% 20X40
R401 0662057M01 0 5% 20X40
R405 0662057M01 0 5% 20X40
R406 0662057N20 75K 5% 20X40
R407 0662057N19 68K 5% 20X40
R409 0662057M98 10K 5% 20X40
R410 0662057N23 100K 5% 20X40
R411 0662057M98 10K 5% 20X40
R413 0662057M01 0 5% 20X40
R414 0662057V34 180K 1% 1/16W
R415 0662057V26 91K 1% 1/16W
R416 0662057N13 39K 5% 20X40
R418 0662057M01 0 5% 20X40
R419 0662057M67 0 5% 20X40
R420 0662057B46 10.0 MEG OHMS 5%
R421 0662057M81 2000 5% 20X40
R423 0662057N21 82K 5% 20X40
R424 0662057N12 36K 5% 20X40
R425 0662057N10 30K 5% 20X40
R426 0662057N35 330K 5% 20X40
R427 0662057M84 2700 5% 20X40
R428 0662057M10 2.2 5% 20X40
R429 0662057M98 10K 5% 20X40
R431 0662057N39 470K 5% 20X40
R432 0662057N16 51K 5% 20X40
Circuit
Ref
Motorola
Part No
Description
R434 0662057M62 330 5% 20X40
R435 0662057M81 2000 5% 20X40
R436 0662057M01 0 5% 20X40
R445 0662057N08 24K 5% 20X40
R446 0662057N31 220K 5% 20X40
R447 0662057N51 1.5 MEG 5% 20X40
R448 0662057N33 270K 5% 20X40
R449 0662057N08 24K 5% 20X40
R450 0683962T45 68 5-1
R457 0662057M98 10K 5% 20X40
R460 0662057M90 4700 5% 20X40
R461 0662057M56 180 5% 20X40
R462 0662057M98 10K 5% 20X40
R463 0662057M61 300 5% 20X40
R471 0662057M92 5600 5% 20X40
R472 0662057M93 6200 5% 20X40
R473 0662057M26 10 5% 20X40
R475 0662057M01 0 5% 20X40
R476 0662057N08 24K 5% 20X40
R477 0662057M74 1000 5% 20X40
R478 0662057M98 10K 5% 20X40
R481 0662057N08 24K 5% 20X40
R492 0662057M01 0 5% 20X40
R499 0662057M98 10K 5% 20X40
R501 0662057M70 680 5% 20X40
R502 0662057M56 180 5% 20X40
R505 0662057M98 10K 5% 20X40
R506 0662057N15 47K 5% 20X40
R701 0662057N05 18K 5% 20X40
R702 0662057N05 18K 5% 20X40
R703 0662057M74 1000 5% 20X40
R704 0662057N13 39K 5% 20X40
R705 0662057N13 39K 5% 20X40
R706 0662057N17 56K 5% 20X40
R707 0662057M91 5100 5% 20X40
R708 0662057N41 560K 5% 20X40
R709 0662057N47 1.0 MEG 5% 20X40
R710 0662057N39 470K 5% 20X40
R716 0662057N01 12K 5% 20X40
R717 0662057M82 2200 5% 20X40
RT400 0680590Z01 THERMISTOR_33K
S501 4080710Z02 SWITCH (FREQUENCY)
S502 1880619Z01 POTENTIOMETER, VOLUME
SH3201 2602023X08 SHIELD
SH3202 2686081B02 SHIELD
SH3203 2686081B03 SHIELD
SH3301 2686081B01 SHIELD
SH3302 2686081B05 SHIELD
SH3303 2686081B06 SHIELD
SH3501 2686081B03 SHIELD
SH3502 2686081B04 SHIELD
Circuit
Ref
Motorola
Part No
Description

Motorola GP series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Number of Channels	16
Channel Spacing	12.5 kHz / 25 kHz
Battery Life	8 hours (with standard battery)
Operating Voltage	7.5V DC
Ingress Protection	IP54
MIL-STD	810 C, D, E, F
