Motorola GP series Service Information

4-28 VHF PCB 8486062B14 Parts List
C427 2113743N50 100 PF 5% COG
C428 2113743M24 100000 PF +80-20% Y5V
C429 2113743M24 100000 PF +80-20% Y5V
C430 2113928N01 CER CHIP 0.1UF 10% 6.3
C431 2113743N50 100 PF 5% COG
C433 2113743L41 10000 PF 10%
C434 2113743M24 100000 PF +80-20% Y5V
only GP360, GP380, GP680
C435 2113743M24 100000 PF +80-20% Y5V
C436 2113743N34 22.0 PF 5% COG
only GP360, GP380, GP680
C437 2113743N34 22.0 PF 5% COG
only GP360, GP380, GP680
C440 2113743G26 4.7UF 16V + 80-20%
C441 2113743L09 470 PF 10%
C442 2113743E20 CHIP. 10 UF 10%
C443 2113928N01 CER CHIP 0.1UF 10% 6.3
C444 2113743N50 100 PF 5% COG
C445 2113743L09 470 PF 10%
C446 2113743L09 470 PF 10%
C447 2113928N01 CER CHIP 0.1UF 10% 6.3
C448 2113928N01 CER CHIP 0.1UF 10% 6.3
C449 2113743N50 100 PF 5% COG
C451 2113743M08 22000PF +80-20% Y5V
C452 2113743G26 4.7UF 16V + 80-20%
C453 2113743N50 100 PF 5% COG
C456 2113743N50 100 PF 5% COG
C458 2113743N50 100 PF 5% COG
C459 2113743N50 100 PF 5% COG
C463 2113743N50 100 PF 5% COG
C466 2113743N50 100 PF 5% COG
C467 2113928N01 CER CHIP 0.1UF 10% 6.3
C471 2113743L09 470 PF 10%
C472 2113743L09 470 PF 10%
C473 2113743L09 470 PF 10%
C474 2113743L41 10000 PF 10%
C475 2113743H14 10.0 UF 16V +80-20%
C476 2113928D08 CERAMIC CHIP 10.0UF
C477 2113743L17 1000 PF 10%
C478 2113743L17 1000 PF 10%
C479 2113928N01 CER CHIP 0.1UF 10% 6.3
C480 2113928D08 CERAMIC CHIP 10.0UF
C481 2113928N01 CER CHIP 0.1UF 10% 6.3
C482 2113928N01 CER CHIP 0.1UF 10% 6.3
C483 2113743L09 470 PF 10%
C484 2113743L09 470 PF 10%
C490 2113743L09 470 PF 10%
C491 2113743L09 470 PF 10%
C492 2113743L09 470 PF 10%
C493 2113743N50 100 PF 5% COG
C494 2113743N50 100 PF 5% COG
C495 2113743L09 470 PF 10%
C496 2113743L09 470 PF 10%
C497 2113743L09 470 PF 10%
C4020 2113743L17 1000PF 10%
Placed on PCB 8486062B14 only
Circuit
Ref
Motorola
Part No
Description
C4021 2113743L17 1000PF 10%
Placed on PCB 8486062B14 only
C502 2311049A05 TANT 10% 0.47UF
C503 2113743N50 100 PF 5% COG
C505 2113743N50 100 PF 5% COG
C511 2113743N50 100 PF 5% COG
C512 2113743N50 100 PF 5% COG
C513 2113743N50 100 PF 5% COG
C514 2113743N50 100 PF 5% COG
C520 2113743L41 10000 PF 10%
C521 2113743L41 10000 PF 10%
C522 2113743L41 10000 PF 10%
C523 2113743L41 10000 PF 10%
C535 2113743L17 1000 PF 10%
CR3301 4802245J42 RING QUAD SOT-143 PKG
CR3302 4805129M96 DIODE SMBV1032
CR3303 4880154K03 SOT MMBD353 DUAL SCHKY
CR411** 4802245J47 SCHOTTKY BARRIER(RB471E)
CR412** 4802245J47 SCHOTTKY BARRIER(RB471E)
CR413** 4802245J47 SCHOTTKY BARRIER(RB471E)
**Placed on PCB 8486062B12 only
CR411*** 4802245J62 SCHOTTKY BARRIER(RB731U)
CR412*** 4802245J62 SCHOTTKY BARRIER(RB731U)
CR413*** 4802245J62 SCHOTTKY BARRIER(RB731U)
***Placed on PCB 8486062B14 only
CR440 4813833C02 DUAL 70V '5B' COMM CATH
CR501 4880107R01 RECTIFIER
CR503 4805729G49 LED RED/YEL
D3270 4862824C01 VARACTOR
D3301 4802081B58 DUAL SILCON (VARICAP)
D3302 4802081B58 DUAL SILCON (VARICAP)
D3521 4880973Z02 PIN DIODE
D3551 4880973Z02 PIN DIODE
D3701 4802233J09 TRIPLE SOT25-RH
D3702 4802233J09 TRIPLE SOT25-RH
* D3761 4862824C03 VARACTOR
D3821 4805649Q13 VCTR ISV 228
D3831 4805649Q13 VCTR ISV 228
D3832 4862824C01 VARACTOR
E400 2480640Z01 C/IND BK1005HM471 BEAD
E401 2480640Z01 C/IND BK1005HM471 BEAD
E402 2480640Z01 C/IND BK1005HM471 BEAD
E403 2480640Z01 C/IND BK1005HM471 BEAD
E404 2480640Z01 C/IND BK1005HM471 BEAD
E405 2480640Z01 C/IND BK1005HM471 BEAD
E406 2480640Z01 C/IND BK1005HM471 BEAD
E407 2480640Z01 C/IND BK1005HM471 BEAD
E408 2480640Z01 C/IND BK1005HM471 BEAD
E409 2480640Z01 C/IND BK1005HM471 BEAD
F501 6580542Z01 FUSE CHIP SMT TR/1608FF 3A
FL401 4870368G02 CLOCK OSC XTAL
only GP360, GP380, GP680
H3501 2680499Z01 HEAT SPREADER
J3501 0180117S05 RF JACK ASSEMBLY
J3502 0280519Z02 NUT, ANTENNA
J400 0905505Y04 CONN ZIF 40Pin
Circuit
Ref
Motorola
Part No
Description
not in GP320
J403 0905505Y02 CONN ZIF MALE 20 PIN
L3200 2462587N68 CHIP IND 1000 NH 5%
L3202 2462587N68 CHIP IND 1000 NH 5%
L3221 2462587N68 CHIP IND 1000 NH 5%
L3270 2462587T15 IND CHIP 100NH 5% LOW PRO
L3271 2462587Q20 IND CHIP 2,200NH 20%
L3301 2462587T35 IND CHIP 12NH 5% LOW PRO
L3303 2462587T35 IND CHIP 12NH 5% LOW PRO
L3304 2462587T23 IND CHIP 470NH 5% LOW PRO
L3305 2462587T35 IND CHIP 12NH 5% LOW PRO
L3306 2462587T35 IND CHIP 12NH 5% LOW PRO
L3308 2462587T34 IND CHIP 10NH 5% LOW PRO
L3309 2462587N55 CHIP IND 150 NH 5%
L3312 2462587V28 CHIP IND 33 NH 5% 0805
L3501 2413926H09 IND CHIP 5.6 NH +/- 0.3NH
L3503 2462587V32 CHIP IND 68NH 5% 0805
L3504 2462587N51 CHIP IND 68 NH 5%
L3511 2462587N44 CHIP IND 18 NH 5%
L3512 2479990B01 AIR WOUND GREEN 11.03NH
L3513 2479990A02 AIR WOUND GREEN 7.66NH
L3515 2479990C03 AIR WOUND GREEN 13.85NH
L3518 2462587N48 CHIP IND 39 NH 5%
L3519 2484657R01 INDUCTOR BEAD CHIP
L3521 2479990A02 AIR WOUND GREEN 7.66NH
L3522 2479990E01 COIL AIR WOUND GREEN 23.75
L3523 2462587N68 CHIP IND 1000 NH 5%
L3531 2479990N01 AIR WOUND GREEN 43.67NH
L3532 2479990N01 AIR WOUND GREEN 43.67NH
L3538 2479990M01 AIR WOUND GREEN 30.54NH
L3551 2479990N01 AIR WOUND GREEN 43.67NH
L3552 2479990A02 AIR WOUND GREEN 7.66NH
L3701 2462587Q42 IND CHIP 390NH 10%
L3731 2462587Q20 IND CHIP 2,200NH 20%
L3801 2462587V34 CHIP IND 100NH 5% 0805
L3809 2462587V27 CHIP IND 27 NH 5% 0805
L3811 2462587V34 CHIP IND 100NH 5% 0805
L3812 2462587V34 CHIP IND 100NH 5% 0805
L3813 2462587Q47 IND CHIP 1000 NH 10%
L3816 2462587V34 CHIP IND 100NH 5% 0805
L3821 2462587N50 CHIP IND 56 NH 5%
L3822 2462587N49 CHIP IND 47 NH 5%
L3823 2462587N49 CHIP IND 47 NH 5%
L3824 2462587N68 CHIP IND 1000 NH 5%
L3825 2462587V34 CHIP IND 100NH 5%
L3826 2462587N68 CHIP IND 1000 NH 5%
L3831 2462587N50 CHIP IND 56 NH 5%
L3832 2462587N51 CHIP IND 68 NH 5%
L3833 2462587N50 CHIP IND 56 NH 5%
L3834 2462587N68 CHIP IND 1000 NH 5%
L400 2462587Q42 IND CHIP 390NH 10%
L401 2462587Q42 IND CHIP 390NH 10%
L410 2462587Q42 IND CHIP 390NH 10%
L411 2462587Q42 IND CHIP 390NH 10%
L505 2462587Q42 IND CHIP 390NH 10%
PB501 4080523Z01 SWITCH, TACT
Circuit
Ref
Motorola
Part No
Description
PB502 4080523Z01 SWITCH, TACT
PB503 4080523Z01 SWITCH, TACT
not in GP320
PB504 4080523Z01 SWITCH, TACT
PB505 4080523Z01 SWITCH, TACT
not in GP320
Q3200 4813827A07 TSTR NPN SML SIG
MMBR941LT1
Q3201 4880214G02 TSTR MMBT3904
Q3202 4880214G02 TSTR MMBT3904
Q3270 4805218N63 RF TRANS SOT 323 BFQ67W
Q3301 4880214G02 TSTR MMBT3904
Q3302 4813827A07 TSTR NPN MMBR941LT1
Q3501 4802245J55 TSTR POWER FIELD EFFECT
Q3561 4813824A17 XSTR PNP40V .2A B=100-300
Q3721 4802245J50 TSTR DUAL NPN/PNP UMC5N
Q3801 4813827A07 TSTR NPN MMBR941LT1
Q400 4809579E18 MOSFET P-CHAN TP010IT
Q403 4880214G02 TSTR MMBT3904
Q405 4802245J54 UMG5N DIGITAL TRANSISTOR
Q410 4802245J54 UMG5N DIGITAL TRANSISTOR
Q416 4809579E18 MOSFET P-CHAN TP010IT
only GP360, GP380, GP680
Q417 4802245J50 TSTR DUAL NPN/PNP UMC5N
Q502 5180159R01 DUAL TRANS NPNS
Q505 4880214G02 TSTR MMBT3904
R3200 0662057M54 150 5% 20X40
R3201 0662057M82 2200 5% 20X40
R3202 0662057M90 4700 5% 20X40
R3203 0662057M98 10K 5% 20X40
R3204 0662057M26 10 5% 20X40
R3205 0662057M74 1000 5% 20X40
R3206 0662057N23 100K 5% 20X40
R3207 0662057N13 39K 5% 20X40
R3208 0662057M50 100 5% 20X40
R3209 0662057M74 1000 5% 20X40
R3210 0662057M82 2200 5% 20X40
R3211 0662057M82 2200 5% 20X40
R3212 0662057M90 4700 5% 20X40
R3213 0662057M82 2200 5% 20X40
R3214 0662057M34 22 5% 20X 40
R3219 0662057M50 100 5% 20X40
R3220 0662057M90 4700 5% 20X40
R3221 0662057M50 100 5% 20X40
R3224 0662057M26 10 5% 20X40
R3225 0662057M74 1000 5% 20X40
R3226 0662057M26 10 5% 20X40
R3270 0662057M74 1000 5% 20X40
R3271 0662057M42 47 5% 20X40
R3272 0662057N15 47K 5% 20X40
R3273 0662057N15 47K 5% 20X40
R3274 0662057M83 2400 5% 20X40
R3275 0662057M74 1000 5% 20X40
R3276 0662057N30 200K 5% 20X40
R3303 0662057N23 100K 5% 20X40
R3304 0662057N23 100K 5% 20X40
Circuit
Ref
Motorola
Part No
Description

Motorola GP series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Number of Channels	16
Channel Spacing	12.5 kHz / 25 kHz
Battery Life	8 hours (with standard battery)
Operating Voltage	7.5V DC
Ingress Protection	IP54
MIL-STD	810 C, D, E, F
