4-34 VHF PCB 8486101B10 Parts List (GP1280)

C4001 2113743N50 100 PF 5%

C4002 2113743N50 100 PF 5%

C4003 2113743N50 100 PF 5%

C401 2113743M24 100000 PF +80-20% Y5V

C402 2113743M24 100000 PF +80-20% Y5V

C4020 2113743L17 1000 PF 10%

C4021 2113743L17 1000 PF 10%

C403 2113928D08 CERAMIC CHIP 10.0UF

C407 2113928N01 0.1UF 10% 6.3

C408 2113743N50 100 PF 5%

C409 2113743M24 100000 PF +80-20% Y5V

C410 2113928N01 0.1UF 10% 6.3

C411 2113743M24 100000 PF +80-20% Y5V

C414 2113743M24 100000 PF +80-20% Y5V

C415 2109720D01 LOW DIS T .01UF

C416 2113928N01 0.1UF 10% 6.3

C419 2113743L41 10000 PF 10%

C420 2113743L41 10000 PF 10%

C421 2113928N01 0.1UF 10% 6.3

C422 2113743M24 100000 PF +80-20% Y5V

C423 2113743N50 100 PF 5%

C424 2311049A59 TANT CHIP A/P 10UF 10% 6V

C425 2113743M24 100000 PF +80-20% Y5V

C426 2113743N50 100 PF 5%

C427 2113743N50 100 PF 5%

C428 2113743M24 100000 PF +80-20% Y5V

C429 2113743M24 100000 PF +80-20% Y5V

C430 2113928N01 0.1UF 10% 6.3

C431 2113743N50 100 PF 5%

C433 2113743L41 10000 PF 10%

C434 2113743M24 100000 PF +80-20% Y5V

C435 2113743M24 100000 PF +80-20% Y5V

C436 2113743N34 22.0 PF 5%

C437 2113743N34 22.0 PF 5%

C440 2113743G26 4.7UF 16V + 80-20%

C441 2113743L09 470 PF 10%

C442 2113743E20 10 UF 10%

C443 2113928N01 CERAMIC CHIP 10.0UF

C444 2113743N50 100 PF 5%

C445 2113743L09 470 PF 10%

C446 2113743L09 470 PF 10%

C447 2113928N01 CERAMIC CHIP 10.0UF

C448 2113928N01 CERAMIC CHIP 10.0UF

C449 2113743N50 100 PF 5%

C451 2113743M08 22000PF +80-20% Y5V

C452 2113743G26 4.7UF 16V + 80-20%

C453 2113743N50 100 PF 5%

C456 2113743N50 100 PF 5%

C458 2113743N50 100 PF 5%

C459 2113743N50 100 PF 5%

C463 2113743N50 100 PF 5%

Circuit

Ref

Motorola

Part No

Description

C466 2113743N50 100 PF 5%

C467 2113928N01 0.1UF 10% 6.3

C471 2113743L09 470 PF 10%

C472 2113743L09 470 PF 10%

C473 2113743L09 470 PF 10%

C474 2113743L41 10000 PF 10%

C475 2113743H14 10.0 UF 16V +80-20%

C476 2113928D08 CERAMIC CHIP 10.0UF

C477 2113743L17 1000 PF 10%

C478 2113743L17 1000 PF 10%

C479 2113928N01 0.1UF 10% 6.3

C480 2113928D08 CERAMIC CHIP 10.0UF

C481 2113928N01 0.1UF 10% 6.3

C482 2113928N01 0.1UF 10% 6.3

C483 2113743L09 470 PF 10%

C484 2113743L09 470 PF 10%

C490 2113743L09 470 PF 10%

C491 2113743L09 470 PF 10%

C492 2113743L09 470 PF 10%

C493 2113743N50 100 PF 5%

C494 2113743N50 100 PF 5%

C495 2113743L09 470 PF 10%

C496 2113743L09 470 PF 10%

C497 2113743L09 470 PF 10%

C502 2311049A05 TANT 10% 0.47UF

C503 2113743N50 100 PF 5%

C505 2113743N50 100 PF 5%

C511 2113743N50 100 PF 5%

C512 2113743N50 100 PF 5%

C513 2113743N50 100 PF 5%

C514 2113743N50 100 PF 5%

C520 2113743L41 10000 PF 10%

C521 2113743L41 10000 PF 10%

C522 2113743L41 10000 PF 10%

C523 2113743L41 10000 PF 10%

C535 2113743L17 1000 PF 10%

C701 2180478Z20 MONOLITHIC CER (1.0UF)

C702 2113928N01 0.1UF 10% 6.3

C703 2113743N50 100 PF 5%

C704 2113928N01 0.1UF 10% 6.3

C705 2113928N01 0.1UF 10% 6.3

C707 2113928N01 0.1UF 10% 6.3

C708 2113928N01 0.1UF 10% 6.3

C709 2113743L17 1000 PF 10%

C711 2113743L41 10000 PF 10%

C713 2113928N01 0.1UF 10% 6.3

C714 2113928N01 0.1UF 10% 6.3

C715 2113928N01 0.1UF 10% 6.3

C717 2113928N01 0.1UF 10% 6.3

C718 2113743L17 1000 PF 10%

C719 2113928N01 0.1UF 10% 6.3

Circuit

Ref

Motorola

Part No

Description

CR3301 4802245J42 RING QUAD SOT-143 PKG

CR3302 4805129M96 DIODE DUAL

CR3303 4880154K03 SOT MMBD353 DUAL SCHTKY

CR411 4802245J47 SCHOTTKY BARIER(RB471E)

Placed on PCB 8486101B09 only

CR412 4802245J62 DIODE SCHOTTKY, RB731U

CR413 4802245J62 DIODE SCHOTTKY, RB731U

CR440 4813833C02 DUAL 70V '5B' COMM CATH

CR501 4880107R01 RECTIFIER

CR503 4805729G49 DIODE RED/YEL

CR700 4802245J47 SCHOTTKY BARIER(RB471E)

D3270 4862824C01 DIODE VARACTOR

D3301 4802081B58 DUAL SILCON (VARICAP)

D3302 4802081B58 DUAL SILCON (VARICAP)

D3521 4880973Z02 PIN DIODE

D3551 4880973Z02 PIN DIODE

D3701 4802233J09 DIODE TRIPLE SOT25-RH

D3702 4802233J09 DIODE TRIPLE SOT25-RH

* D3761 4862824C03 DIODE VARACTOR

D3821 4805649Q13 DIODE VCTR ISV 228

D3831 4805649Q13 DIODE VCTR ISV 228

D3832 4862824C01 DIODE VARACTOR

E400 2480640Z01 C/IND BK1005HM471 BEAD

F501 6580542Z01 FUSE SMT TR/1608FF 3A

FL401 4870368G02 REFLOW CLOCK OSC XTAL

H3501 2680499Z01 HEAT SPREADER

J3501 0180117S05 RF JACK ASSEMBLY

J3502 0280519Z02 NUT, ANTENNA

J400 0905505Y04 CONN ZIF HORIZONTAL

J403 0905505Y02 CONN MALE 20 PIN ZIF

L3200 2462587N68 CHIP IND 1000 NH 5%

L3202 2462587N68 CHIP IND 1000 NH 5%

L3221 2462587N68 CHIP IND 1000 NH 5%

L3270 2462587T15 IND 100NH 5% LOW PRO

L3271 2462587Q20 IND CHIP 2,200NH 20%

L3301 2462587T35 IND CHIP 12NH 5% LOW PRO

L3303 2462587T35 IND CHIP 12NH 5% LOW PRO

L3304 2462587T23 IND CHIP 470NH 5%LOW PRO

L3305 2462587T35 IND CHIP 12NH 5% LOW PRO

L3306 2462587T35 IND CHIP 12NH 5% LOW PRO

L3308 2462587T34 IND CHIP 10NH 5% LOW PRO

L3309 2462587N55 CHIP IND 150 NH 5%

L3312 2462587V28 CHIP IND 33 NH 5% 0805

L3501 2413926H09 IND CHIP 5.6 NH +/- 0.3NH

L3503 2462587V32 CHIP IND 68NH 5% 0805

L3504 2462587N51 CHIP IND 68 NH 5%

L3511 2462587N44 CHIP IND 18 NH 5%

L3512 2479990B01 AIR WND COIL/GRN 11.03NH

L3513 2479990A02 AIR WND COIL/GRN 7.66NH

L3515 2479990C03 AIR WND COIL/GRN 13.85NH

L3518 2462587N48 CHIP IND 39 NH 5%

Circuit

Ref

Motorola

Part No

Description

L3519 2484657R01 INDUCTOR BEAD CHIP

L3521 2479990A02 AIR WND COIL/GRN 7.66NH

L3522 2479990E01 COIL AIR WND/GRN 23.75

L3523 2462587N68 CHIP IND 1000 NH 5%

L3531 2479990N01 AIR WND COIL/GRN 43.67NH

L3532 2479990N01 AIR WND COIL/GRN 43.67NH

L3538 2479990M01 AIR WND COIL/GRN 30.54NH

L3551 2479990N01 AIR WND COIL/GRN 43.67NH

L3552 2479990A02 AIR WND COIL/GRN 7.66NH

L3701 2462587Q42 IND CHIP 390NH 10%

L3731 2462587Q20 IND CHIP 2,200NH 20%

L3801 2462587V34 CHIP IND 100NH 5% 0805

L3809 2462587V27 CHIP IND 27 NH 5% 0805

L3811 2462587V34 CHIP IND 100NH 5% 0805

L3812 2462587V34 CHIP IND 100NH 5% 0805

L3813 2462587Q47 IND CHIP 1000 NH 10%

L3816 2462587V34 CHIP IND 100NH 5% 0805

L3821 2462587N50 CHIP IND 56 NH 5%

L3822 2462587N49 CHIP IND 47 NH 5%

L3823 2462587N49 CHIP IND 47 NH 5%

L3824 2462587N68 CHIP IND 1000 NH 5%

L3825 2462587V34 CHIP IND 100NH 5% 0805

L3826 2462587N68 CHIP IND 1000 NH 5%

L3831 2462587N50 CHIP IND 56 NH 5%

L3832 2462587N51 CHIP IND 68 NH 5%

L3833 2462587N50 CHIP IND 56 NH 5%

L3834 2462587N68 CHIP IND 1000 NH 5%

L400 2462587Q42 IND CHIP 390NH 10%

L401 2462587Q42 IND CHIP 390NH 10%

L410 2462587Q42 IND CHIP 390NH 10%

L411 2462587Q42 IND CHIP 390NH 10%

L505 2462587Q42 IND CHIP 390NH 10%

M701 7585651Z01 PAD, FLEXIBLE

M702 7585651Z01 PAD, FLEXIBLE

M703 7585651Z01 PAD, FLEXIBLE

M704 7585651Z01 PAD, FLEXIBLE

M705 7585651Z01 PAD, FLEXIBLE

M706 7585651Z01 PAD, FLEXIBLE

PB501 4080523Z01 SWITCH, TACT

PB502 4080523Z01 SWITCH, TACT

PB503 4080523Z01 SWITCH, TACT

PB504 4080523Z01 SWITCH, TACT

PB505 4080523Z01 SWITCH, TACT

Q3200 4813827A07 NPNSML SIG MMBR941LT1 7Y

Q3201 4880214G02 TSTR MMBT3904

Q3202 4880214G02 TSTR MMBT3904

Q3270 4805218N63 RF TRANS SOT 323 BFQ67W

Q3301 4880214G02 TSTR MMBT3904

Q3302 4813827A07 NPNSML SIG MMBR941LT1 7Y

Q3501 4802245J55 POWER FIELD EFFECT

Q3561 4813824A17 XSTR PNP40V .2A B=100-300

Circuit

Ref

Motorola

Part No

Description
